CENTRAL DOOR LOCKING SYSTEM INSPECTION
Check the following. Troubleshoot if any of the operations malfunction (Refer to SIMPLIFIED WIRING SYSTEM (SWS) - LANCER EVOLUTION ).
- Insert the key into the driver's key cylinder and turn once counterclockwise to unlock the driver's door. Turn the key again counterclockwise to unlock all doors.
- All doors can be locked or unlocked using the front door < RH > key cylinder key operation.
- All door can be locked using the driver's inside door lock knob.
- All doors can be locked using the door lock switch built into the front power window (main or sub < RH >) switch.
Scheme 167
- Check that the door outside handle play is within the standard value range. Standard value (A): Front door: 2.3 +/- 2.1 mm (0.09 +/- 0.08 inch) Rear door: 1.3 +/- 1.7 mm (0.05 +/- 0.07 inch)
- If the door outside handle play is not within the standard value range, check the door outside handle or the door latch assembly. Replace if necessary.
Scheme 168
Scheme 169
- Check that the door inside handle play is within the standard value range. Standard value (B): Front door: 10.4 +/- 9.6 mm (0.41 +/- 0.38 inch) Rear door: 10 +/- 9.6 mm (0.39 +/- 0.38 inch)
- If the door inside handle play is outside the standard value range: Remove the door trim assembly (Refer to «DOOR TRIM»(/mitsubishi/lancer-evolution/ix-2005-2007/remont/gauges-instrument-panels/#interior-lancer-evolution) ). Remove the waterproof film (Refer to «WINDOW GLASS RUNCHANNEL AND DOOR OPENING WEATHERSTRIP»(/mitsubishi/lancer-evolution/ix-2005-2007/remont/door-locks-anti-theft-systems/#body-lancer-evolution) ). Adjust the door inside handle play with the outer cable end connecting the door inside handle and inside lock cable.
