Freeze Frame Data
The conditions at the time a malfunction is detected will be stored in ECM/PCM as freeze frame data. While multiple DTCs may be recorded, only one freeze frame is recorded. DTCs are assigned a priority with fuel and misfire codes having the highest priority. No-emissions related DTCs have the lowest priority. The DTC with the highest priority will be the one recorded in freeze frame. Freeze frame records are cleared when DTCs are erased. Freeze frame data recorded is
- Engine Coolant Temperature
- Engine RPM
- Vehicle Speed
- Long Term Fuel Trim (Displayed As Percent)
- Short Term Fuel Trim (Displayed As Percent)
- Fuel Control Condition (Open Or Closed Loop)
- Load Value (Displayed As Percent)
- DTC During Data Recording
OBD-II Drive Cycles
Drive cycle is a pattern of driving that meets code set criteria for ECM/PCM to monitor a particular system/component. Drive cycle is used to verify repair by reproducing conditions during which fault occurred. There are 6 different drive cycles. These are Catalytic Converter Monitor, EVAP System Leak Monitor, Heated Oxygen Sensor (HO2S) Monitor, EGR Monitor, Fuel Trim Monitor and Other Monitor. To run drive cycle, see appropriate drive cycle in OBD-II DRIVE CYCLES under VERIFYING REPAIRS.
Failure Management
When main sensor malfunctions are detected, ECM/PCM will enter fail-safe mode. Default values will be substituted in ECM/PCM calculations for faulty sensor.
SERVICE PRECAUTIONS
Before proceeding with diagnosis, following precautions must be observed
- Ensure vehicle has a fully charged battery and functional charging system. Codes cannot be retrieved if battery voltage is too low.
- Visually inspect connectors and circuit wiring being worked on.
- DO NOT disconnect battery or ECM/PCM. This will erase any DTCs stored in ECM/PCM.
- DO NOT cause short circuits when performing electrical tests. This will set additional DTCs, making diagnosis of original problem more difficult.
- DO NOT use a test light in place of a voltmeter. Use voltmeter with 10-megohm impedance.
- When checking for spark, ensure coil wire is NOT more than 1/4" from chassis ground. If coil wire is more than 1/4" from chassis ground, damage to vehicle electronics and/or ECM/PCM may result.
- DO NOT prolong testing of fuel injectors. Engine may hydrostatically (liquid) lock.
Using MIL (Eclipse 2.0L Non-Turbo)
Before entering on-board diagnostics, see SERVICE PRECAUTIONS . Malfunction Indicator Light (MIL) (Service Engine Soon light) is located on instrument cluster, to left of tachometer.
Turn ignition on, off, on, off and on within 5 seconds. Record 2-digit DTCs as displayed by flashing MIL. There will be a slight pause between flashes, representing first and second digits of DTC. Longer pauses separate individual DTCs.
DTCS - ECLIPSE 2.0L NON-TURBO
Note. Listed DTCs are retrieved using scan tool or Malfunction Indicator Light (MIL) (Service Engine Soon light) on instrument cluster. See ENTERING ON-BOARD DIAGNOSTICS .
