Remote Controlled Mirror Operation
- The mirror on the door mirror moves up/down and left/right by operating the remote controlled door mirror switch when the ignition switch is in the "ON" or "ACC" position.
- The rear window defogger relay switch is activated (ON) by turning on the A/C-ECU built-in rear window defogger switch when the ignition switch is in the "ON" position. When the rear window defogger relay is turned ON, power is supplied to the rear window defogger and door mirror, and the heater of the door mirror (heated door mirror) starts operations. The rear window defogger comes with a timer function and will automatically turn OFF the switch approximately 16 minutes after the rear window defogger switch is turned ON. The heated door mirror operations are also terminated along with the rear window defogger, at this time.
CIRCUIT OPERATION
If both of the door mirror heaters do not operate normally it may be due to a malfunction in the rear window defogger system.
If either of the heated door mirrors do not operate normally, it may be due to malfunctions in the heated door mirror circuit or door mirror.
ELECTRIC REMOTE CONTROL MIRROR OPERATION CHECK
Check that the mirror moves as described in the table when each terminal is connected to the battery.
Scheme 1
| Battery connection | Direction operation |
|---|---|
| Connect terminal 6 to the negative battery terminal. Connect terminal 4 to the positive battery terminal. | Up |
| Connect terminal 6 to the positive battery terminal. Connect terminal 4 to the negative battery terminal. | Down |
| Connect terminal 6 to the negative battery terminal. Connect terminal 5 to the positive battery terminal. | Right |
| Connect terminal 6 to the positive battery terminal. Connect terminal 5 to the negative battery terminal. | Left |
BATTERY CONNECTION REFERENCE
| Switch position | Tester connection | Specified condition | |
|---|---|---|---|
| OFF | 9 - 2, 9 - 3, 9 - 6, 9 - 10, 9 - 11, 1 - 2, 1 - 3, 1 - 6, 1 - 10, 1 - 11 | Open circuit | |
| Left side | OFF | 9 - 6, 9 - 10, 9 - 11, 1 - 6, 1 - 10, 1 - 11 | Open circuit |
| Up | 1 - 6, 9 - 11 | Less than 2 ohms | |
| Down | 1 - 11, 6 - 9 | ||
| Right | 1 - 6, 9 - 10 | ||
| Left | 1 - 10, 6 - 9 | ||
| Right side | OFF | 9 - 2, 9 - 3, 9 - 6, 1 - 2, 1 - 3, 1 - 6 | Open circuit |
| Up | 1 - 6, 3 - 9 | Less than 2 ohms | |
| Down | 1 - 3, 6 - 9 | ||
| Right | 1 - 6, 2 - 9 | ||
| Left | 1 - 2, 6 - 9 | ||
CONTINUITY SPECIFICATION
Scheme 2
| CAUTION | When relocating the car between locations with extremely different temperatures (warm and cold), leave the car in the location for a while to adapt to the temperature prior to checking it. |
Check to see that the resistance shown in the graph is almost satisfied when measuring the resistance of terminal 1 and 3 of the door mirror connectors.
