Caster adjustment. To adjust caster, lengthen or shorten strut rod as shown. Scheme 1
Scheme 1: Caster adjustment. To adjust caster, lengthen or shorten strut rod as shown.
Camber adjustment. Rotate pivot shaft or add shims to adjust camber angle. Scheme 2
Scheme 2: Camber adjustment. Rotate pivot shaft or add shims to adjust camber angle.
Caster adjustment. Disconnect upper control arm and rotate shaft to obtain desired caster adjustment. Scheme 3
Scheme 3: Caster adjustment. Disconnect upper control arm and rotate shaft to obtain desired caster adjustment.
Camber adjustment. Adjust caster first (turn upper shaft). Then to adjust camber change shims. Scheme 4
Scheme 4: Camber adjustment. Adjust caster first (turn upper shaft). Then to adjust camber change shims.
Toe adjustment. To adjust, turn eccentric to desired setting. Scheme 5
Scheme 5: Toe adjustment. To adjust, turn eccentric to desired setting.
| Application | Specification |
|---|
| Front (Scheme 1) |
| Camber in Degrees |
| Fraction | 7/16 +/- 1/2 |
| Decimal | .438 +/- .5 |
| Caster in Degrees |
| Fraction | 3/4 +/- 1/2 |
| Decimal | .75 +/- .5 |
| Toe-In in Inches |
| Fraction | 0 +/- 1/8 |
| Decimal | 0 +/- .13 |
| Toe-In in Degrees |
| Fraction | 0 +/- 1/4 |
| Decimal | 0 +/- .25 |
| Toe-Out in Turns |
| Inner | 37 3/4° |
| Outer | 30 11/16° |
| Steering Axis Inclination (SAI) | (1) |
| Rear |
| Camber in Degrees |
| Fraction | 3/8 |
| Decimal | .375 |
| Caster in Degrees |
| Fraction | N/A |
| Decimal | N/A |
| Toe-In in Inches |
| Fraction | 0 |
| Decimal | 0 |
| Toe-In in Degrees |
| Fraction | 0 |
| Decimal | 0 |
| Toe-Out in Turns |
| Inner | N/A |
| Outer | N/A |
| Steering Axis Inclination (SAI) | N/A |
| (1) Information not available. |
| (1) | Information not available. |
WHEEL ALIGNMENT SPECIFICATIONS (CORDIA & TREDIA)
| Application | Specification |
|---|
| Front |
| Camber in Degrees |
| Fraction | 0 +/- 1/8 |
| Decimal | 0 +/- .5 |
| Caster in Degrees |
| Fraction | 3/4 +/- 1/2 |
| Decimal | .75 +/- .5 |
| Toe-In in Inches |
| Fraction | 0 +/- 1/8 |
| Decimal | 0 +/- .13 |
| Toe-In in Degrees |
| Fraction | 0 +/- 1/4 |
| Decimal | 0 +/- .25 |
| Toe-Out in Turns |
| Inner | 41 7/8° |
| Outer | 31 3/4° |
| Steering Axis Inclination (SAI) | (1) |
| Rear |
| Camber in Degrees |
| Fraction | 11/16 |
| Decimal | .687 |
| Caster in Degrees |
| Fraction | N/A |
| Decimal | N/A |
| Toe-In in Inches |
| Fraction | N/A |
| Decimal | N/A |
| Toe-In in Degrees |
| Fraction | N/A |
| Decimal | N/A |
| Toe-Out in Turns |
| Inner | 37 1/2° |
| Outer | 31 3/4° |
| Steering Axis Inclination (SAI) | N/A |
| (1) Information not available. |
| (1) | Information not available. |
WHEEL ALIGNMENT SPECIFICATIONS (MIRAGE)
| Application | Specification |
|---|
| Front ( (Scheme 2)& 3) |
| Camber in Degrees |
| Fraction | 1 +/- 1/2 |
| Decimal | 1.0 +/- .5 |