| Generic Scan Tool DTC | MIL DTC | Description |
|---|---|---|
| P0106 | 61 | Barometric Pressure Out Of Range |
| P0107 | 14 | MAP Sensor Voltage Too Low |
| P0108 | 14 | MAP Sensor Voltage Too High |
| P0112 | 23 | IAT Sensor Voltage Low |
| P0113 | 23 | IAT Sensor Voltage High |
| P0117 | 22 | ECT Sensor Voltage Too Low |
| P0118 | 22 | ECT Sensor Voltage Too High |
| P0121 | 24 | TPS Voltage Does Not Agree With MAP |
| P0122 | 24 | TPS Voltage Low |
| P0123 | 24 | TPS Voltage High |
| P0125 | 17 | Closed Loop Temperature Not Reached |
| P0131 | 21 | Upstream HO2S Voltage Grounded |
| P0132 | 21 | Upstream HO2S Shorted To Voltage |
| P0133 | 21 | Upstream HO2S Response |
| P0133 | 21 | Slow Upstream HO2S Circuit During Catalyst Monitor |
| P0134 | 21 | Upstream HO2S Stays At Center |
| P0135 | 21 | Upstream HO2S Heater Failure |
| P0137 | 21 | Downstream HO2S Voltage Grounded |
| P0138 | 21 | Downstream HO2S Shorted To Voltage |
| P0140 | 21 | Downstream HO2S Stays At Center |
| P0141 | 21 | Downstream HO2S Heater Failure |
| P0171 (1) | 51 | Fuel System Lean |
| P0172 (1) | 52 | Fuel System Rich |
| P0201 | 27 | Injector No. 1 Control Circuit |
| P0202 | 27 | Injector No. 2 Control Circuit |
| P0203 | 27 | Injector No. 3 Control Circuit |
| P0204 | 27 | Injector No. 4 Control Circuit |
| P0220 | 42 | Fuel Pump Relay Control Circuit |
| P0300 (1) (2) | 43 | Multiple Cylinder Misfire |
| P0301 (1) (2) | 43 | Cylinder No. 1 Misfire |
| P0302 (1) (2) | 43 | Cylinder No. 2 Misfire |
| P0303 (1) (2) | 43 | Cylinder No. 3 Misfire |
| P0304 (1) (2) | 43 | Cylinder No. 4 Misfire |
| P0325 | 16 | Knock Sensor No. 1 Circuit |
| P0335 | 11 | No Crankshaft Reference Signal At PCM |
| P0340 | 54 | No Cam Signal At PCM |
| P0351 | 43 | Ignition Coil No. 1 Primary Circuit |
| P0352 | 43 | Ignition Coil No. 2 Primary Circuit |
| P0401 | 32 | EGR System Failure |
| P0403 | 32 | EGR Solenoid Circuit |
| P0422 | 64 | Catalytic Converter Efficiency Failure |
| P0441 | 31 | EVAP Purge Flow Monitor Failure |
| P0442 | 31 | EVAP System Small Leak Detected |
| P0443 | 31 | EVAP Solenoid Circuit |
| P0455 | 31 | EVAP System Large Leak Detected |
| P0500 | 15 | No VSS Signal |
| P0505 | 25 | IAC Motor Circuits |
| P0551 | 65 | Power Steering Pressure Switch Failure |
| P0600 | 53 | PCM Failure - SPI Communications |
| P0601 | 53 | Internal Controller Failure |
| P0700 | 45 | EATX Controller DTC Present |
| P0703 | 152 | Stoplight Switch Circuit |
| P1294 | 25 | Target Idle Not Reached |
| P1295 | 24 | No Reference Voltage To TPS |
| P1296 | 14 | No Reference Voltage To MAP |
| P1297 | 13 | No Change In MAP From Start To Run |
| P1390 | 11 | Timing Belt Skipped One Tooth Or More |
| P1391 | 11 | Intermittent Loss Of CMP Or CKP |
| P1398 | 11 | Misfire Adaptive Numerator At Limit |
| P1486 | 31 | EVAP System Blockage Detected |
| P1487 | 35 | High Speed Radiator Fan Control Relay Circuit |
| P1489 | 35 | High Speed Condenser Fan Control Relay Circuit |
| P1490 | 35 | Low Speed Fan Control Relay Circuit |
| P1492 | 44 | Battery Temperature Sensor Voltage High |
| P1493 | 44 | Battery Temperature Sensor Voltage Low |
| P1494 | 31 | LDP Switch/Mechanical Fault |
| P1495 | 31 | LDP Solenoid Electrical Malfunction |
| P1496 | 14 | 5 Volt Supply Output Low |
| P1696 | 63 | PCM Failure - EEPROM Write Denied |
| P1697 | 62 | PCM Failure - SRI Mile Not Stored |
| P1698 | 66 | No CCD Messages From TCM (A/T) |
| P1899 | 37 | Park/Neutral Switch (Transaxle Range Switch) Failure (A/T) |
| 17 | Engine Cold Too Long | |
