REMOVAL AND INSTALLATION
| WARNING | Before removing the air bag module, refer to SERVICE PRECAUTIONS and Air Bag Module and Clock Spring . When removing and installing the steering wheel, do not let it bump against the air bag module. |
Scheme 119
Required Special Tool
- MB990784: Ornament remover
<< A >> STEERING WHEEL REMOVAL
Insert the special tool MB990784 at the indicated position to remove the cover.
Note. The special tool MB990784 can be inserted through the notch behind the area shown.
Scheme 120
Scheme 121
Scheme 122
- By sliding section A of the clock spring connector shown in the illustration in the arrow direction, disconnect the connector.
- Loosen the bolt completely. Then, remove the steering wheel and airbag module assembly. NOTE: Use a hexagonal bit socket or a hexagonal wrench having an effective length of 75 mm (3.0 inches) or more in the hexagonal section and the diameter of 8 mm (0.31 inches) or more.
<< A >> SPECIAL BOLT REMOVAL
- Drill in the special bolt a hole deep enough for the tap to stand.
- Remove the special bolt with a left-hand tap.
Scheme 123
| WARNING | Before removing the steering gear box, refer to GROUP 52B. Center the front wheels and remove the ignition key. Failure to do so may damage the SRS clock spring and render the SRS system inoperative, risking serious injury. |
Scheme 124
Scheme 125
<< A >> RACK SUPPORT COVER REMOVAL
Using special tool MB991204, remove the rack support cover from the gear box.
Scheme 126
<< B >> LOWER OIL SEAL/PINION AND VALVE ASSEMBLY REMOVAL
Using a plastic hammer, gently tap the pinion to remove it.
Scheme 127
<< C >> SEAL RING REMOVAL
| CAUTION | When cutting the seal ring, be careful not to damage the pinion and valve assembly or the rack. |
Cut the seal ring and remove it from the pinion and valve assembly and the rack.
Scheme 128
<< D >> UPPER BEARING/UPPER OIL SEAL REMOVAL
Using a socket, remove the oil seal and the ball bearing from the valve housing simultaneously.
Scheme 129
Scheme 130
<< E >> CIRCLIP REMOVAL
| CAUTION | If the rack stopper is first turned counterclockwise, the circlip will get caught in the slot in the housing and the rack stopper will not turn. |
- Turn the rack stopper clockwise until the end of the circlip comes out of the slot in the rack housing.
- Turn the rack stopper counterclockwise to remove the circlip.
Scheme 131
Scheme 132
- Pull out the rack slowly. Take out the rack stopper and the rack bushing at the same time. CAUTION: Do not damage the oil seal press fitting surface.
- Partially bend the oil seal and remove it from the rack bushing.
Scheme 133
<< G >> LOWER BEARING REMOVAL
Use a brass bar or special tool MB990939 to remove the ball bearing from the gear housing.
Scheme 134
<< H >> NEEDLE BEARING REMOVAL
| CAUTION | Do not open special tool MB991120 excessively to prevent damaging housing interior. |
Use special tool MB991120 to remove the needle roller bearing from the rack housing.
Scheme 135
<< I >> OIL SEAL REMOVAL
| CAUTION | Be careful not to damage the inner surface of the rack cylinder of the gear housing. |
Use a piece of pipe or similar tool to remove the oil seal from the gear housing.
>> A << OIL SEAL INSTALLATION
- Apply a coating of GENUINE MITSUBISHI POWER STEERING FLUID to the both sides of the oil seal.
- Using special tools MB991202 and MB991197, press the oil seal into the rack housing.
Scheme 136
>> B << NEEDLE BEARING/LOWER BEARING INSTALLATION
- Apply GENUINE MITSUBISHI POWER STEERING FLUID to housing, bearing and oil seal press fitting surface. CAUTION: Press-fit straight. The valve housing is aluminum, and may become deformed if press-fit on an angle.
- Press fit needle roller bearing with special tools MB990938 and MB991202.
Scheme 137
>> C << RACK ASSEMBLY INSTALLATION
| CAUTION | Do not close the vent hole in the rack with grease. |
Scheme 138
- Apply a coating of multipurpose grease to the rack teeth face.
- Cover rack serrations with special tool MB991213.
- Apply GENUINE MITSUBISHI POWER STEERING FLUID to special tool MB991213.
- Align the center of the oil seal with the rack to prevent the retainer spring from slipping. Slowly insert the rack from power cylinder side.
Scheme 139
Scheme 140
- Apply GENUINE MITSUBISHI POWER STEERING FLUID to the outer surface of the oil seal. Using the special tool, press in the oil seal until it is flush with the bushing end face.
- Apply GENUINE MITSUBISHI POWER STEERING FLUID to the oil seal inner surface and the O-ring.
- Wrap the rack end with plastic tape, and push the rack bushing onto the rack.
Scheme 141
>> E << CIRCLIP INSTALLATION
| CAUTION | Insert the circlip to the rack stopper hole while turning the rack stopper clockwise. |
Insert the circlip to the rack stopper hole through cylinder hole. Turn the rack stopper clockwise and insert the circlip firmly.
Scheme 142
>> F << UPPER OIL SEAL/UPPER BEARING INSTALLATION
Apply a coating of GENUINE MITSUBISHI POWER STEERING FLUID to the outside of the upper oil seal/upper bearing. Using special tools MB990938 and MB991203, press the upper oil seal/upper bearing into the valve housing.
