Specifications Mitsubishi Galant VI

Specifications 5 illustrations ~296 words

INTRODUCTION

Use this article to quickly find specifications related to servicing and on-vehicle adjustments. This article may be used for quick reference when familiar with proper adjustment procedures and only needing a specification.

ApplicationAmp. Hr. Rating
Mirage, Pickup, Starion & Van/Wagon36
Galant40
Montero
2.6L40
3.0L57
Precis60
Sigma52

BATTERY SPECIFICATIONS

FLUID CAPACITIES

ApplicationQuantity
Automatic Transaxle (Dexron II)
Mirage13 pts. (6.2L)
Galant12.9 pts. (6.1L)
Precis12.2 pts. (5.8L)
Sigma6.1 qts. (5.8L)
Automatic Transmission (Dexron II)
Starion7.4 qts. (7.0L)
Pickup
2WD14.4 pts. (6.8L)
4WD15.2 pts. (7.2L)
Montero15.2 pts. (7.2L)
Van/Wagon14.4 pts. (6.8L)
Cooling System (Includes Heater & Reserve Tank)
Mirage5.3 qts. (5.0L)
Starion9.5 qts. (9.0L)
Galant7.6 qts. (7.2L)
Raider
2.6L8.5 qts. (8.0L)
3.0L9.5 qts. (9.0L)
Pickup
2.0L7.4 qts. (7.0L)
2.6L8.3 qts. (7.9L)
Precis5.3 qts. (5.0L)
Sigma9.7 qts. (9.2L)
Van/Wagon
Without Rear Heater8.6 qts. (8.1L)
With Rear Heater9.1 qts. (8.6L)
Crankcase (Includes Filter)
Mirage
1.5L3.5 qts. (3.3L)
1.6L4.5 qts. (4.3L)
Starion(1) 4.5 qts. (4.3L)
Galant
2.6L (SOHC)4.25 qts. (4.0L)
2.6L (DOHC)5.0 qts. (4.7L)
Montero(1) 5.0 qts. (4.7L)
Pickup
2.0L4.0 qts. (3.8L)
2.6L
2WD4.5 qts. (4.3L)
4WD5.0 qts. (4.7L)
Precis3.6 qts. (3.4L)
Sigma4.5 qts. (4.3L)
Van/Wagon4.0 qts. (3.8L)
Drive Axle (SAE 80W-90/API GL-5)
Starion2.7 pts. (1.3L)
Raider
Front2.3 pts (1.1L)
Rear
2.6L3.8 pts. (1.8L)
3.0L5.5 pts. (2.6L)
Pickup
Front2.3 pts. (1.1L)
Rear3.2 pts. (1.5L)
Van/Wagon3.2 pts. (1.5L)
Manual Transaxle (SAE 75W-85/API GL-4)
Galant3.8 pts. (1.8L)
Mirage
1.5L
4-Speed3.6 pts. (1.7L)
5-Speed3.8 pts. (1.8L)
1.6L
KM2063.8 pts. (1.8L)
KM2104.4 pts. (2.1L)
Precis2.2 qts. (2.1L)
Sigma2.6 qts. (2.5L)
Manual Transmission (SAE 75W-85/API GL-4)
Starion2.4 pts. (2.3L)
Montero
2.6L4.7 pts. (2.2L)
3.0L5.3 pts. (2.5L)
Pickup
2WD4.9 pts. (2.3L)
4WD4.7 pts. (2.2L)
Power Steering (Dexron II)
Mirage1.9 pts. (.9L)
Starion1.2 qts. (1.1L)
Galant1.9 pts. (.9L)
Montero2.2 pts. (1.04L)
Pickup1.9 pts. (.9L)
Precis1.7 pts. (.8L)
Sigma1.9 pts. (.9L)
Van/Wagon1.9 pts. (.9L)
Transfer Case (SAE 75W-85/API GL-4)4.7 pts. (2.2L)
(1) Add .5 qt. (.4L) with oil cooler.
(1)Add .5 qt. (.4L) with oil cooler.