| 33 | A/C Clutch Relay Circuit | |
| 41 | Generator Field Not Switching Properly | |
| 42 | Fuel Level Sending Unit Circuit Malfunction | |
| 42 | No MFI Relay Output Voltage At PCM | |
| 42 | MFI Relay Control Circuit Failure | |
| 44 | Battery Temperature Volts Out Of Limit | |
| 46 | Charging System Voltage High | |
| 47 | Charging System Voltage Low | |
| (1) MIL will illuminate on first detection of the malfunction. For all other malfunctions, MIL will illuminate when engine is next turned on and malfunction is again detected. (2) If misfire is severe enough to cause catalytic converter damage, MIL will continuously flash as long as danger is present. | ||
| (1) | MIL will illuminate on first detection of the malfunction. For all other malfunctions, MIL will illuminate when engine is next turned on and malfunction is again detected. |
| (2) | If misfire is severe enough to cause catalytic converter damage, MIL will continuously flash as long as danger is present. |
DTC INDEX - ECLIPSE 2.0L NON-TURBO
DTCS - ALL OTHER MODELS
Note. DTCs can only be retrieved by using a scan tool. See ENTERING ON-BOARD DIAGNOSTICS .
| Generic Scan Tool DTC | Description |
|---|---|
| No Code | ECM Malfunction |
| P0100 | Volume Airflow Circuit Malfunction |
| P0105 | BARO Circuit Malfunction |
| P0105 | (1) MAP Circuit Malfunction |
| P0110 | IAT Circuit Malfunction |
| P0115 | ECT Circuit Malfunction |
| P0120 | TPS Circuit Malfunction |
| P0125 (2) | Excessive Time To Enter Closed Loop Fuel Control |
| P0130 | O2 Sensor Circuit Malfunction (Bank 1 Sensor 1) |
| P0135 | O2 Sensor Heater Circuit Malfunction (Bank 1 Sensor 1) |
| P0136 | O2 Sensor Circuit Malfunction (Bank 1 Sensor 2) |
| P0141 | O2 Sensor Heater Circuit Malfunction (Bank 1 Sensor 2) |
| P0150 | O2 Sensor Circuit Malfunction (Bank 2 Sensor 1) |
| P0155 | O2 Sensor Heater Circuit Malfunction (Bank 2 Sensor 1) |
| P0156 | O2 Sensor Circuit Malfunction (Bank 2 Sensor 2) |
| P0161 | O2 Sensor Heater Circuit Malfunction (Bank 2 Sensor 2) |
| P0170 | Fuel Trim Malfunction (Bank 1) |
| P0173 | Fuel Trim Malfunction (Bank 2) |
| P0201 | Injector No. 1 Circuit Malfunction |
| P0202 | Injector No. 2 Circuit Malfunction |
| P0203 | Injector No. 3 Circuit Malfunction |
| P0204 | Injector No. 4 Circuit Malfunction |
| P0205 | Injector No. 5 Circuit Malfunction |
| P0206 | Injector No. 6 Circuit Malfunction |
| P0300 (3) | Random Misfire Detected |
| P0301 (3) | Cylinder No. 1 Misfire Detected |
| P0302 (3) | Cylinder No. 2 Misfire Detected |
| P0303 (3) | Cylinder No. 3 Misfire Detected |
| P0304 (3) | Cylinder No. 4 Misfire Detected |
| P0305 (3) | Cylinder No. 5 Misfire Detected |
| P0306 (3) | Cylinder No. 6 Misfire Detected |
| P0335 | CKP Sensor Circuit Malfunction |
| P0340 | CMP Sensor Circuit Malfunction |
| P0400 | EGR Flow Malfunction |
| P0403 | EGR Solenoid Malfunction |
| P0420 | Catalyst Efficiency Below Threshold (2.0L Turbo & Federal 2.4L) |
| P0421 | Warm Up Catalyst Efficiency Below Threshold (Bank 1 - California 2.4L) |
| P0431 | Warm Up Catalyst Efficiency Below Threshold (Bank 2 - California 2.4L) |
| P0442 | EVAP System Leak Detected |
| P0443 | EVAP Purge Control Valve Circuit Malfunction |
| P0446 | EVAP System Vent Control Malfunction |
| P0450 | EVAP System Pressure Sensor Malfunction Or Blocked System (2.0L Turbo & 2.4L) |
| P0455 | EVAP System Leak Or Blockage Detected (2.0L Turbo & 2.4L) |
| P0505 | Idle Control System Malfunction |
| P0510 | Closed Throttle Position Switch Malfunction |
