Wheel Alignment Specifications & Procedures Nissan 300ZX Z31

Wheel Alignment 2 illustrations

Scheme 1

Scheme 1: ALIGNMENT PROCEDURES
Scheme 1: ALIGNMENT PROCEDURES

Scheme 2

Scheme 2
Scheme 2
ApplicationSpecification
Front
Camber in Degrees
Fraction5/16 +/- 3/4
Decimal.31 +/- .75
Caster in Degrees
Fraction2 +/- 3/4
Decimal2.0 +/- .75
Toe-In in Inches
Fraction3/32 +/- 3/64
Decimal.09 +/- .05
Toe-In in Degrees
Fraction1/5 +/- 3/32
Decimal.20 +/- .09
Toe-Out in Turns
Inner35 1/2 +/- 1 1/2°
Outer29 +/- 2°
Steering Axis Inclination (SAI)(1)
Rear
Camber in Degrees
Fraction1/4 +/- 3/4
Decimal.25 +/- .75
Caster in Degrees
FractionN/A
DecimalN/A
Toe-In in Inches
FractionN/A
DecimalN/A
Toe-In in Degrees
FractionN/A
DecimalN/A
Toe-Out in Turns
InnerN/A
OuterN/A
Steering Axis Inclination (SAI)N/A
(1) Information not available.
(1)Information not available.

WHEEL ALIGNMENT SPECIFICATIONS (MAXIMA)

ApplicationSpecification
Rear
Camber in Degrees
Fraction7/16 +/- 3/4
Decimal.43 +/- .75
Caster in Degrees
FractionN/A
DecimalN/A
Toe-In in Inches
FractionN/A
DecimalN/A
Toe-In in Degrees
FractionN/A
DecimalN/A
Toe-Out in Turns
InnerN/A
OuterN/A
Steering Axis Inclination (SAI)N/A

WHEEL ALIGNMENT SPECIFICATIONS (MAXIMA WAGON)

ApplicationSpecification
Front (Scheme 1)
Camber in Degrees
Fraction1/2 +/- 1/2
Decimal.5 +/- .5
Caster in Degrees
Fraction1/2 +/- 1 5/16
Decimal.5 +/- 1.31
Toe-In in Inches
Fraction1/4 +/- 1/32
Decimal.25 +/- .03
Toe-In in Degrees
Fraction1/2 +/- 1/16
Decimal.5 +/- .06
Toe-Out on Turns
Inner20°
Outer18°
Steering Axis Inclination (SAI)9°

WHEEL ALIGNMENT SPECIFICATIONS (PICKUP - 2WD)

ApplicationSpecification
Front (Scheme 1)
Camber in Degrees
Fraction11/16 +/- 1/2
Decimal.68 +/- .5
Caster in Degrees
Fraction1/2 +/- 1 7/16
Decimal.5 +/- 1.43
Toe-In in Inches
Fraction3/32 +/- 1/32
Decimal.09 +/- .03
Toe-In in Degrees
Fraction3/16 +/- 1/16
Decimal.19 +/- .19
Toe-Out in Turns
Inner20°
Outer18°
Steering Axis Inclination (SAI)8°

WHEEL ALIGNMENT SPECIFICATIONS (PICKUP - 4WD)

ApplicationSpecification
Front
Camber in Degrees
Fraction7/13 +/- 1/2
Decimal.44 +/- .5
Caster in Degrees
Fraction11/62 +/- 1/2
Decimal.34 +/- .5
Toe-In in Inches
Fraction1/8 +/- 1/62
Decimal.13 +/- .03
Toe-In in Degrees
Fraction1/4 +/- 1/13
Decimal.25 +/- .13
Toe-Out in Turns
Inner22°
Outer20°
Steering Axis Inclination (SAI)7 15/16°

WHEEL ALIGNMENT SPECIFICATIONS (1986 1/2 PICKUP - 2WD)

