FASTENER TIGHTENING SPECIFICATIONS
| ITEM | SPECIFICATION | |
|---|---|---|
| Cylinder block | ||
| Cylinder block drain plug | 44 ± 5 N.m (33 ± 3 ft-lb) | |
| Radiator | ||
| Air Pipe B bolt | 12 ± 2 N.m (102 ± 22 in-lb) | |
| Cooling fan motor bolt | 4.5 ± 0.4 N.m (39 ± 4 in-lb) | |
| Cooling fan nut | 3.5 ± 0.4 N.m (31 ± 4 in-lb) | |
| Cooling fan shroud bolt | 4.0 ± 0.4 N.m (35 ± 4 in-lb) | |
| Reserve tank bolt | 5.0 ± 1.0 N.m (44 ± 9 in-lb) | |
| Reserve tank bracket bolt | 5.0 ± 1.0 N.m (44 ± 9 in-lb) | |
| Reserve tank hose bolt | 5.0 ± 1.0 N.m (44 ± 9 in-lb) | |
| Upper insulator bolt | 12 ± 2 N.m (102 ± 22 in-lb) | |
| Thermostat | ||
| Accelerator cable bolt | 5.0 ± 1.0 N.m (44 ± 9 in-lb) | |
| Control harness bolt | 11 ± 1 N.m (98 ± 8 in-lb) | |
| Vacuum pipe bolt | 11 ± 1 N.m (98 ± 8 in-lb) | |
| Water outlet fitting bolt | 10 ± 1 N.m (84 ± 13 in-lb) | |
| Water hose and water pipe | ||
| Accelerator cable bolt | 5.0 ± 1.0 N.m (44 ± 9 in-lb) | |
| Bracket bolt | 36 ± 6 N.m (27 ± 4 ft-lb) | |
| Control harness bolt | 11 ± 1 N.m (98 ± 8 in-lb) | |
| Engine hanger bolt | 22 ± 4 N.m (16 ± 3 ft-lb) | |
| Turbocharger water feed pipe bolt (bolt, eye) | 42 ± 7 N.m (31 ± 5 ft-lb) | |
| Turbocharger water feed pipe bolt (bolt, flange) | 10 ± 1 N.m (84 ± 13 in-lb) | |
| Turbocharger water return pipe bolt (bolt, eye) | 42 ± 7 N.m (31 ± 5 ft-lb) | |
| Turbocharger water return pipe bolt (bolt, flange) | 10 ± 1 N.m (84 ± 13 in-lb) | |
| Vacuum pipe bolt | 11 ± 1 N.m (98 ± 8 in-lb) | |
| Vacuum pipe bracket bolt | 11 ± 1 N.m (98 ± 8 in-lb) | |
| Water inlet pipe bolt | M6 | 5.0 ± 1.0 N.m (44 ± 9 in-lb) |
| M8 | 13 ± 2 N.m (111 ± 22 in-lb) | |
| Water outlet fitting and thermostat case bolt | 23 ± 4 N.m (17 ± 3 ft-lb) | |
| Water pump | ||
| Generator brace bolt | 22 ± 4 N.m (16 ± 3 ft-lb) | |
| Water pump and generator brace bolt | 23 ± 3 N.m (17 ± 2 ft-lb) | |
| Water pump bolt | 14 ± 1 N.m (120 ± 13 in-lb) | |