| P0551 | Power Steering Pressure Sensor Circuit Range/Performance |
| P0705 | Transaxle Range Sensor Circuit Malfunction (PRNDL Input) |
| P0710 | Transaxle Fluid Temperature Sensor Circuit Malfunction |
| P0715 | Input/Turbine Speed Sensor Malfunction |
| P0720 | Output Speed Sensor Circuit Malfunction |
| P0725 | Engine Speed Input Circuit Malfunction |
| P0740 | Torque Converter Clutch System Malfunction |
| P0750 | Shift Solenoid A Malfunction |
| P0755 | Shift Solenoid B Malfunction |
| P0760 | Shift Solenoid C Malfunction |
| P0765 | Shift Solenoid D Malfunction |
| P1103 | Turbocharger Waste Gate Actuator Malfunction (2.0L Turbo) |
| P1104 | Turbocharger Waste Gate Solenoid Malfunction (2.0L Turbo) |
| P1105 | Fuel Pressure Solenoid Malfunction (2.0L Turbo) |
| P1400 | Manifold Differential Pressure Sensor Circuit Malfunction |
| P1600 | Serial Communication Link Malfunction |
| P1715 | Pulse Generator Assembly Malfunction |
| P1720 | VSS Signal Line Malfunction |
| P1750 | Solenoid Assembly Malfunction |
| P1751 | A/T Control Relay Malfunction |
| P1791 | ECT Level Input Circuit To TCM Malfunction |
| P1795 | Throttle Position Input Circuit Malfunction |
| (1) Applies to 1.5L only (2) MIL will illuminate on first detection of the malfunction (one-trip detection). For all other malfunctions, except severe misfire, MIL will illuminate when engine is next turned on and malfunction is again detected (two-trip detection). (3) If misfire is severe enough to cause catalytic converter damage, MIL will illuminate on first detection and continuously flash as long as danger is present (one-trip detection). If misfire is not severe enough to cause catalytic converter damage, but will cause emissions levels to increase 150 percent over Federal Test Procedure standards, a pending code will be set on first occurrence. If next time key is cycled on and off and misfire is detected under similar conditions to the first occurrence, MIL will illuminate (2-trip detection). | |
| (1) | Applies to 1.5L only |
| (2) | MIL will illuminate on first detection of the malfunction (one-trip detection). For all other malfunctions, except severe misfire, MIL will illuminate when engine is next turned on and malfunction is again detected (two-trip detection). |
| (3) | If misfire is severe enough to cause catalytic converter damage, MIL will illuminate on first detection and continuously flash as long as danger is present (one-trip detection). If misfire is not severe enough to cause catalytic converter damage, but will cause emissions levels to increase 150 percent over Federal Test Procedure standards, a pending code will be set on first occurrence. If next time key is cycled on and off and misfire is detected under similar conditions to the first occurrence, MIL will illuminate (2-trip detection). |
DTC INDEX - ALL MODELS EXCEPT ECLIPSE 2.0L NON-TURBO
CLEARING DTCS
| CAUTION | When battery is disconnected, vehicle computer and memory systems may lose memory data. Driveability problems may exist until computer systems have completed a relearn cycle. |
| CAUTION | All data will be lost when DTCs are cleared. Record data that may be needed later, such as freeze frame data for verifying repairs, before erasing DTCs. |
To clear DTCs using a scan tool, refer to owner's manual supplied with scan tool. If scan tool is not available, DTCs may be cleared by disconnecting negative battery cable or ECM/PCM for a few minutes. Reconnect negative battery cable. Start and warm up engine. Run at idle for about 15 minutes. Check for DTCs to confirm repair.
