ENGINE COOLANT LEAK CHECK

WARNING

When pressure testing the cooling system, slowly release cooling system pressure to avoid getting burned by hot coolant.

CAUTION

Be sure to completely clean away any moisture from the places checked. When the tester is taken out, be careful not to spill any coolant. Be careful when installing and removing the tester and when testing not to deform the filler neck of the radiator.

Scheme 33

Check that the coolant level is up to the filler neck. Install a radiator tester and apply 160 kPa (23 psi) pressure, and then check for leakage from the radiator hose or connections.
If there is leakage, repair or replace the appropriate part.

RADIATOR CAP PRESSURE CHECK

Note. Be sure that the cap is clean before testing. Rust or other foreign material on the cap seal will cause an improper reading.

Scheme 34

Scheme 34: RADIATOR CAP PRESSURE CHECK

Use a cap adapter to attach the cap to the tester.
Increase the pressure until the indicator of the gauge stops moving. Minimum limit: 83 kPa (12 psi) Standard value: 93 - 123 kPa (14 - 18 psi)
Replace the radiator cap if the reading does not remain at or above the limit.

FAN CONTROL RELAY CONTINUITY CHECK

BATTERY VOLTAGE	TERMINAL NO. TO BE CONNECTED TO TESTER	CONTINUITY TEST RESULTS
Not applied	4-2	Open circuit
Connect terminal No. 3 and battery (-) terminal. Connect terminal No. 1 and battery (+) terminal.	4-2	Less than 2 ohms

FAN CONTROL RELAY BATTERY VOLTAGE AND CONTINUITY TEST RESULTS

Scheme 35

RADIATOR FAN RELAY CHECK

BATTERY VOLTAGE	TERMINAL NO. TO BE CONNECTED TO TESTER	CONTINUITY TEST RESULTS
Not applied	2-4	Less than 2 ohms
Not applied	2-5	Open circuit
Connect terminal No. 3 and battery (-) terminal. Connect terminal No. 1 and battery (+) terminal.	2-5	Less than 2 ohms

RADIATOR FAN RELAY BATTERY VOLTAGE AND CONTINUITY TEST RESULTS

Scheme 36

Scheme 37

Scheme 37: RADIATOR FAN MOTOR CHECK

Remove the radiator fan motor connector.
Check to see that the fan motor of the radiator turns when applying battery power between the connector terminals of the radiator fan motor. Also check to see that there is no abnormal sound coming from the radiator fan motor at this time.
If the radiator fan motor is defective, replace it.

Scheme 38

Scheme 38: < 2.4L ENGINE >

Scheme 39

Scheme 39: < 3.8L ENGINE >

<< A >> RADIATOR UPPER HOSE/RADIATOR LOWER HOSE DISCONNECTION

Make mating marks on the radiator hose and the hose clamp. Disconnect the radiator hose.

Scheme 40

Scheme 40: << A >> RADIATOR UPPER HOSE/RADIATOR LOWER HOSE DISCONNECTION

<< A >> RADIATOR LOWER HOSE DISCONNECTION

Make mating marks on the radiator hose and the hose clamp. Disconnect the radiator hose.

Scheme 41

Scheme 41: << A >> RADIATOR LOWER HOSE DISCONNECTION

<< A >> RADIATOR UPPER HOSE DISCONNECTION

After making mating marks on the radiator hose and hose clamp, disconnect the radiator hose.

Scheme 42

Scheme 42: << A >> RADIATOR UPPER HOSE DISCONNECTION

After making mating marks on the radiator hose and hose clamp, disconnect the radiator hose.

Scheme 43

Scheme 43: << A >> RADIATOR UPPER HOSE DISCONNECTION

Water Pipe and Hose Check

Check the water pipe and hose for cracks, damage and clogs. Replace them if necessary.

< 2.4L ENGINE >

ITEM	SPECIFIED SEALANT
Cylinder block drain plug	3M™ AAD Part No. 8731 or equivalent
Thermostat case	3M™ AAD Part No. 8672, 3M™ AAD Part No.8679/8678 or equivalent
Water outlet fitting
Thermostat case bolt	3M™ AAD Part No. 8730, 8731 or equivalent

SEALANTS SPECIFICATIONS

< 3.8L ENGINE >

ITEM	SPECIFIED SEALANT
Cylinder block drain plug	3M™ AAD Part No. 8731 or equivalent
Engine coolant temperature sensor	3M™ AAD Part No. 8731 or equivalent