ApplicationSpecification
Front
Camber in Degrees
Fraction5/8 +/- 1/2
Decimal.63 +/- .5
Caster in Degrees
Fraction1 11/62 +/- 1/2
Decimal1.34 +/- .5
Toe-In in Inches
Fraction5/34 +/- 1/62
Decimal.08 +/- .03
Toe-In in Degrees
Fraction5/62 +/- 1/13
Decimal.16 +/- .06
Toe-Out in Turns
Inner22°
Outer20°
Steering Axis Inclination (SAI)6 3/4°

WHEEL ALIGNMENT SPECIFICATIONS (1986 1/2 PICKUP - 4WD)

ApplicationSpecification
Front
Camber in Degrees
Fraction5/16 +/- 3/4
Decimal.313 +/- .75
Caster in Degrees
Fraction1 5/8 +/- 3/4
Decimal1.625 +/- .75
Toe-In in Inches
Fraction7/32 +/- 1/32
Decimal.22 +/- .03
Toe-In in Degrees
Fraction7/16 +/- 1/16
Decimal.44 +/- .06
Toe-Out in Turns
Inner20°
Outer17 1/2°
Steering Axis Inclination (SAI)12 3/4°
Rear
Camber in Degrees
FractionN/A
DecimalN/A
Caster in Degrees
FractionN/A
DecimalN/A
Toe-In in Inches
Fraction0 +/- 5/16
Decimal0.0 +/- .31
Toe-In in Degrees
Fraction0 +/- 5/8
Decimal0.0 +/- .63
Toe-Out in Turns
InnerN/A
OuterN/A
Steering Axis Inclination (SAI)N/A

WHEEL ALIGNMENT SPECIFICATIONS (PULSAR NX)

ApplicationSpecification
Front
Camber in Degrees
Fraction5/16 +/- 3/4
Decimal.31 +/- .75
Caster in Degrees
Fraction1 1/2 +/- 3/4
Decimal1.5 +/- .75
Toe-In in Inches
Fraction7/32 +/- 1/32
Decimal.22 +/- .03
Toe-In in Degrees
Fraction7/16 +/- 1/16
Decimal.44 +/- .06
Toe-Out in Turns
Inner20°
Outer17 1/2°
Steering Axis Inclination (SAI)12 3/4°
Rear
Camber in Degrees
Fraction1 +/- 3/4
Decimal1.0 +/- .75
Caster in Degrees
FractionN/A
DecimalN/A
Toe-In in Inches
Fraction0 +/- 5/16
Decimal0.0 +/- .31
Toe-In in Degrees
Fraction0 +/- 5/8
Decimal0.0 +/- .63
Toe-Out in Turns
InnerN/A
OuterN/A
Steering Axis Inclination (SAI)N/A

WHEEL ALIGNMENT SPECIFICATIONS (SENTRA)

ApplicationSpecification
Front
Camber in Degrees
Fraction5/16 +/- 3/4
Decimal.313 +/- .75
Caster in Degrees
Fraction1 7/16 +/- 3/4
Decimal1.43 +/- .75
Toe-In in Inches
Fraction1/16 +/- 1/32
Decimal.06 +/- .03
Toe-In in Degrees
Fraction1/8 +/- 1/16
Decimal.13 +/- .06
Toe-Out in Turns
Inner20°
Outer18 1/2°
Steering Axis Inclination (SAI)14 5/8°
Rear
Camber in Degrees
Fraction3/4 +/- 3/4
Decimal.75 +/- .75
Caster in Degrees
FractionN/A
DecimalN/A
Toe-In in Inches
FractionN/A
DecimalN/A
Toe-In in Degrees
FractionN/A
DecimalN/A
Toe-Out in Turns
InnerN/A
OuterN/A
Steering Axis Inclination (SAI)N/A

WHEEL ALIGNMENT SPECIFICATIONS (STANZA)