| Caster in Degrees |
| Fraction | 2 15/16 +/- 1/2 |
| Decimal | 2.938 +/- .5 |
| Toe-In in Inches |
| Fraction | 7/32 +/- 1/8 |
| Decimal | .22 +/- .13 |
| Toe-In in Degrees |
| Fraction | 7/16 +/- 1/4 |
| Decimal | .44 +/- .13 |
| Toe-Out in Turns |
| Inner | 32 1/2° |
| Outer | 29° |
| Steering Axis Inclination (SAI) | 9° |
WHEEL ALIGNMENT SPECIFICATIONS (MONTERO)
| Application | Specification |
|---|
| Front |
| Camber in Degrees |
| Fraction | 1/2 +/- 1/2 |
| Decimal | .5 +/- .5 |
| Caster in Degrees |
| Fraction | 11/16 +/- 1/2 |
| Decimal | .687 +/- .5 |
| Toe-In in Inches |
| Fraction | 0 +/- 1/8 |
| Decimal | 0 +/- .13 |
| Toe-In in Degrees |
| Fraction | 0 +/- 1/4 |
| Decimal | 0 +/- .25 |
| Toe-Out in Turns |
| Inner | 37 1/8° |
| Outer | 30 9/16° |
| Steering Axis Inclination (SAI) | (1) |
| (1) Information not available. |
| (1) | Information not available. |
WHEEL ALIGNMENT SPECIFICATIONS (GALANT)
| Application | Specification |
|---|
| Front ( (Scheme 3)& (Scheme 4) ) |
| Camber in Degrees |
| Fraction | 1 +/- 1/2 |
| Decimal | 1.0 +/- .5 |
| Caster in Degrees |
| Fraction | 2 1/2 +/- 1 |
| Decimal | 2.5 +/- 1.0 |
| Toe-In in Inches |
| Fraction | 7/32 +/- 3/16 |
| Decimal | .22 +/- .19 |
| Toe-In in Degrees |
| Fraction | 7/16 +/- 3/8 |
| Decimal | .44 +/- .38 |
| Toe-Out in Turns |
| Inner | 37° |
| Outer | 30 1/2° |
| Steering Axis Inclination (SAI) | 9° |
WHEEL ALIGNMENT SPECIFICATIONS (PICKUP - 2WD)
| Application | Specification |
|---|
| Front ( (Scheme 2)& (Scheme 3) ) |
| Camber in Degrees |
| Fraction | 1 +/- 1/2 |
| Decimal | 1.0 +/- .5 |
| Caster in Degrees |
| Fraction | 2 +/- 1 |
| Decimal | 2.0 +/- 1.0 |
| Toe-In in Inches |
| Fraction | 7/32 +/- 3/16 |
| Decimal | .22 +/- .19 |
| Toe-In in Degrees |
| Fraction | 7/16 +/- 3/8 |
| Decimal | .44 +/- .38 |
| Toe-Out in Turns |
| Inner | 30 3/4° |
| Outer | 28° |
| Steering Axis Inclination (SAI) | 9° |
WHEEL ALIGNMENT SPECIFICATIONS (PICKUP - 4WD)
| Application | Specification |
|---|
| Front (Scheme 1) |
| Camber in Degrees |
| Fraction | 1/2 |
| Decimal | .5 |
| Caster in Degrees |
| Fraction | 5 1/8 |
| Decimal | 5.875 |
| Toe-In in Inches |
| Fraction | 0 +/- 1/32 |
| Decimal | 0 +/- .03 |
| Toe-In in Degrees |
| Fraction | 0 +/- 1/16 |
| Decimal | 0 +/- .02 |
| Toe-Out in Turns |
| Inner | (1) |
| Outer | (1) |
| Steering Axis Inclination (SAI) | (1) |
| Rear (Scheme 5) |
| Camber in Degrees |
| Fraction | 0 |
| Decimal | 0 |
| Caster in Degrees |
| Fraction | N/A |
| Decimal | N/A |
| Toe-In in Inches |
| Fraction | 0 +/- 1/32 |
| Decimal | 0 +/- .03 |
| Toe-In in Degrees |
| Fraction | 0 +/- 1/16 |
| Decimal | 0 +/- .02 |
| Toe-Out in Turns |
| Inner | N/A |
| Outer | N/A |
| Steering Axis Inclination (SAI) | N/A |
| (1) Information not available. |
| (1) | Information not available. |
WHEEL ALIGNMENT SPECIFICATIONS (STARION)
