DESCRIPTION

Starter is a conventional 12-volt, 4-pole brush-type motor, with direct or reduction gear drive. The starter-mounted solenoid shifts overrunning clutch and pinion into flywheel when starter is energized.

ModelType or Part No.
MaximaS114-430A
Pickup (1986 Gasoline)S114-348
Pickup (1986 Diesel)S13-45B
Pickup (1986 1/2 V6)S114-503
Pickup (1986 4 Cylinder)
Federal (2WD)S114-426
Federal (4WD)S114-446
California (2WD)S114-348
Calif (4WD)S114-304
Pulsar & Sentra (Gasoline)S114-316
Pulsar & Sentra (Diesel)S114-357A
Stanza & 200SXS114-320A/322A
300ZXS114-374B

HITACHI STARTER APPLICATION (MANUAL TRANSMISSION)

ModelType or Part No.
MaximaS114-430A
Pickup (1986 Gasoline)S114-295
Pickup (1986 Diesel)S13-45B
Pickup (1986 1/2 V6)S114-503
Pickup (4 Cylinder)
Federal (2WD)S114-427
Federal (4WD)S114-446
California (2WD)S114-295
California (4WD)S114-304
Pulsar & Sentra (Gasoline)S114-345A
Stanza & 200SXS114-320A/322A
300ZXS114-374B

HITACHI STARTER APPLICATION (AUTOMATIC TRANSMISSION)

No Load Tests

Connect starter in series with a 12-volt battery, a voltmeter and a 1000-amp ammeter. Compare readings with appropriate STARTER NO LOAD SPECIFICATIONS table.

ApplicationMax. AmpsMin. RPM
Maxima1003000
Pickup, Pulsar, & 200SX607000
Sentra (Manual Transmission)607000
Sentra (Automatic Transmission)602000
Stanza (Standard)607000
Stanza (Optional)1003900
300ZX1003900
(1) Applied voltage of 11.5-12 volts.
(1)Applied voltage of 11.5-12 volts.

STARTER NO LOAD SPECIFICATIONS (GASOLINE) (1)

ApplicationMax. AmpsMin. RPM
Pickup Diesel1503500
Sentra Diesel1003900
(1) Applied voltage of 11.5-12 volts.
(1)Applied voltage of 11.5-12 volts.

STARTER NO LOAD SPECIFICATIONS (DIESEL) (1)

Load (Lock Torque) Test

Mount starter in a test stand to perform torque measurement test. Follow manufacturer's instructions for test stand operation. With voltage adjusted, ammeter reading and torque should be within specification.

SOLENOID TESTS

Note. Make tests with solenoid removed from starter or remove solenoid lead to starter. Ensure solenoid plunger and sleeve are clean and dry. Make tests in less than 10 seconds to prevent coil damage.

Scheme 1

Scheme 1: Pull-In Coil Test
  1. Connect jumper between positive post of 12-volt battery and "S" terminal. Connect a second jumper to negative battery terminal and touch "M" (MT) terminal (and between terminal "S" and switch body). (Scheme 1) (Scheme 1): Connections for Conducting Solenoid Pull-In Test Remove solenoid-to-starter lead before testing.
  2. If pinion moves outward (or plunger is pulled-in), pull-in coil is good. If not, replace magnetic switch.

Scheme 2

Scheme 2: Hold-In Coil Test
  1. Connect a jumper wire between "M" (MT) terminal and solenoid case. Apply 8 volts to "S" terminal to pull in plunger. (Scheme 2) Disconnect lead to "M" (MT) terminal. (Scheme 2): Connections for Conducting Solenoid Hold-In Test Make tests in less than 10 seconds to avoid solenoid damage.
  2. If pinion remains out (plunger is pulled-in), hold-in coil is good. If not, replace magnetic switch.

Scheme 3

Scheme 3: Return Test
  1. Apply 12 volts between "M" (MT) terminal and solenoid case. Pull pinion out and release it (push plunger into solenoid body by hand). (Scheme 3) (Scheme 3): Connections for Conducting Return Test Connect battery to "M" terminal and solenoid case.
  2. If case is short-circuited, pinion will remain out (plunger will be attracted). If nothing happens, solenoid is good.

Removal & Installation (Pickup - 2WD)

Remove following parts to make room and take out starter from the cylinder head side area.

  1. RF wheel
  2. RF splash guard
  3. Exhaust manifold heat insulator
  4. Exhaust manifold
  5. Oil filter
  6. Oil purssure switch connector

Pickup - 4WD

Remove following parts to make room and take out starter through the clearance between body and frame.

