O-Ring Part Numbers and Specifications
| Connection type | Piping connection point | Part number | QTY | O-ring size | |
|---|---|---|---|---|---|
| New | Low-pressure pipe 2 to low-pressure pipe 1 (One-touch joint) | 92473 N8221 | 2 | 16 | |
| Low-pressure pipe 2 to low-pressure flexible hose (One touch joint) | 92473 N8221 | 2 | 16 | ||
| High-pressure pipe 1 to high-pressure pipe 2 (One-touch joint) | 92471 N8221 | 2 | 8 | ||
| Condenser to high-pressure flexible hose (One-touch joint) | 92472 N8221 | 2 | 12 | ||
| Condenser to high-pressure pipe 1 (One-touch joint) | 92471 N8221 | 2 | 8 | ||
| Low-pressure pipe 1 to expansion valve | 92473 N8210 | 1 | 16 | ||
| High-pressure pipe 2 to expansion valve | 92471 N8210 | 1 | 8 | ||
| Compressor to low-pressure flexible hose | 92474 N8210 | 1 | 19 | ||
| Compressor to high-pressure flexible hose | 92472 N8210 | 1 | 12 | ||
| Liquid tank to condenser pipe | Inlet | 92471 N8210 | 1 | 8 | |
| Outlet | 1 | ||||
| Former | Refrigerant pressure sensor to liquid tank | J2476 89956 | 1 | 10 | |
| Expansion valve to evaporator | Inlet | 92475 71L00 | 1 | 12 | |
| Outlet | 92475 72L00 | 1 | 16 | ||
O-RING PART NUMBERS AND SPECIFICATIONS
| WARNING | Make sure all refrigerant is discharged into the recycling equipment and the pressure in the system is less than atmospheric pressure. Then gradually loosen the discharge side hose fitting and remove it. |
Tightening Connection Of Seal Seat. Scheme 1
