Emission Control (Mfi - T/c) - Lancer Evolution: Removal & Installation Mitsubishi Lancer X

Testing & Diagnostics 1 illustration

VACUUM HOSE INSTALLATION

  1. When connecting the vacuum hoses, they should be securely inserted onto the nipples.
  2. Connect the hoses correctly, using the VACUUM HOSE ROUTING diagram as a guide.

<< A >> HEATED OXYGEN SENSOR (REAR) REMOVAL

Use special tool MB991953 to remove the heated oxygen sensor (rear).

Scheme 11

Scheme 11: << A >> HEATED OXYGEN SENSOR (REAR) REMOVAL
Scheme 11: << A >> HEATED OXYGEN SENSOR (REAR) REMOVAL

>> A << HEATED OXYGEN SENSOR (REAR) INSTALLATION

Tighten the heated oxygen sensor (rear) to the specified torque by using special tool MB991953.

Tightening torque: 44 ± 5 N.m (33 ± 3 ft-lb)
