Engine Mechanical: Specifications Nissan 350Z I рестайлинг

Parts Requiring Angle Tightening

1. Use angle wrench [SST: KV10112100 (BT8653-A)] for the final tightening of the following engine parts: Cylinder head bolts Lower cylinder block bolts Connecting rod cap bolts
2. Do not use a torque value for final tightening.
3. The torque value for these parts are for a preliminary step.
4. Ensure thread and seat surfaces are clean and coated with engine oil.

Scheme 1

1. After removing mounting bolts and nuts, separate the mating surface using seal cutter (SST) and remove old liquid gasket sealing. CAUTION: Be careful not to damage the mating surfaces.
2. Tap seal cutter to insert it, and then slide it by tapping on the side as shown in the figure.
3. In areas where seal cutter (SST) is difficult to use, use plastic hammer to lightly tap the parts, to remove it. CAUTION: If for some unavoidable reason tool such as screwdriver is used, be careful not to damage the mating surfaces. (Scheme 1): Inserting Tap Seal Cutter And Slide By Tapping On Side

Scheme 2

Scheme 3

Scheme 4

1. Using scraper, remove old liquid gasket adhering to the gasket application surface and the mating surface. Remove liquid gasket completely from the groove of the gasket application surface, mounting bolts, and bolt holes.
2. Wipe the liquid gasket application surface and the mating surface with white gasoline (lighting and heating use) to remove adhering moisture, grease and foreign materials. (Scheme 2): Removing Liquid Gasket Using Scraper
3. Attach liquid gasket tube to tube presser [SST: WS39930000 ( - )]. Use Genuine RTV Silicone Sealant or equivalent. Refer to " «RECOMMENDED CHEMICAL PRODUCTS AND SEALANTS»(ref-271535-S39395321612007111400000) ".
4. Apply liquid gasket without breaks to the specified location with the specified dimensions. If there is a groove for liquid gasket application, apply liquid gasket to the groove. (Scheme 3): Applying Liquid Gasket Without Breaks Specified Location As for bolt holes, normally apply liquid gasket inside the holes. Occasionally, it should be applied outside the holes. Make sure to read the text of this manual. Within five minutes of liquid gasket application, install the mating component. If liquid gasket protrudes, wipe it off immediately. Do not retighten mounting bolts or nuts after the installation. After 30 minutes or more have passed from the installation, fill engine oil and engine coolant. CAUTION: If there are specific instructions in this manual, observe them. (Scheme 4): Applying Bead Of Sealant To Bolt Holes

GENERAL SPECIFICATIONS

GENERAL SPECIFICATIONS Cylinder arrangement V-6 Displacement cm 3 (cu. in.) 3,498 (213.45) Bore and stroke mm (in) 95.5 x 81.4 (3.76 x 3.205) Valve arrangement DOHC Firing order 1-2-3-4-5-6 Number of piston rings Compression 2 Oil 1 Number of main bearings 4 Compression ratio 10.6 Compression pressure kPa (kg/cm 2 , psi)/300 RPM Standard 1,275 (13.0, 185) Minimum 981 (10.0, 142) Differential limit between cylinders 98 (1.0, 14) Cylinder number

GENERAL SPECIFICATIONS Valve timing (Intake valve timing control - "OFF")

Scheme 5

GENERAL SPECIFICATIONS
