FASTENER TIGHTENING SPECIFICATIONS
| ITEM | SPECIFICATION |
|---|---|
| Center bearing assembly nut | 30 ± 4 N.m (22 ± 3 ft-lb) |
| Companion flange to front propeller shaft connecting nut | 34 ± 5 N.m (25 ± 4 ft-lb) |
| Companion flange, LJ assembly, LJ boot and washer connecting nut | 34 ± 5 N.m (25 ± 4 ft-lb) |
| Propeller shaft and differential companion flange connecting nut | 32 ± 2 N.m (24 ± 1 ft-lb) |
| Self locking nut (companion flange to front and center propeller shaft connection) | 187 ± 29 N.m (138 ± 21 ft-lb) |
Fastener Tightening Specifications
GENERAL SPECIFICATIONS
| ITEM | SPECIFICATION | ||
|---|---|---|---|
| Propeller shaft | Type | 3 way split 4-joint type propeller shaft | |
| Length (1) x Outside diameter mm (in) | Front | 608.5 x 65 (24.0 x 2.56) | |
| Center | 551 x 65 (21.7 x 2.56) | ||
| Rear | 750.5 x 65 (29.5 x 2.56) | ||
| Universal joint | Type | No.1 | Cross type (cauking method) |
| No.2 | Cross type (cauking method) | ||
| No.3 | Constant velocity type (LJ) | ||
| No.4 | Cross type (cauking method) | ||
| Cross type joint | Bearing | Non-lubrication type needle roller bearing | |
| Journal diameter mm (in) | 16.3 (0.64) | ||
| (1) The propeller shaft length indicates the length between the center points of each joint. | |||
| (1) | The propeller shaft length indicates the length between the center points of each joint. |
Propeller Shaft General Specification
Note. *: The propeller shaft length indicates the length between the center points of each joint.