  1. RF splash guard
  2. Oil purssure switch connector
  3. Oil filter
  4. Exhaust manifold heat insulator
  5. Fuel tube retainer bolt

Except Pickup

On all models except Pickup, remove negative battery cable. If necessary, raise vehicle on hoist. Remove starter mounting bolts. Remove starter from vehicle.

DISASSEMBLY

Note. Procedures may vary slightly between conventional and reduction gear starters.

  1. Loosen nut securing connecting plate to magnetic switch "M" terminal. Remove screws securing magnetic switch and remove switch (solenoid) assembly. Remove through bolts and brush cover assembly. Tap yoke assembly loose with wooden mallet. Remove yoke, armature assembly and pinion shift lever.
  2. Remove pinion stop ring from end of armature shaft by pushing stop ring to clutch side. Remove snap ring and overrunning clutch assembly from armature shaft.

CLEANING & INSPECTION

Clean all parts. Do not use grease dissolving solvent on overrunning clutch, armature assembly, solenoid assembly or field coils. Inspect all parts for damage or wear and replace as required.

Brushes & Springs

Check brush spring tension using a spring scale. Check brush contact surface condition and brush length. Check lead clip and wire connections and condition of brush holders. Replace as required. See BRUSH SPRING TENSION and MINIMUM BRUSH LENGTH tables.

ApplicationOzs. (g)
Maxima, Stanza, 300ZX & Sentra Diesel56-70 (1585-1981)

BRUSH SPRING TENSION

ApplicationIn. (mm)
Maxima.31 (8.0)
Pickup Diesel.28 (7.0)
Pickup Gasoline.47 (12.0)
Pulsar NX, Sentra, Stanza, 200SX & 300ZX.43 (11.0)

MINIMUM BRUSH LENGTH

Armature

Check external condition of armature for scoring or other damage. Measure shaft runout with dial indicator. Replace armature if shaft runout exceeds .003" (.08 mm) on Nissan.

Commutator

  1. Inspect commutator for roughness, grooves, burns or pitting. Sand lightly with 500-600 grit sandpaper if necessary. Check commutator for out-of-round and mica insulators undercut to a depth of .020-.031" (.50-.80 mm).
  2. If necessary, commutator may be turned less than .04" (1.0 mm) from original size and mica undercut. Replace if excessively worn.

Field Coil

  1. Check field coil continuity by connecting test probe of circuit tester or an ohmmeter to the field coil positive terminal and brush holder. If circuit is open, replace field coil.
  2. Check for grounding of field coils by placing one probe of circuit tester on starter housing and other probe to field coil positive terminal. If little or no resistance is present, field coil is grounded and must be replaced.

Overrunning Clutch Assembly

  1. Inspect pinion assembly and sleeve. Sleeve should slide freely on armature shaft and spline. If damage or resistance is noted, replace assembly.
  2. Check pinion and flywheel teeth for excessive rubbing or damaged teeth. Replace as required.

Pinion Gear Clearance

The clearance between pinion gear and pinion stopper collar should be.012-.098" (.3-2.5 mm) on Hitachi starters when solenoid is engaged. Adjust as necessary by changing shims between solenoid and starter yoke. (Scheme 5)

Disassembled View of a Typical Hitachi Conventional Starter For Nissan Pickups with Gasoline Engine. Scheme 4

Scheme 4: Disassembled View of a Typical Hitachi Conventional Starter For Nissan Pickups with Gasoline Engine

Pinion Case Bearing

Inspect bearing for wear and check side play. If clearance exceeds .008" (.20 mm), replace bearing. New bearing clearance should be .001-.004" (.025-.10 mm) for Hitachi starters.

Note. Ensure bearing is installed so it is flush with gear case end.

REASSEMBLY

To reassemble, reverse disassembly procedure. Fill rear case on reduction gear models with grease. Lightly oil pinion and all bearing surfaces.

Measuring Pinion Gear-to-Pinion Stopper Collar Clearance. Scheme 5

Scheme 5: Measuring Pinion Gear-to-Pinion Stopper Collar Clearance

Reduction Gear Starter for Maxima & 300ZX. Scheme 6

Scheme 6: Reduction Gear Starter for Maxima & 300ZX

Reduction Gear Starter for Sentra & Pulsar w/Auto. Trans. Scheme 7

Scheme 7: Reduction Gear Starter for Sentra & Pulsar w/Auto. Trans.
