Contents Section: Gauges & Instrument Panels All sections

Interior - Lancer Evolution Mitsubishi Lancer Evolution IX

Gauges & Instrument Panels 37 illustrations ~702 words

SEAT BELT WARNING SYSTEM

  1. When the ignition switch is turned "ON" without fastening the seat belts (seat belt switch OFF), the tone alarm will sound for approximately 6 seconds to warn the driver to fasten the seat belts. When the seat belts are fastened, the tone alarm will stop sounding.
  2. When the ignition switch is turned "ON" without fastening the seat belt, the seat belt warning light comes on to warn the driver to fasten the seat belt.

SEAT BELT WARNING SYSTEM DIAGNOSIS

The seat belt warning system is controlled by Simplified Warning System (SWS). For troubleshooting, refer to SWS DIAGNOSIS .

SPECIAL TOOL

SPECIAL TOOL CHART TOOL TOOL NUMBER AND NAME SUPERSESSION APPLICATION MB990784 Ornament remover General service tool Removal of switch, trim, etc

Scheme 40

Scheme 40: SPECIAL TOOL

REMOVAL AND INSTALLATION

The following bolts and screws are used for installing the instrument panel. Bolts and screws are indicated as marks shown in the illustration in the sections of "Removal and Installation" and "Disassembly and Assembly."

BOLT AND SCREW SPECIFICATION NAME SYMBOL SIZE (D x L) mm COLOR SHAPE Tapping screw a 5 x 16 Black b 5 x 16 - c 5 x 12 - Bolt with washer d 6 x 12 - e 5 x 20 - D: Thread diameter L: Effective thread length

Scheme 41

Scheme 41: REMOVAL AND INSTALLATION

Scheme 42

Scheme 42

Scheme 43

Scheme 43

Scheme 44

Scheme 44

Scheme 45

Scheme 45

Scheme 46

Scheme 46: CLIP AND CLAW POSITION

<< A >> PASSENGER'S (FRONT) AIR BAG MODULE REMOVAL

CAUTIONDo not damage the claws of the hinge when removing the passenger's (front) air bag module. Store the removed passenger's (front) air bag module with the deployed side facing upward, in a clean and dry place.

Insert the flat-tipped screwdriver into the position shown in the illustration and pull up the screwdriver to disengage the claws for removal of the passenger's (front) air bag module.

Scheme 47

Scheme 47

Scheme 48

Scheme 48: DISASSEMBLY AND ASSEMBLY

Scheme 49

Scheme 49: REMOVAL AND INSTALLATION

Scheme 50

Scheme 50: REMOVAL AND INSTALLATION

Scheme 51

Scheme 51: DISASSEMBLY AND ASSEMBLY

Required Special Tool

  1. MB990784: Ornament Remover

<< A >> CONSOLE LID ASSEMBLY REMOVAL

Insert the special tool MB990784 into the hinges of the console lid assembly and the rear floor console through the ashtray mounting hole to pry for removal.

Scheme 52

Scheme 52: << A >> CONSOLE LID ASSEMBLY REMOVAL

Scheme 53

Scheme 53: REMOVAL AND INSTALLATION

Scheme 54

Scheme 54: CLIP POSITION

<< A >> FRONT PILLAR TRIM REMOVAL

Release the clip by pulling in the direction shown in the illustration and remove the front pillar trim.

Scheme 55

Scheme 55: << A >> FRONT PILLAR TRIM REMOVAL

Scheme 56

Scheme 56: REMOVAL AND INSTALLATION

Required Special Tool

Scheme 57

Scheme 57
  1. MB990784: Ornament Remover

Required Special Tool

  1. MB991784: Ornament Remover

Scheme 58

Scheme 58: CLIP AND CLAW POSITIONS

Scheme 59

Scheme 59

Scheme 60

Scheme 60: << A >> DOOR INSIDE HANDLE COVER REMOVAL

Scheme 61

Scheme 61
  1. Insert a flat-tipped screwdriver into the rear end of the tapping screw cap on the door inside handle cover, and pry out the cap in the direction shown. Then remove the tapping screw.
  2. Insert special tool MB990784 into the clearance between the door inside handle cover and the door inside handle, and disengage the claws of the door inside handle.
  3. Insert special tool MB990784 into the rear end of the inside handle cover, and pry out the cover in the direction shown. Then remove the door inside handle cover.

