DATA LIST REFERENCE TABLE Mitsubishi Outlander II facelift

Continuously Variable Transaxle (Cvt) Diagnosis & On-Vehicle Service 2 illustrations

DATA LIST REFERENCE TABLE

Item No.	Display on scan tool	Check conditions		Normal conditions
1	Primary speed sensor signal	Driving conditions		Nearly the same as the tachometer display
2	Secondary speed sensor signal	Driving conditions		Nearly the same as the speedometer display
3	Primary pressure sensor signal	Always		0 V
4	Secondary pressure sensor signal	Engine: Idling Transmission range: N		0.5 - 3.0 V
5	Transmission fluid temperature sensor signal	Ignition switch: ON	Transmission fluid temperature: Approximately 20°C (68°F)	1.9 - 2.2 V
5	Transmission fluid temperature sensor signal	Ignition switch: ON	Transmission fluid temperature: Approximately 80°C (176°F)	0.8 - 1.1 V
6	Power supply voltage	Ignition switch: ON		Battery positive voltage
7	Primary speed	Driving conditions		Nearly the same as the tachometer display
8	Secondary speed	Driving conditions		Approximately (Speedometer display) x 45
9	Engine revolution	Engine: Idling		Nearly the same as the tachometer display
11	Real variable speed ratio	Driving conditions		2.34 - 0.39
13	Accelerator position	Accelerator pedal: Fully closed		0%
		Accelerator pedal: Depressed		Opening angle value increases in response to the depression amount of the accelerator pedal.
		Accelerator pedal: Fully opened		100%
18	Primary pressure	Always		0 MPa
19	Secondary pressure	Engine: Idling Transmission range: N		0.1 - 3.0 MPa (14.5 - 435 psi)
20	Transmission fluid temperature (1)	Ignition switch: ON	Transmission fluid temperature: Approximately 20°C (68°F)	39 - 55 count
20	Transmission fluid temperature (1)	Ignition switch: ON	Transmission fluid temperature: Approximately 80°C (176°F)	152 - 170 count
21	Vehicle speed (inference)	Driving conditions		Nearly the same as the speedometer display
22	Real vehicle speed	Driving conditions		Nearly the same as the speedometer display
26	Real step	Driving conditions		20 to 190 step
30	LU solenoid monitor current	From lockup release to engage		0 - 0.7 A
31	LU solenoid output current	From lockup release to engage		0 - 0.7 A
32	Line pressure SOL. monitor current	Engine: Idling Transmission range: N		0.45 - 0.75 A
32	Line pressure SOL. monitor current	Engine: Stalled		0.08 - 0.3 A
33	Line pressure SOL. output current	From low line pressure to high line pressure		0 - 0.8 A
34	Secondary PRS. SOL. monitor current	Engine: Idling Transmission range: N		0.45 - 0.75 A
34	Secondary PRS. SOL. monitor current	Engine: Stalled		0.08 - 0.3 A
35	Secondary PRS. SOL. monitor output current	From low secondary pressure to high secondary pressure		0 - 0.8 A
36	LU/SEL changeover SOL. output	Ignition switch: ON	Transmission range: P, N	ON
36	LU/SEL changeover SOL. output	Ignition switch: ON	Transmission range: 5 or more seconds have passed after the selector lever has been moved to R or D position.	OFF
37	LU/SEL changeover SOL. monitor	Ignition switch: ON	Transmission range: P, N	ON
37	LU/SEL changeover SOL. monitor	Ignition switch: ON	Transmission range: 5 or more seconds have passed after the selector lever has been moved to R or D position.	OFF
38	Stepper motor coil A	Driving conditions		ON/OFF switches alternately.
39	Stepper motor coil B	Driving conditions		ON/OFF switches alternately.