ApplicationSpecification
Front
Camber in Degrees
Fraction1/2 +/- 3/4
Decimal.5 +/- .75
Caster in Degrees
Fraction1 1/2 +/- 3/4
Decimal1.5 +/- .75
Toe-In in Inches
Fraction1/16 +/- 3/32
Decimal.06 +/- .09
Toe-In in Degrees
Fraction1/8 +/- 3/16
Decimal.13 +/- .19
Toe-Out in Turns
Inner21 1/2°
Outer20°
Steering Axis Inclination (SAI)11 1/4°

WHEEL ALIGNMENT SPECIFICATIONS (STANZA WAGON)

ApplicationSpecification
Front
Camber in Degrees
Fraction1/4 +/- 3/4
Decimal.25 +/- .75
Caster in Degrees
Fraction1 3/16 +/- 3/4
Decimal1.18 +/- .75
Toe-In in Inches
Fraction3/16 +/- 3/16
Decimal.19 +/- .19
Toe-In in Degrees
Fraction3/8 +/- 3/8
Decimal.13 +/- .13
Toe-Out in Turns
InnerN/A
OuterN/A
Steering Axis Inclination (SAI)N/A
Rear
Camber in Degrees
Fraction3/4 +/- 3/4
Decimal.75 +/- .75
Caster in Degrees
Fraction1 1/2 +/- 3/4
Decimal1.5 +/- .75
Toe-In in Inches
FractionN/A
DecimalN/A
Toe-In in Degrees
FractionN/A
DecimalN/A
Toe-Out in Turns
InnerN/A
OuterN/A
Steering Axis Inclination (SAI)N/A

WHEEL ALIGNMENT SPECIFICATIONS (STANZA WAGON - 4WD)

ApplicationSpecification
Front
Camber in Degrees
Fraction5/16 +/- 3/4
Decimal.31 +/- .75
Caster in Degrees
Fraction3 1/2 +/- 3/4
Decimal3.5 +/- .75
Toe-In in Inches
Fraction1/64 +/- 1/32
Decimal.02 +/- .03
Toe-In in Degrees
Fraction1/32 +/- 1/16
Decimal.03 +/- .06
Toe-Out in Turns
Inner20°
Outer18 3/4°
Steering Axis Inclination (SAI)11 15/16°
Rear
Camber in Degrees
Fraction1/2 +/- 3/4
Decimal.5 +/- .75
Caster in Degrees
FractionN/A
DecimalN/A
Toe-In in Inches
FractionN/A
DecimalN/A
Toe-In in Degrees
FractionN/A
DecimalN/A
Toe-Out in Turns
InnerN/A
OuterN/A
Steering Axis Inclination (SAI)N/A

WHEEL ALIGNMENT SPECIFICATIONS (200SX)

ApplicationSpecification
Front
Camber in Degrees
Fraction5/32 +/- 3/4
Decimal.15 +/- .75
Caster in Degrees
Fraction6 9/16 +/- 3/4
Decimal6.56 +/- .75
Toe-In in Inches
Fraction1/16 +/- 1/16
Decimal.06 +/- .06
Toe-In in Degrees
Fraction1/8 +/- 1/8
Decimal.13 +/- .13
Toe-Out in Turns
Inner22 1/2°
Outer20°
Steering Axis Inclination (SAI)13 11/32°
Rear (Scheme 2)
Camber in Degrees
Fraction1 5/32 +/- 3/4
Decimal1.16 +/- .75
Caster in Degrees
FractionN/A
DecimalN/A
Toe-In in Inches
FractionN/A
DecimalN/A
Toe-In in Degrees
FractionN/A
DecimalN/A
Toe-Out in Turns
InnerN/A
OuterN/A
Steering Axis Inclination (SAI)N/A
Rear
Camber in Degrees
Fraction1 +/- 3/4
Decimal1.0 +/- .75
Caster in Degrees
FractionN/A
DecimalN/A
Toe-In in Inches
FractionN/A
DecimalN/A
Toe-In in Degrees
FractionN/A
DecimalN/A
Toe-Out in Turns
InnerN/A
OuterN/A
Steering Axis Inclination (SAI)N/A

WHEEL ALIGNMENT SPECIFICATIONS (300ZX)