Scheme 143
>> G << SEAL RING INSTALLATION
Because the seal rings expand after installation, tighten after installing by using special tool MB991317 to compress the rings, or press down by hand.
Scheme 144
>> H << OIL SEAL INSTALLATION
| CAUTION | To eliminate a seal malfunction at the valve housing alignment surface, the upper surface of the oil seal should project outward approximately 1 mm (0.04 inch) from the housing edge surface. |
Using special tool MB990941, press the oil seal into the valve housing.
Scheme 145
>> I << END PLUG INSTALLATION
- Apply 3M TM AAD Part number 8661, 8663, 8672, 8678, 8679 or equivalent to the threaded part of the end plug.
- Secure the threaded portion of the end plug at two places by using a punch.
Scheme 146
>> J << RACK SUPPORT COVER/JAM NUT INSTALLATION
- Position the rack at its center.
- Apply 3M TM AAD Part number 8661, 8663, 8672, 8678, 8679 or equivalent to the threaded part of the rack support cover.
- Use special tool MB991204 to tighten the rack support cover to 2 +/- 23 N.m (1 +/- 17 ft-lb).
- Turn the rack support cover 30 degree angle counterclockwise.
- Use special tool MB991204 to hold the rack support cover, and then tighten the jam nut to 10 +/- 59 N.m (7 +/- 44 ft-lb).
Scheme 147
>> L << TAB WASHER/TIE ROD INSTALLATION
After installing the tie rod to the rack, fold tab washer end (two locations) to tie rod notch.
Scheme 148
Scheme 149
Scheme 150
Scheme 151
- Turn the adjusting bolt of special tool MB991561 to adjust the opening dimension (W) to the standard value. NOTE: The dimension (W) is adjusted by approximately 0.7 mm (0.03 inch) per one turn. NOTE: Do not turn the adjusting bolt more than one turn. Standard value (W): 2.9 mm (0.11 inch) : Screw in the adjusting bolt. : Loosen the adjusting bolt. CAUTION: Hold the rack housing, and use special tool MB991561 to crimp the bellows band securely. Crimp the bellows band until special tool MB991561 touches the stopper.
- Use special tool MB991561 to crimp the bellows band.
- Check that crimped width (A) is within the standard value. Standard value (A): 2.4 - 2.8 mm (0.09 - 0.11 inch) : Readjust the dimension (W) of step (1) to the value calculated by the following equation, and repeat step (2). W = 5.5 mm (0.22 inch) - A [Example: if (A) is 2.9 mm (0.11 inch), (W) is 2.6 mm (0.10 inch).] : Remove the bellows band, readjust the dimension (W) of step (1) to the value calculated by the following equation, and use a new bellows band to repeat steps (2) to (3). W = 5.5 mm (0.22 inch) - A [Example: if (A) is 2.3 mm (0.09 inch), (W) is 3.2 mm (0.13 inch).]
>> N << TIE ROD END/TIE ROD END JAM NUT INSTALLATION
Screw in the tie rod end to achieve the right and left length as illustrated. Lock with the jam nut.
Note. The locking nut must be tightened securely only after the power steering gear box and linkage are installed to the vehicle and toe-in is adjusted.
Scheme 152
>> O << GEAR MOUNTING RUBBER INSTALLATION
Install the gear mounting rubber to the rack housing so that the distance is as shown in the illustration.
Scheme 153
TIE ROD END BALL JOINT DUST COVER REPLACEMENT
If the dust cover is damaged accidentally during service work, replace the dust cover as follows
- Apply grease to the lip and inside of the dust cover.
- Drive in the dust cover with special tool MB990776 until it is fully seated.
- Check the dust cover for cracks or damage by pushing it with your finger.
Scheme 154
<< A >> OIL PUMP ASSEMBLY REMOVAL
With the engine lifted by the jack, remove the oil pump assembly mounting bolt (lower side) at the pulley side.
>> B << OIL SEAL INSTALLATION
Use special tool MB991203 and MB990938 to install the oil seal.
Scheme 155
>> C << CAM RING INSTALLATION
| CAUTION | Be sure to install the cam ring in the correct direction as shown. |
Install the cam ring as shown in the illustration.
| WARNING | Before removing the steering gear box, refer to GROUP 52B. Center the front wheels and remove the ignition key. Failure to do so may damage the SRS clock spring and render the SRS system inoperative, risking serious injury. |
| CAUTION | *: Indicates parts which should be temporarily tightened, and then fully tightened with the vehicle on the ground in an unladen condition. |
Scheme 156
<< A >> EYE BOLT/RETURN TUBE REMOVAL
- Loosen the crossmember mounting bolts and nuts, and lower the crossmember to a position so that the eye bolts or return tube at the steering gear side can be removed. NOTE: In this case, do not remove the crossmember mounting bolts and nuts.
- Remove the eye bolts or return tube.
Scheme 157
>> A << RETURN HOSE INSTALLATION
Install the return hose so that the marking is positioned as shown in the illustration.
Scheme 158
>> B << RETURN HOSE INSTALLATION
Install the return hose so that the marking is positioned as shown in the illustration.
Scheme 159
>> C << SUCTION HOSE INSTALLATION
Install the suction hose so that the marking is positioned as shown in the illustration.
