FASTENER TIGHTENING SPECIFICATIONS
| ITEMS | SPECIFICATIONS |
|---|---|
| Cooling fan | |
| Cooling fan bolt | 11 ± 1 N.m (93 ± 13 in-lb) |
| Fan clutch nut | 11 ± 1 N.m (93 ± 13 in-lb) |
| Radiator | |
| Radiator support bolt | 12 ± 2 N.m (101 ± 23 in-lb) |
| Shroud bolt | 5.0 ± 1.0 N.m (44 ± 9 in-lb) |
| Thermostat | |
| Water inlet fitting bolt | 12 ± 1 N.m (102 ± 13 in-lb) |
| Water pump | |
| Water pump bolt | 24 ± 3 N.m(18 ± 2 ft-lb) |
| Fitting and Water pump bolt | 12 ± 1 N.m (102 ± 13 in-lb) |
| Thermostat case and Fitting bolt | 9.0 ± 1.0 N.m (80 ± 9 in-lb) |
| Water outlet fitting and Thermostat case bolt | 12 ± 1 N.m (102 ± 13 in-lb) |
| Water outlet fitting and Bracket bolt | 14 ± 1 N.m (120 ± 13 in-lb) |
| Water hose and water pipe | |
| Fitting bolt | 12 ± 1 N.m (102 ± 13 in-lb) |
| Water pipe assembly bolt | 14 ± 1 N.m (120 ± 13 in-lb) |
| Water outlet pipe assembly bolt | 14 ± 1 N.m (120 ± 13 in-lb) |
| Water passage assembly bolt | 19 ± 1 N.m (14 ± 1 ft-lb) |
| Water outlet fitting and Thermostat case and Fitting bolt | 9.0 ± 1.0 N.m (80 ± 9 in-lb) |
