Maintenance Information Mitsubishi Starion I

VIN LOCATION

The Vehicle Identification Number (VIN) is located on the left side of the dash panel at the base of the windshield. The VIN chart explains the code characters.

VIN CODE ID EXPLANATION

Numbers preceding the explanations in the legend below refer to the sequence of characters as listed on VIN identification label. See VIN example below.

VIN Code ID Explanation. Scheme 2

SEVERE & NORMAL SERVICE DEFINITIONS

Note. Use the Severe Service schedule if the vehicle to be serviced is operated under ANY (one or more) of these conditions

Service is recommended at mileage intervals based on vehicle operation. Service schedules are based on the following primary operating conditions

Normal Service

1. Driven More Than 10 Miles Daily
2. No Operating Conditions From Severe Service Schedule

Severe Service (Unique Driving Conditions)

1. Driving In Dusty Conditions
2. Police, Taxi Or Commercial Operation
3. Extensive Idling
4. Short-Trip Operation At Freezing Temperatures
5. Driving In Sandy Conditions
6. Driving In Salty Areas
7. More Than 50% Operation In Heavy Traffic During Hot Weather
8. Driving Off-Road

Scheme 3

Scheme 4

WHEEL TIGHTENING

Tighten wheel lug nuts to 50-57 ft. lbs. (67-77 N.m) for steel wheels and to 65-80 ft. lbs. (88-108 N.m) for aluminum wheels.

BATTERY SPECIFICATIONS

If battery is replaced, new battery should be of the same group number as shown on the original battery's label.

All engines use batteries with B.C.I. group number 24.

TRANSMISSION FLUID

Make certain that no fluid is spilled when the transmission fluid is inspected or is added soon after driving. If it spills onto the exhaust manifold, there is a danger of fire.

CARGO LOADING

When determining vehicle passenger and/or cargo load, DO NOT use the Gross Vehicle Weight Rating data on the safety certification label. Use the weight values on the tire pressure label.

RADIATOR CAP

Before removing radiator cap, make sure that the engine is thoroughly cooled down. Otherwise hot steam or boiling water could gush from the filler port and cause injury.

WARRANTY INFORMATION

BASIC COVERAGE

Covers all parts and components for any repairs or adjustments needed to correct defects in materials or workmanship for 36 months or 36,000 miles, whichever comes first, from date of delivery to the first retail buyer.

POWERTRAIN COVERAGE

Upon expiration of Basic Coverage, this warranty covers the following powertrain components for repairs needed to correct defects in materials or workmanship up to a maximum of 36 months or 50,000 miles from original in-service date, whichever comes first

1. Engine Cylinder block, all internal parts, cylinder head assemblies and gaskets, engine mounts, valve cover, belts & gears, turbocharger, oil pan, oil pump, intake manifold, water pump, timing gears, timing belts, timing chain and related parts, fuel pump, diesel injection pump external seals and flywheel.
2. Transmission Case and all internal parts, torque converter including ring gear, transfer case and all internal parts, transmission mounts, seals and gaskets.
3. Front Wheel Drive Vehicles Transaxle case and all internal parts, gaskets and seals, torque converter and drive plate (including ring gear), axle shaft assemblies, CV joints, final drive housing and all internal parts, front hub bearings.
4. Rear Wheel Drive Vehicles Drive shaft assembly (front and rear), universal joints, axle housing and all internal parts, gaskets and seals, axle shafts, bearings and supports.

BATTERY COVERAGE

Covers replacement of original battery for 12 months or 12,000 miles, whichever occurs first, and after 12 months or 12,000 miles, covers a pro-rated amount based on months and mileage in service up to a maximum of 36 months or 36,000 miles, whichever occurs first.

AIR CONDITIONERS

Covers manufacturer's air conditioners for 36 months or 36,000 miles, whichever occurs first, and covers air conditioner refrigerant charge for the first 12 months or 12,000 miles, whichever occurs first.

ANTI-CORROSION PERFORATION LIMITED WARRANTY

Covers any body sheet metal panel found to have developed perforation (rust-through) due to corrosion in normal use for 36 months from date of delivery or first use, whichever occurs first, regardless of mileage. Outer panel rust-through coverage extends to 5 years with unlimited mileage from warranty start date.