FLUID CAPACITIES

REPLACEMENT INTERVALS

ComponentInterval (Miles)
Mirage
Air Filter30,000
Automatic Transaxle Fluid30,000
Belts30,000
Coolant30,000
Fuel & Vapor Hoses50,000
Oil & Filter
Non-Turbocharged7,500
Turbocharged5,000
Spark Plugs30,000
Timing Belt60,000
Starion
Air Filter30,000
Automatic Transmission Fluid30,000
Belts30,000
Coolant30,000
Fuel Filter50,000
Fuel & Vapor Hoses50,000
Oil & Filter5,000
Rear Axle Fluid30,000
Spark Plugs30,000
Galant
Air Filter30,000
Automatic Transaxle Fluid30,000
Belts30,000
Coolant30,000
Fuel & Vapor Hoses50,000
Oil & Filter7,500
Spark Plugs30,000
Timing & Balance Shaft Belts60,000
Montero
Air Filter30,000
Automatic Transmission Fluid30,000
Belts30,000
Coolant30,000
Front & Rear Axle Fluid30,000
Fuel Filter50,000
Fuel & Vapor Hoses50,000
Oil & Filter7,500
Spark Plugs30,000
Timing Belt60,000
Transfer Case Fluid30,000
Pickup
Air Filter30,000
Belts30,000
Coolant30,000
Front & Rear Axle Fluid30,000
Fuel Filter50,000
Fuel & Vapor Hoses50,000
Oil & Filter7,500
Spark Plugs30,000
Timing Belt60,000
Precis
Air Filter30,000
Belts30,000
Brake Fluid30,000
Coolant30,000
Fuel Filter50,000
Fuel & Vapor Hoses50,000
Oil & Filter7,500
O2 Sensor50,000
Spark Plugs30,000
Timing Belt60,000
Transaxle Fluid30,000
Sigma
Air Filter30,000
Automatic Transaxle Fluid30,000
Belts30,000
Coolant30,000
Fuel & Vapor Hoses50,000
Oil & Filter7,500
Spark Plugs30,000
Timing & Balance Shaft Belts60,000
Van/Wagon
Air Filter30,000
Belts30,000
Coolant30,000
EGR Valve (1)50,000
Fuel & Vapor Hoses50,000
Oil & Filter7,500
O2 Sensor (1)50,000
Spark Plugs30,000
Spark Plug Wires (1)60,000
Timing Belt60,000
Vapor Canister100,000
(1) Federal models only.
(1)Federal models only.

REPLACEMENT INTERVALS

BELT ADJUSTMENT

Application(1) Deflection: In. (mm)
Mirage
1.5L.22-.28 (5.6-7.1)
1.6L.28-.34 (7.1-8.6)
Starion.28-.39 (7.1-9.9)
Galant.28-.34 (7.1-8.6)
Montero
2.6L.35-.47 (8.9-11.9)
3.0L.26-.32 (6.6-8.1)
Pickup
2.0L.28-.39 (7.1-9.9)
2.6L.35-.47 (8.9-11.9)
Precis
A/C Belt.32-.40 (8.1-10.2)
Alternator Belt.28-.32 (7.1-8.1)
Sigma.16-.20 (4.1-5.1)
Van/Wagon.28-.40 (7.1-10.2)
(1) Deflection with 22 lbs. (10 kg) pressure applied midway on belt run.
(1)Deflection with 22 lbs. (10 kg) pressure applied midway on belt run.

