VACUUM HOSE INSTALLATION

  1. When connecting the vacuum hoses, they should be securely inserted onto the nipples.
  2. Connect the hoses correctly, using the VACUUM HOSE ROUTING diagram as a guide. See «VACUUM CIRCUIT DIAGRAM»(ref-282563-S09429113902008040300000) .

>> A << EGR VALVE GASKET INSTALLATION

Install the EGR valve gasket as shown in the illustration.

Scheme 20

Scheme 20: >> A << EGR VALVE GASKET INSTALLATION

Scheme 21

Scheme 21: REMOVAL AND INSTALLATION < 3.8L ENGINE >

Install the EGR valve gasket as shown in the illustration.

Scheme 22

Scheme 22: >> A << EGR VALVE GASKET INSTALLATION

Scheme 23

Scheme 23: REMOVAL AND INSTALLATION

Scheme 24

Scheme 24: EVAPORATIVE EMISSION VENTILATION SOLENOID CHECK

Scheme 25

Scheme 25
  1. Connect a hand vacuum pump to nipple (A) of the solenoid.
  2. Check air tightness by applying a vacuum with voltage applied directly from the battery to the evaporative emission ventilation solenoid and without applying voltage. BATTERY POSITIVE VOLTAGE DESCRIPTION BATTERY VOLTAGE NORMAL CONDITION Applied Vacuum maintained Not applied Vacuum leaks
  3. Measure the resistance between the terminals of the solenoid. Standard value: 17-21 ohms [at 20°C (68°F)]
