DATA LIST REFERENCE TABLE Mitsubishi Lancer Ralliart IX

DATA LIST REFERENCE TABLE

Note. *:Disconnect the throttle position sensor connector, and then delete the diagnostic trouble code that was recorded during the inspection with the use of scan tool MB991958 after the inspection has been completed.

Scheme 97

Scheme 98

Scheme 99

Scheme 100

Scheme 101

Scheme 102

Scheme 103

Scheme 104

Scheme 105

1. Turn the ignition switch to the "ON" position.
2. Check that the "CRUISE" indicator light within the combination meter illuminates when the "CRUISE" (MAIN) switch is switched "ON".

Scheme 106

1. Switch "ON" the "CRUISE" (MAIN) switch.
2. Drive at the desired speed, above approximately 40 km/h (25 mph).
3. Push the auto-cruise control switch in the direction of arrow.
4. Check to be sure that when the switch is released the speed is the desired constant speed. NOTE: If the vehicles speed decreases the approximately 15 km/h (9 mph) below the set speed because of climbing a hill for example, the auto-cruise control will be cancelled.

Scheme 107

1. Set to the desired speed.
2. Push the auto-cruise control switch in the direction of arrow.
3. Check to be sure that acceleration continues while the switch is held, and that after it is released the constant speed at the time when it was released becomes the driving speed. NOTE: Acceleration can be continued even if the vehicle speed has passed the high-speed limit [approximately 170 km/h (106 mph)]. But the speed when the auto-cruise control switch is released will be recorded as the high-speed limit.

Scheme 108

1. Set to the desired speed.
2. Push the auto-cruise control switch in the direction of arrow.
3. Check to be sure that deceleration continues while the switch is pressed, and that after it is released the constant speed at the time when it was released becomes the driving speed. NOTE: When the vehicle speed reaches the low limit [approximately 40 km/h (25 mph)] during deceleration, the auto-cruise control will be cancelled.

Scheme 109

1. Set the auto-cruise speed control.
2. When any of the following operations are performed while at constant speed during auto-cruise control, check if normal driving is resumed and deceleration occurs. The auto-cruise control switch is pulled in the direction of arrow. The brake pedal is depressed. The selector lever is moved to the "N" range.
3. At a vehicle speed of 40 km/h (25 mph) or higher, check if when the "ACC/RES" switch is switched ON, the vehicle speed returns to the speed before auto-cruise control driving was cancelled, and constant speed driving occurs.
4. When the "CRUISE" (MAIN) switch is turned to the "OFF" while driving at constant speed, check if normal driving is resumed and deceleration occurs.

Scheme 110

Scheme 111

1. Remove the auto-cruise control switch. (Refer to «AUTO-CRUISE CONTROL»(/mitsubishi/lancer-ralliart/ix-2003-2005/remont/cruise-control-systems/#auto-cruise-control-system-sportback) ).
2. Measure the resistance between terminal 2 and terminal 3 when each of the "COAST/SET", "ACC/RES", "CANCEL" and "CRUISE" (MAIN) switches is pressed. If the values measured at the time correspond to those in the table below, the resistance values are correct.

Scheme 112

Scheme 113

1. Disconnect the connector.
2. Check for continuity between the terminals of the switch.