BELT ADJUSTMENT

COMPRESSION SPECS

ApplicationSpecification
Compression Ratio
1.5L (VIN J)9.4:1
1.5L (VIN X)9.4:1
1.6L (VIN Y)9.2:1
1.6L Turbo (VIN Z)8.0:1
1.8L (VIN T)9.0:1
2.0L (VIN V)8.5:1
2.0L DOHC (VIN R)9.0:1
2.4L (VIN W)8.5:1
2.6L (VIN E)8.7:1
2.6L Turbo (VIN N)7.0:1
3.0L (VIN S)8.9:1
Compression Pressure
1.5L (VIN J)164 psi (11.3 kg/cm 2 )
1.5L (VIN X)137 psi (9.6 kg/cm 2 )
1.6L (VIN Y)171 psi (12.0 kg/cm 2 )
1.6L (VIN Z) Turbo149 psi (10.5 kg/cm 2 )
1.8L (VIN T)131 psi (9.2 kg/cm 2 )
2.0L (VIN R) DOHC (Galant)137 psi (9.6 kg/cm 2 )
2.0L (VIN V) SOHC, 2.4L, 2.6L & 3.0L119 psi (8.4 kg/cm 2 )
2.6L (VIN N) Turbo142 psi (10.0 kg/cm 2 )
Maximum Variation Between Cylinders14 psi (1.0 kg/cm 2 )

COMPRESSION SPECIFICATIONS

VALVE CLEARANCE SPECS

Note. Valve adjustment is required only on engines equipped with mechanical valve lifters.

ApplicationLifter Type
1.5L (Mirage & Precis)Mechanical
1.6L (Mirage)Hydraulic
2.0L
GalantHydraulic
Pickup(1) Hydraulic & Mechanical
2.4L (Van/Wagon)Hydraulic
2.6L (Montero, Pickup, & Starion)(1) Hydraulic & Mechanical
3.0L (Montero & Sigma)Hydraulic
(1) Intake and exhaust valves have hydraulic lifters. Jet valves have mechanical lifters.
(1)Intake and exhaust valves have hydraulic lifters. Jet valves have mechanical lifters.

VALVE LIFTER APPLICATION

ApplicationIn. (mm)
Hot Engine
Jet (1).010 (.25)
Intake.006 (.15)
Exhaust.010 (.25)
Cold Engine
Jet (1).007 (.17)
Intake.003 (.07)
Exhaust.007 (.17)
(1) Adjust jet valve with intake valve fully loosened.
(1)Adjust jet valve with intake valve fully loosened.

VALVE CLEARANCE SPECIFICATIONS

4-CYL VALVE ARRANGEMENT

Note. Right and left sides refer to engine, as viewed from flywheel.

1.5L (VIN X), 1.6L, 1.8L, 2.0L (VIN R & V) & 2.4L

  1. Right Side - Exhaust valves.
  2. Left Side - Intake valves.

1.5L (VIN J), 2.0L (VIN D) & 2.6L

  1. Right Side - Exhaust valves.
  2. Left Side - Intake & jet valves.

Left Side

  1. E-I-E-I-E-I (Front-to-rear).

Right Side

  1. I-E-I-E-I-E (Front-to-rear).

IGNITION COIL

ApplicationPrimarySecondary
1.5L (VIN J)1.1-1.311,600-15,800
1.5L (VIN X).72-.8810,300-13,900
1.6L (VIN Y & Z) (1).77-.9510,300-13,900
1.8L (VIN T).72-.8810,300-13,900
2.0L (VIN R) (1).77-.9510,300-13,900
2.0L (VIN V).72-.8810,800-13,200
2.4L (VIN W).72-.8810,300-13,900
2.6L (VIN E)
Montero1.1-1.314,500-19,500
Pickup1.1-1.322,100-29,900
2.6L (VIN N)1.12-1.389,400-12,700
3.0L (VIN S).72-.8810,300-13,900
(1) Distributorless ignition.
(1)Distributorless ignition.

