Power Plant Mount - Lancer Evolution: Overview Mitsubishi Lancer X

Mechanical 2 illustrations ~146 words

GENERAL INFORMATION

For the power plant support, the inertial axis four-point mounting system is adopted, and the system has the following features.

  1. Environmental-load substances are totally abolished for hexavalent chromium-free and lead-free components.
  2. For the engine and transaxle mounting insulator, the cylindrical liquid seal mountings are adopted. This reduces idling vibration and acceleration noise, and improves riding comfort.
  3. A front axle crossmember is adopted to improve steering ability.
  4. The mass damper is added into the centermember to reduce muffled sound during acceleration.
  5. The front axle crossmember bar and the front axle crossmember stay are added to enhance rigidity.

Scheme 253

Scheme 253: CONSTRUCTION DIAGRAM
  1. The shape of engine mounting insulator stopper is optimized to reduce vibration transfer.
  2. The engine mounting stopper is added to the engine mounting insulator to reduce movement of engine. < TC-SST >

Scheme 254

Scheme 254: CONSTRUCTION DIAGRAM
