>> C << SNAP RING INSTALLATION Mitsubishi Lancer IX facelift

>> C << SNAP RING INSTALLATION

Select and install appropriate snap ring onto the reverse idler gear shaft so that the clearance of the thrust washer A meets the standard value.

Standard Value: 0 - 0.11 mm (0 - 0.0043 inch)

Scheme 242

Scheme 243

1. Check that the synchronizer ring clutch gear teeth are free of damage.
2. Check that the inside surface of the synchronizer ring cone is free of damage and wear.
3. Check that the synchronizer ring and synchronizer key are not damaged or worn in the contact surface.
4. Press the synchronizer ring against the gear and check clearance "A". If "A" is less than the limit value, replace the synchronizer ring. Limit: 0.5 mm (0.02 inch)