EMISSION CONTROL SYSTEM DEFECT WARRANTY

Warrants that the vehicle was designed, built and equipped to conform at the time of sale with all applicable U.S. emission standards. Covers any repairs needed to correct defects in materials or workmanship of genuine Mitsubishi parts which would cause the vehicle not to meet these standards for 5 years or 50,000 miles from date of original retail delivery or first use, whichever occurs first.

EMISSION CONTROL SYSTEMS PERFORMANCE WARRANTY

Covers all repairs, adjustments, or replacements if vehicle has been maintained in accordance with the prescribed scheduled maintenance instructions, fails to conform to applicable emission standards and such failure results or will result in the vehicle owner having to bear any penalty or other sanctions under local, state or federal law for 5 years or 50,000 miles, whichever comes first. Covers remedy of non-conformity which causes vehicle to fail EPA approved emissions test during the first 24 months or 24,000 miles of this warranty. After the first 24 months or 24,000 miles, the warranty covers remedy of non-conformity resulting from failure of any of the following components

1. Carburetor Feedback Control System
2. Electronic Control Injection System
3. Electric Choke System
4. Dual Diaphragm Vacuum Advance Unit
5. Electronic Spark Controller
6. Timing Advance/Retard System
7. Vapor Storage Canister And Controls
8. PCV Valve
9. EGR Valve And Controls
10. Air Injection Controls
11. Catalytic Converters
12. Fuel Filler Neck And Fuel Tank Cap
13. Cold Mixture Heater
14. Hoses, Clamps, Fittings And Tubing Used In Above Systems
15. Vacuum, Temperature, Altitude, Time And Speed Sensitive Valves And Switches Used In Above Systems

FUSES & CIRCUIT BREAKERS

The fuse box is located beneath the instrument cluster to the left of the steering column.

Scheme 5

Fuse & Circuit Breaker Identification

1. 1 - 10 Amp Dome Light, Luggage Compartment Light, Clock, VELNAS (1984-85), Radio, Door Light, Electronic Time & Alarm Control System (ETACS) (1985-89), Light Monitor Buzzer (1987), Automatic Seat Belt, Clock (1987-89), Theft Alarm (1988-89)
2. 2 - 15 Amp Stoplights, Cruise Control Unit (1987-89)
3. 3 - 15 Amp Hazard Warning Flasher
4. 4 - 10 Amp Pop-Up Motor
5. 5 - 15 Amp (1984) Power Antenna, Center Door Lock (1984) 20 Amp (1985-89) Heater (1985-86), Blower Motor (1987-89)
6. 6 - Blank (1983-84) 15 Amp (1985-89) Position Lights, Illumination Lights, Taillights, ETACS (1985), License Light (1987-89)
7. 7 - 15 Amp 1983-84 Position & Illumination Lights Blank (1985) 10 Amp (1986-89) Magnetic Clutch, Rear Intermittent Wiper Relay (1987)
8. 8 - 20 Amp (1983-84) Heater 15 Amp (1985-89) Power Antenna, Central Door Lock, Door Light, Theft Alarm, Horn Relay (1987), Alarm Buzzer (1987-89), Power Window Relay (1988-89)
9. 9 - 15 Amp Horn, Cigarette Lighter, Headlight Relay (1988-89)
10. 10 - 15 Amp Wiper & Washer Motors, ETACS (1985-89), Rear Intermittent Wiper Relay (1988-89)
11. 11 - 10 Amp Radio, Clock, Power Antenna (1985-89), Rear Brake Lock-Up Control Relay (1987-89)
12. 12 - 10 Amp Gauges (1983-84), Remote Control Mirror (1984), Heater Relay (1985-86), Defogger Relay (1985-89), Blower Relay, Air Conditioner (1987-89)
13. 13 - 10 Amp Turn Signal Light, Gauges, Remote Control Mirror, Power Antenna (1985-89), ETACS (1986-89), Automatic Seat Belt (1987-89)
14. 14 - 10 Amp Alternator, Back-Up Light, Overdrive Relay (1985-89), Cruise Control Switch (1987-89)