IGNITION COIL RESISTANCE - Ohms @ 68°F (20°C)

IGNITION COIL RESISTOR

ApplicationOhms
1.5L (VIN J)1.2-1.6
2.6L (VIN N & E)1.22-1.48

IGNITION COIL RESISTOR RESISTANCE @ 68°F (20°C)

PICK-UP COIL

ApplicationIn. (mm)
Montero 2.6L.031 (.8)
Pickup
2.0L.008-.015 (.2-.4)
2.6L.031 (.8)
Precis.031 (.8)
(1) Information not available for engines not listed.
(1)Information not available for engines not listed.

PICK-UP COIL AIR GAP (1)

ApplicationOhms
2.0L (VIN D)140-180
2.6L (VIN N)920-1120
(1) Information not available for engines not listed.
(1)Information not available for engines not listed.

PICK-UP COIL RESISTANCE (1)

HIGH TENSION WIRE RESISTANCE

ApplicationOhms
1.5L (VIN J)N/A
1.5L (VIN X)
Coil Wire3,000
No. 1 Wire10,000
No. 2 Wire12,000
No. 3 Wire11,000
No. 4 Wire13,000
1.6L (VIN Y & Z)
Coil WireNot Used
No. 1 Wire5,800
No. 2 Wire8,400
No. 3 Wire10,600
No. 4 Wire9,700
1.8L (VIN T)
Coil Wire3,000
No. 1 Wire11,000
No. 2 Wire12,000
No. 3 Wire12,000
No. 4 Wire14,000
2.0L (VIN V)
Coil Wire2,700
No. 1 Wire10,100
No. 2 Wire11,800
No. 3 Wire13,100
No. 4 Wire13,000
2.4L (VIN W)
Coil Wire3,000
No. 1 Wire10,000
No. 2 Wire12,000
No. 3 Wire12,000
No. 4 Wire14,000
2.6L (VIN N)
Pickup & Starion
Coil Wire10,000
No. 1 Wire10,000
No. 2 Wire12,000
No. 3 Wire13,000
No. 4 Wire15,000
Montero
Coil Wire7,000
No. 1 Wire9,000
No. 2 Wire11,000
No. 3 Wire13,000
No. 4 Wire14,000
3.0L (VIN S)
Montero
Coil Wire3,000
No. 1 Wire9,000
No. 2 Wire8,500
No. 3 Wire10,000
No. 4 Wire9,000
No. 5 Wire12,000
No. 6 Wire10,000
Sigma
Coil Wire5,800
No. 1 Wire7,400
No. 2 Wire5,400
No. 3 Wire9,100
No. 4 Wire6,900
No. 5 Wire10,200
No. 6 Wire8,000

HIGH TENSION WIRE RESISTANCE

SPARK PLUGS

ApplicationNippondenso No.
1.5L (VIN J)(1) RN9YC4
1.5L (VIN X)W20EPR-11
1.6L (VIN Y)W20EPR-11
1.6L (VIN Z)W20EPR
1.8L (VIN T)W20EPR-11
2.0L (VIN V)W20EPR-11
2.4L (VIN W)P20PR-11
2.6L (VIN N)W22EPR-S11
3.0L (VIN S)
MonteroW16EPR-11
SigmaP16PR-11
(1) Champion spark plug.
(1)Champion spark plug.

SPARK PLUG TYPE

ApplicationGap: In. (mm)Torque: Ft. Lbs. (N.m)
1.5L (VIN J).039-.043 (1.0-1.1)15-21 (20-30)
1.5L (VIN X).039-.043 (1.0-1.1)15-21 (20-30)
1.6L (VIN Y).039-.043 (1.0-1.1)15-21 (20-30)
1.6L (VIN Z).028-.031 (.7-.8)15-21 (20-30)
1.8L (VIN T).039-.043 (1.0-1.1)15-21 (20-30)
2.0L (VIN V).039-.043 (1.0-1.1)15-21 (20-30)
2.4L (VIN W).039-.043 (1.0-1.1)15-21 (20-30)
2.6L (VIN N).039-.043 (1.0-1.1)15-21 (20-30)
3.0L (VIN S).039-.043 (1.0-1.1)15-21 (20-30)