40	Stepper motor coil C	Driving conditions		ON/OFF switches alternately.
41	Stepper motor coil D	Driving conditions		ON/OFF switches alternately.
42	Indicator P output	Ignition switch: ON Engine: Stopped	Transmission range: P	ON
42	Indicator P output	Ignition switch: ON Engine: Stopped	Transmission range: Other than the above	OFF
43	Indicator R output	Ignition switch: ON Engine: Stopped	Transmission range: R	ON
43	Indicator R output	Ignition switch: ON Engine: Stopped	Transmission range: Other than the above	OFF
44	Indicator N output	Ignition switch: ON Engine: Stopped	Transmission range: N	ON
44	Indicator N output	Ignition switch: ON Engine: Stopped	Transmission range: Other than the above	OFF
45	Indicator D output	Ignition switch: ON Engine: Stopped	Transmission range: D	ON
45	Indicator D output	Ignition switch: ON Engine: Stopped	Transmission range: Other than the above	OFF
47	Indicator SP mode output	Ignition switch: ON Engine: Stopped	Transmission range: Sport mode	ON
47	Indicator SP mode output	Ignition switch: ON Engine: Stopped	Transmission range: Other than the above	OFF
48	Idle switch signal	Ignition switch: ON Engine: Stopped	Accelerator pedal: Fully closed	ON
48	Idle switch signal	Ignition switch: ON Engine: Stopped	Accelerator pedal: Fully opened	OFF
49	Transmission range switch	Ignition switch: ON Engine: Stopped	Transmission range: P	P, N
			Transmission range: R	R
			Transmission range: N	P, N
			Transmission range: D	D
50	Brake switch	Ignition switch: ON Engine: Stopped	Brake pedal: Depressed	ON
50	Brake switch	Ignition switch: ON Engine: Stopped	Brake pedal: Released	OFF
51	SP mode switch	Ignition switch: ON Engine: Stopped	Transmission range: Sport mode	ON
51	SP mode switch	Ignition switch: ON Engine: Stopped	Transmission range: Other than sport mode	OFF
52	Select switch (up)	Ignition switch: ON Engine: Stopped	Transmission range: Upshift and hold	ON
52	Select switch (up)	Ignition switch: ON Engine: Stopped	Transmission range: Other than the above	OFF
53	Select switch (down)	Ignition switch: ON Engine: Stopped	Transmission range: Downshift and hold	ON
53	Select switch (down)	Ignition switch: ON Engine: Stopped	Transmission range: Other than the above	OFF
54	Paddle switch (up)	Ignition switch: ON Engine: Stopped	Paddle shift lever position: Upshift and hold	ON
54	Paddle switch (up)	Ignition switch: ON Engine: Stopped	Paddle shift lever position: Other than the above	OFF
55	Paddle switch (down)	Ignition switch: ON Engine: Stopped	Paddle shift lever position: Downshift and hold	ON
55	Paddle switch (down)	Ignition switch: ON Engine: Stopped	Paddle shift lever position: Other than the above	OFF
56	ABS actuation signal	ABS operated		ON
56	ABS actuation signal	ABS not operated		OFF
59	Shift position	Ignition switch: ON Engine: Stopped	Transmission range: P	P, N
			Transmission range: R	R
			Transmission range: N	P, N
			Transmission range: D	D
60	Gear position (SP mode)	Transmission range: Sport mode	Idling	1st
			Drive at a constant speed of 30 km/h (19 mph) in 2nd gear.	2nd
			Drive at a constant speed of 35 km/h (22 mph) in 3rd gear.	3rd
			Drive at a constant speed of 40 km/h (25 mph) in 4th gear.	4th
			Drive at a constant speed of 50 km/h (31 mph) in 5th gear.	5th
			Drive at a constant speed of 60 km/h (37 mph) in 6th gear.	6th
(1) Relation between fluid temperature and COUNT is shown to the characteristics chart.

