Maintenance Information: Overview Mitsubishi Galant VII

Fuse & Circuit Breaker Identification

1. 1 - 10 Amp Dome Light, Clock
2. 2 - 10 Amp Stoplights
3. 3 - 10 Amp (1986) Hazard Light, Power Window Relay
4. 3 - 20 Amp (1987) Heater
5. 4 - 20 Amp (1986) Heater
6. 4 - 10 Amp (1987) Hazard Light, Power Window Relay
7. 5 - 15 Amp Radio, Cigarette Lighter
8. 6 - 20 Amp Wipers
9. 7 - 20 Amp Defogger
10. 8 - 15 Amp Power Door Locks, Electronic Control Suspension (If Equipped)
11. 9 - 10 Amp Turn Signals, Gauges
12. 10 - 10 Amp Back-Up Lights
13. 11 - 10 Amp (1986) Defogger Relay, Heater Relay, Automatic Transaxle Control System
14. 10 Amp (1987) Defogger Relay, Automatic Transaxle Control System
15. 12 - 15 Amp (1986) Electronic Control Power Steering, Electronic Control Suspension (If Equipped)
16. 13 - Spare Fuses

Scheme 1

1. 1 - 15 Amp Cigarette Lighter, Dimming Mirror (If Equipped)
2. 2 - 10 Amp Radio
3. 3 - 10 Amp Defogger Relay, Heater Relay
4. 4 - 10 Amp Electronic Control Power Steering (If Equipped)
5. 5 - Blank (1989-90)
6. 5 - 10 Amp (1991-93) Seat Belts
7. 6 - 10 Amp Turn Signals
8. 7 - 10 Amp Gauges (1989), Meters (1990-93)
9. 8 - 10 Amp Horn
10. 9 - 15 Amp Wipers
11. 10 - Blank
12. 11 - 10 Amp Automatic Transaxle Control System (If Equipped)
13. 12 - 15 Amp Power Door Locks (If Equipped)
14. 13 - 10 Amp Dome Light, Clock
15. 14 - 10 Amp Back-Up Lights
16. 15 - 15 Amp Stoplights
17. 16 - 30 Amp Heater
18. 17 - 20 Amp Sun Roof (Optional)
19. 18 - 20 Amp (1989-91) Defogger
20. 18 - Blank (1992-93)
21. 19 - 20 Amp Electronic Control Suspension
22. 20 - Spare Fuses

Scheme 2

1. 1 - 10 Amp Horn
2. 2 - 10 Amp Heater Relay
3. 3 - 15 Amp Cigarette Lighter
4. 4 - 10 Amp 4 A/T
5. 5 - 10 Amp Remote Controlled Outside Mirror
6. 6 - 20 Amp Sunroof
7. 7 - 30 Amp Rear Window Defogger
8. 8 - 10 Amp E.P.S.
9. 9 - 10 Amp Meters
10. 10 - 20 Amp Wiper
11. 11 - 10 Amp Seat Belt
12. 12 - 30 Amp Heater
13. 13 - 10 Amp Back-Up Lights
14. 14 - 10 Amp Turn Signals
15. 15 - 10 Amp Stoplights
16. 16 - Spare

Scheme 3

1. 1 - 10 Amp Horn
2. 2 - 10 Amp Heater Relay
3. 3 - 15 Amp Cigarette Lighter
4. 4 - 10 Amp 4 A/T
5. 5 - 10 Amp Remote Controlled Outside Mirror
6. 6 - 20 Amp Sunroof
7. 7 - 30 Amp Rear Window Defogger
8. 8 - 10 Amp Meters
9. 9 - 15 Amp Wiper
10. 10 - 30 Amp Heater
11. 11 - 10 Amp Back-Up Lights
12. 12 - 10 Amp Turn Signals
13. 13 - 10 Amp Stoplights
14. 14 - Spare

Scheme 4

1. 1 - 30 Amp Ignition Switch
2. 2 - 50 Amp ABS
3. 3 - 30 Amp Radiator Fan
4. 4 - 40 Amp Headlights
5. 5 - 30 Amp Power Windows
6. 6 - 30 Amp ABS
7. 7 - 30 Amp Condenser Fan
8. 8 - 10 Amp Hazard
9. 9 - 20 Amp Engine
10. 10 - 10 Amp Air Conditioning
11. 11 - 10 Amp High Beam
12. 12 - 10 Amp Tail Lights
13. 13 - 10 Amp Theft
14. 14 - 15 Amp Fog Lights

Scheme 5

1. 1 - 30 Amp Engine
2. 2 - 30 Amp Power Window
3. 3 - 60 Amp ABS
4. 4 - 30 Amp Radiator Fan
5. 5 - 30 Amp Ignition Switch
6. 6 - 40 Amp Headlights
7. 7 - 10 Amp Hazard
8. 8 - 10 Amp Theft
9. 9 - 10 Amp ABS
10. 10 - 15 Amp Radio
11. 11 - 10 Amp Room Lights
12. 12 - 25 Amp Air Conditioning
13. 13 - 10 Amp Air Conditioning
14. 14 - 10 Amp High Beam
15. 15 - 15 Amp Fog Lights
16. 16 - 10 Amp Tail Lights