DTCs will be automatically erased by ECM/PCM under certain conditions
- If non-emission related fault does not reoccur within 51 engine starts, code will clear.
- If emission related fault, except misfire and fuel system lean/rich, does not reoccur in 40 drives, code will be erased.
- If misfire or fuel system lean/rich fault does not reoccur in 80 drives, code will be cleared.
Note. A drive is when engine goes from start to stop and component is monitored in between. The component's code set criteria must be met while the engine is operating before it will be monitored. Due to this, component may not be monitored every engine start to stop cycle.
VERIFYING REPAIRS
If verifying repair on Eclipse 2.0L non-turbo, go to SYSTEM READINESS TEST PROCEDURE . If verifying repair on all vehicles except Eclipse 2.0L non-turbo, go to the appropriate monitor referred to from self-diagnostics or find monitor related to the DTC that was repaired. Then carry out the drive cycle described under that monitor.
Note. These drive cycles apply to all vehicles except Eclipse 2.0L non-turbo.
Catalytic Converter Monitor
This monitor applies to DTCs P0420, P0421 and P0431. Following conditions must be met during the test
- Atmospheric temperature is 14°F (-10°C) or more.
- A/C switch is in OFF position.
- If automatic transmission, selector lever is in Drive.
- If applicable, overdrive switch is in ON position.
- If applicable, power/economy changeover switch is in POWER position.
Monitor takes about 20 minutes to complete. To run monitor, use illustration. (Scheme 80) Perform steps as follows
- Start engine.
- Accelerate to 45 MPH.
- Travel 300 seconds or more while keeping speed at 45-60 MPH (M/T in 5th gear on non-turbo, or 6th gear on turbo).
- Decelerate to 35-40 MPH.
- While keeping accelerator pedal opening degree constant, keep speed at 35-40 MPH for 90 seconds or more (M/T in 4th gear on non-turbo, or 5th gear on turbo).
- Fully close throttle and decelerate for 10 seconds. Then, quickly accelerate until speed is 35-40 MPH. Then repeat steps 5) and 6) five more times.
- Return vehicle to shop and turn ignition off.
- Confirm DTC is not output. If DTC is output, go to appropriate DTC test in appropriate SELF-DIAGNOSTICS article.
Scheme 80
EVAP System Leak Monitor
This monitor applies to DTCs P0442, P0450 and P0455. Following conditions must be met during the test
- Engine coolant temperature must be 113°F (45°C) or less.
- Atmospheric temperature is 41-113°F (5-45°C).
- If automatic transmission, selector lever is in "D" range.
- If applicable, overdrive switch is in ON position.
- If applicable, pattern select switch is in OFF position.
Monitor takes about 8 minutes to complete. To run monitor, use illustration. (Scheme 81) Perform steps as follows
- Start engine.
- Accelerate to 55-60 MPH.
- Travel for 200 seconds or more while keeping speed at 55-60 MPH (M/T: 5th gear).
- While keeping accelerator pedal opening degree constant, keep speed at 55-60 MPH for 150 seconds or more (this is when monitor runs).
- Return vehicle to shop and turn ignition off.
- Confirm DTC is not output. If DTC is output, go to appropriate DTC test in appropriate SELF-DIAGNOSTICS article.
Scheme 81
EGR Monitor
This monitor applies to DTC P0400. Following conditions must be met during the test
- Engine coolant temperature must be 176°F (80°C) or more.
- Atmospheric temperature is 41°F (5°C) or more.
- If automatic transmission, selector lever is in "D" range.
- If applicable, overdrive switch is in ON position.
- If applicable, power/economy changeover switch is in POWER position.
- A/C switch is in OFF position.
Monitor takes about 10 minutes to complete. To run monitor, use illustration. (Scheme 82) Perform steps as follows
- Start engine.
