FUSE PANEL LOCATION
The fuse box is located beneath the instrument panel to the left of the steering column. The fuse specifications are on a decal on the inside of the fuse box lid.
EXTENDED STORAGE SWITCH
This switch, located at the top of the fuse box, is used when the vehicle will be stored for an extended period of time. When the switch is turned to OFF position, the power to the clock, interior light, power antenna timer, and time control unit is cut off. When checking the power supply circuit for each system, make sure the extended storage switch is in the ON position.
Scheme 2
- 1 - 20 Amp Door Lock Timer, Keyless Entry Relay
- 2 - 10 Amp Hazard Warning Light
- 3 - 10 Amp Extended Storage Switch, Interior Lights, Clock, Power Antenna, Time Control Unit, Steering Lock Switch
- 4 - 10 Amp Exterior Lights, Illumination
- 5 - 15 Amp Rear Wiper & Washer Motors
- 6 - 15 Amp Wiper & Washer Motors, Wiper Relay, Time Control Unit, Rain Sensor
- 7 - 10 Amp Clock, Radio, Deck, Panel Speaker Amplifier, Power Antenna Timer
- 8 - 20 Amp Condenser Fan Motor
- 9 - 10 Amp Fuel Pump, Air Regulator, EFI Relay
- 10 - 10 Amp ASCD Inhibitor Relay, Bulb Check Relay, Idle-Up Solenoid, Power Steering Pump Switch
- 11 - 10 Amp Stoplight, Headlight Warning Light, Horn
- 12 - 15 Amp Left Headlight
- 13 - 15 Amp Right Headlight
- 14 - 20 Amp Rear Defogger
- 15 - 20 Amp Rear Defogger
- 16 - 15 Amp Blower Motor
- 17 - 15 Amp Blower Motor
- 18 - 15 Amp Door Mirror, Cigarette Lighter, A/C Compressor Magnetic Clutch
- 19 - 10 Amp Gauge, Warning Light, Chime, Time Control Unit, Voice Warning Unit, Back-Up Light, Rear Defogger Relay, Interrupt Relay, Power Antenna Timer
- 20 - 10 Amp ASCD, Turn Signal, Exhaust Gas Sensor Warning Amp, Lock-Up Solenoid, Kickdown Solenoid, OD Cancel Solenoid
