Automatic Transmission: Adjustments Nissan 370Z I

Adjustment

ATF : Refer to " GENERAL SPECIFICATION ".

Fluid capacity : Refer to " GENERAL SPECIFICATION ".

Scheme 35

Scheme 36

1. Install the O-ring (315268E000) (A) to the charging pipe (310811EA5A) (B).
2. Start the engine.
3. Make the ATF temperature approximately 40°C (104°F). NOTE: The ATF level is greatly affected by the temperature. Always check the ATF temperature on "ATF TEMP 1" of "Data Monitor" using CONSULT-III.
4. Park vehicle on level surface and set parking brake.
5. Shift the selector lever through each gear position. Leave selector lever in "P" position.
6. Lift up the vehicle.
7. Check the ATF leakage from transmission.
8. Remove overflow plug from oil pan.
9. Install the charging pipe (A) to the overflow plug hole. CAUTION: Tighten the charging pipe by hand.
10. Install the bucket pump hose (B) to the charging pipe. CAUTION: Insert the bucket pump hose all the way to the end of the charging pipe.
11. Fill approximately 0.5 liters (1/2 US qt, 1/2 lmp qt) of the ATF.
12. Check that the ATF leaks when removing the charging pipe and the bucket pump hose. If the ATF does not leak, refill the ATF.
13. When the ATF starts to drip, tighten the overflow plug to the oil pan to the specified torque. Refer to " «EXPLODED VIEW»(ref-402639-S37593464942011053100000) ". CAUTION: Never reuse overflow plug.

ADJUSTMENT AFTER INSTALLATION

Adjust A/T position. Refer to " INSPECTION AND ADJUSTMENT ".

Scheme 37

Refer to " COMPONENTS " for symbols not described on the above.

Adjust A/T position. Refer to " INSPECTION AND ADJUSTMENT ".

Scheme 38

Refer to " COMPONENTS " for symbols in the figure.

Adjust A/T fluid level. Refer to " ADJUSTMENT ".

Scheme 39

Refer to " COMPONENTS " for symbols not described on the above.

Scheme 40

Scheme 41

Scheme 42

Scheme 43

Scheme 44

Scheme 45

Scheme 46

Scheme 47

Scheme 48

Scheme 49

Scheme 50

1. Drain ATF through drain plug.
2. Remove exhaust front tube and center muffler with power tool. Refer to " «EXPLODED VIEW»(ref-402635-S33524790992011053100000) ".
3. Separate propeller shaft assembly. Refer to " «EXPLODED VIEW»(ref-402640-S30514047112011053100000) ".
4. Remove control rod. Refer to " «EXPLODED VIEW»(ref-402639-S22607305772011053100000) ".
5. Support A/T assembly with a transmission jack. CAUTION: When setting transmission jack, be careful not to allow it to collide against the drain plug.
6. Remove rear engine mounting member with power tool. Refer to " «EXPLODED VIEW»(ref-402630-S37220918692011053100000) ".
7. Remove engine mounting insulator (rear). Refer to " «EXPLODED VIEW»(ref-402630-S37220918692011053100000) ".
8. Remove tightening bolts for rear extension assembly and transmission case.
9. Tap rear extension assembly with a soft hammer (A).
10. Remove rear extension assembly (with needle bearing) from transmission case.
11. Remove bearing race (1) from output shaft (2).
12. Remove output shaft (1) from transmission case by rotating left/right.
13. Remove parking gear (1) from output shaft (2).
14. Remove seal rings (1) from output shaft.
15. Remove needle bearing (1) from rear extension.
16. Remove parking actuator support (1) from rear extension.
17. Remove parking pawl (with return spring) (1) and pawl shaft (2) from rear extension.
18. Remove return spring (1) from parking pawl (2).

Adjust A/T positions. Refer to " INSPECTION AND ADJUSTMENT ".

Scheme 51

Refer to " COMPONENTS " for symbols in the figure.

Scheme 52

1. Separate propeller shaft assembly. Refer to " «EXPLODED VIEW»(ref-402640-S30514047112011053100000) ".
2. Remove rear oil seal (1) using a flat-bladed screwdriver (A). CAUTION: Be careful not to scratch rear extension assembly.

Adjust A/T fluid level. Refer to " ADJUSTMENT ".

Scheme 53

Refer to " COMPONENTS " for symbols not described on the above.

Scheme 54

Scheme 55

Scheme 56

Scheme 57

Scheme 58

Scheme 59

Scheme 60

1. Disconnect the battery cable from the negative terminal.
2. Drain ATF through drain plug.
3. Remove exhaust front tube and center muffler with power tool. Refer to " «EXPLODED VIEW»(ref-402635-S33524790992011053100000) ".
4. Separate propeller shaft assembly. Refer to " «EXPLODED VIEW»(ref-402640-S30514047112011053100000) ".
5. Remove control rod. Refer to " «EXPLODED VIEW»(ref-402639-S22607305772011053100000) ".
6. Remove exhaust mounting bracket. Refer to " «EXPLODED VIEW»(ref-402635-S33524790992011053100000) ".
7. Disconnect heated oxygen sensor 2 harness connectors (A).
8. Remove heated oxygen sensor 2 harness (B) from clips (1).
9. Remove bracket (2) from transmission assembly.
10. Remove clips (1).
11. Remove oil pan (2) and oil pan gasket.
12. Support A/T assembly with a transmission jack. CAUTION: When setting transmission jack, place wooden blocks to prevent from damaging control valve & TCM and transmission case.
13. Remove rear engine mounting member with power tool. Refer to " «EXPLODED VIEW»(ref-402630-S37220918692011053100000) ".
14. Remove engine mounting insulator (rear). Refer to " «EXPLODED VIEW»(ref-402630-S37220918692011053100000) ".
15. Remove tightening bolts for rear extension assembly and transmission case.
16. Tap rear extension assembly with a soft hammer (A).
17. Remove rear extension assembly (with needle bearing) from transmission case.
18. Disconnect output speed sensor connector (A). CAUTION: Be careful not to damage connector
19. Disengage terminal clips.
20. Remove output speed sensor (1) from transmission case. CAUTION: Never subject it to impact by dropping or hitting it. Never disassemble. Never allow metal filings, etc. to get on the sensor's front edge magnetic area. Never place in an area affected by magnetism.

Adjust A/T positions. Refer to " INSPECTION AND ADJUSTMENT ".

Scheme 61

Adjust A/T fluid level. Refer to " ADJUSTMENT ".

Scheme 62

Refer to " COMPONENTS " for symbols in the figure.

1. Adjust A/T fluid level. Refer to " «ADJUSTMENT»(ref-402639-S39389681162011053100000) ".
2. Adjust A/T position. Refer to " «INSPECTION AND ADJUSTMENT»(ref-402639-S25976953632011053100000) "

Scheme 63

Refer to " COMPONENTS " for symbols not described on the above.

Scheme 64

Refer to " COMPONENTS " for symbols not described on the above.

Scheme 65

Refer to " COMPONENTS " for symbols not described on the above.

Scheme 66

Refer to " COMPONENTS " for symbols in the figure.

Scheme 67

Refer to " COMPONENTS " for symbols in the figure.

Scheme 68

Refer to " COMPONENTS " for symbols in the figure.

Scheme 69

Refer to " COMPONENTS " for symbols in the figure.

Scheme 70

Scheme 71

ITEM SPECIFICATION

Scheme 72

SNAP RING SPECIFICATION