- Accelerate to 35-40 MPH.
- Keep speed constant for 20 seconds or more (M/T in 4th gear).
- Fully close throttle from engine speed of 2000-3000 RPM (keep clutch engaged if M/T) and decelerate to about 900 RPM without applying brakes. DO NOT turn steering wheel or operate light switch during this time.
- Accelerate to 35-40 MPH, then hold speed constant for 20 seconds or more (M/T: 4th gear). Repeat steps 4) and 5) seven more times.
- Return vehicle to shop and turn ignition off.
- Confirm DTC is not output. If DTC is output, go to appropriate DTC test in appropriate SELF-DIAGNOSTICS article.
Scheme 82
Fuel Trim Monitor
This monitor applies to DTCs P0170 and P0173. Following conditions must be met during the test
- Engine coolant temperature is 176-207°F (80-97°C).
- Atmospheric temperature is 14-140°F (-10-60°C).
- If automatic transmission, selector lever is in "D" range.
- If applicable, overdrive switch is in ON position.
- If applicable, power/economy changeover switch is in POWER position.
Monitor takes about 35 minutes to complete. To run monitor, use illustration. (Scheme 83) Perform steps as follows
- Start engine.
- Accelerate to 55-60 MPH.
- Drive at 55-60 MPH for 30 minutes or more (M/T in 5th gear on non-turbo, or 6th gear on turbo). During this period DO NOT drive at constant speed for more than 120 seconds. Carry out gradual deceleration and acceleration within every 120 second time frame. Depressing brake pedal is okay, but avoid abrupt braking.
- Return vehicle to shop and turn ignition off.
- Confirm DTC is not output. If DTC is output, go to appropriate DTC test in appropriate SELF-DIAGNOSTICS article.
Scheme 83
Heated Oxygen Sensor Monitor
This monitor applies to DTCs P0130, P0136, P0150 and P0156. Following conditions must be met during the test
- Engine coolant temperature must be 176°F (80°C) or more.
- Atmospheric temperature is 41°F (5°C) or more.
- If automatic transmission, selector lever is in "D" range.
- If applicable, overdrive switch is in ON position.
- If applicable, power/economy changeover switch is in POWER position.
Monitor takes about 5 minutes to complete. To run monitor, use illustration. (Scheme 84) Perform steps as follows
- Start engine.
- Accelerate to 35-40 MPH.
- While keeping accelerator pedal opening degree constant, keep speed at 35-40 MPH for 120 seconds or more (M/T in 4th gear on non-turbo, or 5th gear on turbo).
- Return vehicle to shop and turn ignition off.
- Confirm DTC is not output. If DTC is output, go to appropriate DTC test in appropriate SELF-DIAGNOSTICS article.
Scheme 84
Other Monitor
This monitor applies to DTCs not covered by rest of the monitors. Following conditions must be met during the test
- Engine coolant temperature must be 176°F (80°C) or more.
- Atmospheric temperature is 41°F (5°C) or more.
- If automatic transmission, selector lever is in "D" range.
- If applicable, overdrive switch is in ON position.
- If applicable, power/economy changeover switch is in POWER position.
Monitor takes about 10 minutes to complete. To run monitor, use illustration. (Scheme 85) Perform steps as follows
- Start engine.
- Accelerate to 35-40 MPH.
- Drive for 5 minutes or more at 35-40 MPH.
- Return vehicle to shop and let idle. While engine is idling, A/C switch must be in OFF position, lights and accessories must be off, steering wheel must be straight ahead and, if applicable, automatic transaxle must be in "P" range. After idling for 5 minutes, turn ignition off.
- Confirm DTC is not output. If DTC is output, go to appropriate DTC test in appropriate SELF-DIAGNOSTICS article.
Scheme 85
SUMMARY
If no there are no present or pending DTCs and driveability symptoms exist, proceed to TROUBLE SHOOTING - NO CODES article for diagnosis by symptom (i.e., ROUGH IDLE, NO START, etc.) or intermittent diagnostic procedures.
