Removal & Installation
Remove door trim panel and waterproof shield. Remove glass retaining screws and glass. (Scheme 6) Remove motor and slider assembly retaining bolts. Remove motor and slider assembly from door. To install, reverse removal procedure.
Scheme 6
Scheme 6: Removal & Installation
Power Window System Wiring Diagram (Mirage - 2-Door). Scheme 7
Scheme 7: Power Window System Wiring Diagram (Mirage - 2-Door)
Power Window System Wiring Diagram (Mirage - 4-Door). Scheme 8
Scheme 8: Power Window System Wiring Diagram (Mirage - 4-Door)
Power Window System Wiring Diagram (Montero). Scheme 9
Scheme 9: Power Window System Wiring Diagram (Montero)
Power Window System Wiring Diagram (Montero Sport). Scheme 10
Scheme 10: Power Window System Wiring Diagram (Montero Sport)
Power Window System Wiring Diagram (3000GT). Scheme 11
Scheme 11: Power Window System Wiring Diagram (3000GT)
