CHECK OF CAN SYSTEM TYPE (HOW TO USE CAN SYSTEM TYPE SPECIFICATION CHART)
Determine CAN system type based on vehicle equipment.
Note. This chart is used if CONSULT-III does not automatically recognize CAN system type. There are two styles for CAN system type specification charts. Depending on the number of available system types, either style A or style B may be used.
CAN System Type Specification Chart (Style A)
Note. CAN system type is easily checked with the vehicle equipment identification information shown in the chart.
Scheme 1
CAN System Type Specification Chart (Style B)
Note. CAN system type is easily checked with the vehicle equipment identification information shown in the chart.
Scheme 2
CAN System Specification Chart
Determine CAN system type from the following specification chart.
Note. Refer to " TROUBLE DIAGNOSIS PROCEDURE " for how to use CAN system specification chart.
| Body type | Coupe | Roadster | ||||||
|---|---|---|---|---|---|---|---|---|
| Axle | 2WD | |||||||
| Engine | VQ37VHR | |||||||
| Transmission | M/T | A/T | M/T | A/T | ||||
| Brake control | VDC | |||||||
| Navigation system | X | X | X | X | ||||
| CAN system type | 21 | 22 | 23 | 24 | 1 | 2 | 3 | 4 |
| X: Applicable | ||||||||