SPARK PLUG SPECIFICATIONS

FIRING ORDER

WARNINGOn the 3.0L V6, the firing order and the spark plug connection order on the top of the distributor do not match. Circuits internal to the distributor cap differ from the external spark plug wire connections. This is intentional and is done to avoid spark plug wires crossover. (Scheme 4)

1.5L, 1.8L, 2.0L & 2.4L Firing Order & Distributor Rotation. Scheme 1

Scheme 1: 1.5L, 1.8L, 2.0L & 2.4L Firing Order & Distributor Rotation
Scheme 1: 1.5L, 1.8L, 2.0L & 2.4L Firing Order & Distributor Rotation

1.6L & 2.0L DOHC Firing Order. Scheme 2

Scheme 2: 1.6L & 2.0L DOHC Firing Order
Scheme 2: 1.6L & 2.0L DOHC Firing Order

2.6L Firing Order & Distributor Rotation. Scheme 3

Scheme 3: 2.6L Firing Order & Distributor Rotation
Scheme 3: 2.6L Firing Order & Distributor Rotation

3.0L (Montero) Firing Order & Distributor Rotation. Scheme 4

Scheme 4: 3.0L (Montero) Firing Order & Distributor Rotation
Scheme 4: 3.0L (Montero) Firing Order & Distributor Rotation

3.0L (Sigma) Firing Order & Distributor Rotation. Scheme 5

Scheme 5: 3.0L (Sigma) Firing Order & Distributor Rotation
Scheme 5: 3.0L (Sigma) Firing Order & Distributor Rotation

IGNITION TIMING

Application(1) Basic(2) (3) Actual
1.5L
Precis
Federal5 @ 650-850N/A
California3 @ 650-850N/A
Mirage5 @ 650-85015 @ 650-850
1.6L (Mirage)5 @ 650-8508 @ 650-850
2.0L (Galant & Pickup)5 @ 600-800(4) 10 @ 600-800
2.4L (Van/Wagon)5 @ 650-8508 @ 650-850
2.6L
Starion10 @ 750-95015 @ 750-950
Montero & Pickup7 @ 750-95012 @ 750-950
3.0L (Montero & Sigma)5 @ 600-80015 @ 600-800
(1) With ignition timing adjustment connector grounded or vacuum hose (farthest from dist.) disconnected. (2) With ignition timing adjustment connector ungrounded or vacuum hose (farthest from dist.) connected. Ignition timing may fluctuate. (3) If vehicle altitude is more than 2300 ft. above sea level, actual timing may be advanced. (4) Dual Overhead Camshaft (DOHC) is 12 degrees.
(1)With ignition timing adjustment connector grounded or vacuum hose (farthest from dist.) disconnected.
(2)With ignition timing adjustment connector ungrounded or vacuum hose (farthest from dist.) connected. Ignition timing may fluctuate.
(3)If vehicle altitude is more than 2300 ft. above sea level, actual timing may be advanced.
(4)Dual Overhead Camshaft (DOHC) is 12 degrees.

IGNITION TIMING (Degrees BTDC @ RPM)

