Generators & Regulators: Removal & Installation Mitsubishi Mirage V

Charging System 5 illustrations ~431 words

REMOVAL & INSTALLATION

CAUTIONDisconnect the battery to remove power from alternator.

Note. Before disconnecting battery, retrieve radio code if equipped with Anti-theft radio (Anti-Theft will be present on radio facia).

For drive belt routing information. See ELECTRIC COOLING FANS, SPECIFICATIONS & DRIVE BELTS .

Removal & Installation (Diamente)

For Alternator (Generator) removal procedures, follow numbered steps in illustration. (Scheme 10) For Alternator (Generator) Installation Procedures, follow the numbered steps in the illustration in reverse order. Numbered steps in illustration refer to service points to observe while removing and installing Instrument Panel. Arrows pointing AWAY from each other refer to service points to be observed while performing that step of the removal procedure. Arrows pointing TOWARD each other refer to service points to be observed while performing that step of the installation procedure. More detail on specific step(s) is covered, as necessary, under Points Of Removal and/or Points Of Installation.

Scheme 10

Scheme 10: Removal & Installation (Diamente)

Removal & Installation (DOHC, 3000GT)

For Alternator (Generator) removal procedures, follow numbered steps in illustration. (Scheme 11)and (Scheme 12). For Alternator (Generator) Installation Procedures, follow the numbered steps in the illustration in reverse order. Numbered steps in illustration refer to service points to observe while removing and installing Instrument Panel. Arrows pointing AWAY from each other refer to service points to be observed while performing that step of the removal procedure. Arrows pointing TOWARD each other refer to service points to be observed while performing that step of the installation procedure. More detail on specific step(s) is covered, as necessary, under Points Of Removal and/or Points Of Installation.

Scheme 11

Scheme 11: Removal & Installation (DOHC, 3000GT)

Scheme 12

Scheme 12

Points Of Removal

  1. Step 3: Removing clamp nuts of A/C Suction hose On vehicles equipped with air conditioning, remove clamp nuts, carefully raise the suction hose and suspend it from the engine hood using a cord.

Removal & Installation (SOHC 3000GT)

For Alternator (Generator) removal procedures, follow numbered steps in illustration. (Scheme 13)and (Scheme 14). For Alternator (Generator) Installation Procedures, follow the numbered steps in the illustration in reverse order. Numbered steps in illustration refer to service points to observe while removing and installing Instrument Panel. Arrows pointing AWAY from each other refer to service points to be observed while performing that step of the removal procedure. Arrows pointing TOWARD each other refer to service points to be observed while performing that step of the installation procedure. More detail on specific step(s) is covered, as necessary, under Points Of Removal and/or Points Of Installation.

Scheme 13

Scheme 13: Removal & Installation (SOHC 3000GT)

Scheme 14

Scheme 14
  1. Step 6: Removing alternator Take out the alternator from behind the surge tank (intake manifold plenum) at the center of the vehicle.
