Wiring diagram: Power windows — Power windows circuit, except evolution without central door locking Mitsubishi Lancer X
All systems — 32 systems
- Air conditioning 4
- Anti-lock brakes 2
- Anti-theft 4
- Body control modules 2
- Computer data lines 2
- Cooling fan 2
- Cruise control 2.0l
- Cruise control 2.0l turbo
- Defoggers
- Engine performance 2.0l
- Engine performance 2.0l turbo
- Exterior lights 4
- Ground distribution 2
- Headlights 3
- Horn
- Instrument cluster 2
- Interior lights 4
- Navigation 5
- Power distribution 2
- Power door locks 4
- Power mirrors 2
- Power seats
- Power top/sunroof 2
- Power windows 3
- Radio 7
- Shift interlock 2
- Starting/charging 3
- Supplemental restraints 2
- Transmission 2
- Trunk, tailgate, fuel door
- Warning systems 4
- Wiper/washer
Power windows
# Power windows circuit, except evolution without central door locking
Components on the diagram
Components on these wiring diagrams 26
Click a component to highlight it on every diagram it appears on.