ApplicationCentrifugal Degrees @ RPMVacuum Degrees @ In. Hg
Starion
2.6L0 @ 12000 @ 3.15
2.6L10 @ 200012 @ 5.91
2.6L33 @ 600023 @ 11.01
Montero
2.6L (2)0 @ 16000 @ 3.15
2.6L9 @ 28008 @ 5.91
2.6L19 @ 600020 @ 14.17
Pickup
2.0L
California Models (2)
Man. Trans.0 @ 12000 @ 3.15
Man. Trans.12 @ 280012 @ 5.91
Man. Trans.20 @ 600023 @ 11.01
Auto. Trans.0 @ 12000 @ 3.15
Auto. Trans.12 @ 28008 @ 5.91
Auto. Trans.20 @ 600020 @ 14.17
Federal Models
Man. Trans.0 @ 12000 @ 3.15
Man. Trans.12 @ 280012 @ 5.91
Man. Trans.20 @ 600023 @ 11.01
Auto. Trans.0 @ 12000 @ 3.15
Auto. Trans.12 @ 28008 @ 5.91
Auto. Trans.20 @ 600020 @ 14.17
Precis
1.5L0 @ 15000 @ 3.15
1.5L5 @ 2500N/A
1.5L16 @ 6000(3) 23 @ 14.17
(1) Advance specifications for models not listed are computer controlled. (2) Idle advance on Calif. and High Alt. models is zero degrees @ 2.36 in. Hg and 5 degrees @ 3.15 in. Hg. (3) Vacuum advance on Federal man. trans. models is 23 degrees @ 11.02 in. Hg.
(1)Advance specifications for models not listed are computer controlled.
(2)Idle advance on Calif. and High Alt. models is zero degrees @ 2.36 in. Hg and 5 degrees @ 3.15 in. Hg.
(3)Vacuum advance on Federal man. trans. models is 23 degrees @ 11.02 in. Hg.

DISTRIBUTOR ADVANCE SPECIFICATIONS (1)

FUEL PUMP (CARBURETED)

ApplicationPressure psi (kg/cm 2 )Volume in one min. Pts. (L)
Montero 2.6L2.8-4.2 (.20-.29)N/A
Pickup
2.0L2.7-3.7 (.19-.26)N/A
2.6L2.8-4.2 (.20-.29)N/A
Precis2.8-3.6 (.20-.25)1.7 (.80)

FUEL PUMP SPECIFICATIONS

FUEL PUMP (FUEL INJECTED)

ApplicationAt Idle w/Vacuum psi (kg/cm 2 )At Idle w/o Vacuum psi (kg/cm 2 )
Starion35-38 (2.5-2.7)47-50 (3.3-3.5)
Montero
3.0L38 (2.7)147-53 (3.3-3.5)
All Other Models38 (2.7)47-50 (3.3-3.5)

REGULATED FUEL PRESSURE

INJECTOR RESISTANCE

ApplicationOhms
Galant, Montero & Van/Wagon13-16
Starion2-3
Mirage
1.5L13-16
1.6L2-3
Sigma15-17

INJECTOR RESISTANCE SPECIFICATIONS

IDLE SPEED & MIXTURE

ApplicationIdle RPMCO %
Montero 2.6L700-900.1-.3
Pickup
2.0L650-850.1-.3
2.6L700-900.1-.3
Precis650-850.1-.3
(1) Idle speed and mixture are computer controlled on fuel injected models.
(1)Idle speed and mixture are computer controlled on fuel injected models.

IDLE SPEED & CO LEVEL SPECIFICATIONS (1)

FAST IDLE SPEED

ApplicationEngine RPM
Montero (2.6L)2350
Pickup
2.0L2500
2.6L2350
Precis
Automatic Transmission2700
Manual Transmission2800
(1) Fast idle speed is computer controlled on fuel injected models.
(1)Fast idle speed is computer controlled on fuel injected models.

FAST IDLE SPEED (1)

DASHPOT SPECIFICATION

ApplicationRPM
Montero (2.6L)2000
Pickup
Automatic Transmission1500
Manual Transmission2000
Precis1800

DASHPOT RPM SPECIFICATIONS

ApplicationRPM
Montero (2.6L)
A/C Compressor Load900-950
Pickup
A/C Compressor Load850-950
Precis
A/C Compressor Load850-900
Electrical & Power Steering Load750-950

THROTTLE OPENER SPECIFICATIONS

THROTTLE POSITION SENSOR (TPS)

ApplicationVolts At Idle
Galant, Mirage, Sigma, Starion & Van/Wagon.48-.52
Montero
2.6L.25
3.0L.4-1.0
Pickup.25
Precis.25

TPS SPECIFICATIONS