Scheme 62

Scheme 62: REMOVAL AND INSTALLATION

Required Special Tool

  1. MB990784: Ornament Remover

<< A >> SUN VISOR HOLDER REMOVAL

Insert special tool MB990784 into side claws of the sun visor holder through both sides of the sun visor holder, to remove the hinges.

Scheme 63

Scheme 63: << A >> SUN VISOR HOLDER REMOVAL

<< B >> HEADLINING REMOVAL

Bend the headlining to remove from the front passenger's door.

Scheme 64

Scheme 64: REMOVAL SERVICE POINT
  1. Disengage claw A and lower the cover in the arrow 1 direction.
  2. Push claw B in the arrow 2 direction to unlock, and pull out the mirror in the arrow 3 direction.

Scheme 65

Scheme 65: REMOVAL AND INSTALLATION

Scheme 66

Scheme 66: >> A << FRONT SEAT ASSEMBLY INSTALLATION
  1. Temporarily tighten the nuts and bolts in all mounting locations shown in the illustration with no load applied to the front seat cushion, and check the operation of the seat slide.
  2. Tighten the nuts and bolts in all mounting locations to the specified torque.

Scheme 67

Scheme 67: DISASSEMBLY AND ASSEMBLY

Scheme 68

Scheme 68: REMOVAL AND INSTALLATION

Scheme 69

Scheme 69

>> A << INSTALLATION OF REAR SEATBACK ASSEMBLY

Press the rear seatback assembly in the direction shown in the illustration and fit the attachment wire into the hook securely to install the rear seatback assembly.

Scheme 70

Scheme 70: >> A << INSTALLATION OF REAR SEATBACK ASSEMBLY

>> B << INSTALLATION OF REAR SEAT CUSHION ASSEMBLY

Fit the rear seat cushion into the rear seat hook securely.

Scheme 71

Scheme 71: >> B << INSTALLATION OF REAR SEAT CUSHION ASSEMBLY

Scheme 72

Scheme 72: DISASSEMBLY AND ASSEMBLY

Scheme 73

Scheme 73
CAUTIONSRS: Before removing and installing the seat belts with pre-tensioner, refer to SEAT BELTS WITH PRE-TENSIONER .

Scheme 74

Scheme 74

SEAT BELT SWITCH CONTINUITY CHECK

ITEMTESTER CONNECTIONSPECIFIED CONDITION
Fastened seat belt1 -2Open circuit
Unfastened seat belt1 -2Less than 2 ohms

ITEM TESTER CONNECTION SPECIFIED CONDITION

Scheme 75

Scheme 75

Scheme 76

Scheme 76: REMOVAL AND INSTALLATION

FASTENER TIGHTENING SPECIFICATION

ITEMSPECIFICATION
TRIMS
Child restraint fitting bolt22 +/-4 N. m(16 +/- 3ft-lb)
FRONT SEAT ASSEMBLY
Front seat assembly bolt45 +/- 10 N. m (34 +/- 7 ft-lb)
Front seat assembly nut30 +/- 5 N. m (22 +/- 4 ft-lb)
Seatback assembly bolt22 +/- 3 N. m (16 +/- 2 ft-lb)
Slide adjuster inner bolt22 +/- 3 N. m (16 +/- 2 ft-lb)
Slide adjuster outer bolt22 +/- 3 N. m (16 +/- 2 ft-lb)
REAR SEAT ASSEMBLY
Rear seatback assembly bolt22 +/- 4 N. m (16 +/- 3 ft-lb)
FRONT SEAT BELT
Adjustable seat belt anchor bolt44 +/- 10 N. m (33 +/- 7 ft-lb)
Inner seat belt bolt44 +/- 10 N. m (33 +/- 7 ft-lb)
Outer seat belt bolt44 +/- 10 N. m (33 +/- 7 ft-lb)
REAR SEAT BELT
Center seat blet, inner bolt44 +/- 10 N. m (33 +/- 7 ft-lb)
Center seat belt, outer bolt44 +/- 10 N. m (33 +/- 7 ft-lb)
Inner seat belt bolt44 +/- 10 N. m (33 +/- 7 ft-lb)
Outer seat belt bolt44 +/- 10 N. m (33 +/- 7 ft-lb)

FASTENER TIGHTENING SPECIFICATION