(1)	Relation between fluid temperature and COUNT is shown to the characteristics chart.

DATA LIST REFERENCE CHART

Scheme 68

Scheme 68

Scheme 68

Scheme 69

Scheme 69: TCM TERMINAL VOLTAGE REFERENCE CHART FOR TRANSAXLE OPERATION

Scheme 69: TCM TERMINAL VOLTAGE REFERENCE CHART FOR TRANSAXLE OPERATION

Terminal No.	Check item	Check condition		Standard value
1	Line pressure solenoid valve	Ignition switch: ON Engine: Stopped Transmission range: P	Accelerator pedal: Fully closed	Approximately 5.0 - 7.0 V
1	Line pressure solenoid valve	Ignition switch: ON Engine: Stopped Transmission range: P	Accelerator pedal: Fully opened	Approximately 1.0 V
2	Secondary pressure solenoid valve	Ignition switch: ON Engine: Stopped Transmission range: P	Accelerator pedal: Fully closed	Approximately 5.0 - 7.0 V
2	Secondary pressure solenoid valve	Ignition switch: ON Engine: Stopped Transmission range: P	Accelerator pedal: Fully opened	Approximately 3.0 - 4.0 V
3	Lockup solenoid valve	Driving conditions	Lockup released	Approximately 6.0 V
3	Lockup solenoid valve	Driving conditions	Lockup engaged	Approximately 1.5 V
4	CAN_H
5	CAN_L
12	Power supply	Ignition switch: ON		Battery positive voltage
12	Power supply	Ignition switch: OFF		1 V or less
13	Ground	Always		1 V or less
14	Lockup/select switching solenoid valve	Ignition switch: ON Engine: Stopped	Transmission range: N, P	Battery positive voltage
14	Lockup/select switching solenoid valve	Ignition switch: ON Engine: Stopped	Transmission range: 5 or more seconds have passed after the selector lever has been moved to R or D position.	1 V or less
17	ROM assembly (SEL2)
18	ROM assembly (SEL1)
19	ROM assembly (SEL3)
21	Paddle shift switch (down)	Ignition switch: ON	Paddle shift lever position: Downshift and hold	1 V or less
21	Paddle shift switch (down)	Ignition switch: ON	Paddle shift lever position: Other than the above	Battery positive voltage
22	Paddle shift switch (up)	Ignition switch: ON	Paddle shift lever position: Upshift and hold	1 V or less
22	Paddle shift switch (up)	Ignition switch: ON	Paddle shift lever position: Other than the above	Battery positive voltage
25	Power supply	Ignition switch: ON		Battery positive voltage
25	Power supply	Ignition switch: OFF		1 V or less
26	Ground	Always		1 V or less
31	Back-up power supply	Always		Battery positive voltage
32	Transmission range switch P	Ignition switch: ON Transmission range: P		Battery positive voltage
32	Transmission range switch P	Ignition switch: ON Transmission range: Other than P		1 V or less
33	Transmission range switch R	Ignition switch: ON Transmission range: R		Battery positive voltage
33	Transmission range switch R	Ignition switch: ON Transmission range: other than R		1 V or less
34	Transmission range switch N	Ignition switch: ON Transmission range: N		Battery positive voltage
34	Transmission range switch N	Ignition switch: ON Transmission range: Other than N		1 V or less
35	Select switch	Ignition switch: ON	Transmission range: Sport mode	1 V or less
35	Select switch	Ignition switch: ON	Transmission range: Other than the above	Battery positive voltage
36	Secondary pulley rotation sensor	Transmission range: D Drive at a constant speed of Approximately 20 km/h (12 mph) Use an oscilloscope to measure the voltage between the terminals No. 36 and No. 26.		Oscilloscope inspection procedure (Refer to OSCILLOSCOPE INSPECTION PROCEDURES .)
37	Primary rotation sensor	Transmission range: D Drive at a constant speed of Approximately 20 km/h (12 mph) Use an oscilloscope to measure the voltage between the terminals No. 37 and No. 26.		Oscilloscope inspection procedure (Refer to OSCILLOSCOPE INSPECTION PROCEDURES .)
39	Secondary pressure sensor	Engine: Idling Transmission range: N		Approximately 1.0 V
40	Stepper motor A	Within 2 seconds after the ignition switch is turned to the ON position		Pulse width: 30 ms
41	Stepper motor B	Within 2 seconds after the ignition switch is turned to the ON position		Pulse width: 10 ms
43	Upshift switch	Transmission range: Sport mode	Transmission range: Upshift and hold	1 V or less
43	Upshift switch	Transmission range: Sport mode	Transmission range: Other than the above	Battery positive voltage
44	Downshift switch	Transmission range: Sport mode	Transmission range: Downshift and hold	1 V or less
44	Downshift switch	Transmission range: Sport mode	Transmission range: Other than the above	Battery positive voltage
45	Transmission range switch D	Ignition switch: ON Transmission range: D		Battery positive voltage
45	Transmission range switch D	Ignition switch: ON Transmission range: other than D		1 V or less
48	Sensor ground	Always		1 V or less
49	Sensor power supply	Ignition switch: ON		5.0 V
50	Transmission fluid temperature sensor	Ignition switch: ON Transmission fluid temperature: 20°C (68°F)		Approximately 2.0 V
50	Transmission fluid temperature sensor	Ignition switch: ON Transmission fluid temperature: 80°C (176°F)		Approximately 1.0 V
51	Stepper motor C	Within 2 seconds after the ignition switch is turned to the ON position		Pulse width: 30 ms
52	Stepper motor D	Within 2 seconds after the ignition switch is turned to the ON position		Pulse width: 10 ms

TCM TERMINALS VOLTAGE REFERENCE CHART
