SPECIAL TOOL

SPECIAL TOOLS DESCRIPTION CHART TOOL TOOL NUMBER AND NAME SUPERSESSION APPLICATION MB991958 MB991824 MB991827 MB991910 MB991911 MB991914 MB991825 MB991826 M.U.T.-III sub assembly Vehicle communication interface (V.C.I.) M.U.T.-III USB cable M.U.T.-III main harness A (Vehicles with CAN communication system) M.U.T.-III main harness B (Vehicles without CAN communication system) M.U.T.-III main harness C (for Daimler Chrysler models only) M.U.T.-III adapter harness M.U.T.-III trigger harness MB991824-KIT NOTE: G: MB991826 M.U.T.-III trigger harness is not necessary when pushing V.C.I. ENTER key. CAUTION: For vehicles with CAN communication, use M.U.T.-III main harness A to send simulated vehicle speed. If you connect M.U.T.-III main harness B instead, the CAN communication does not function correctly. Checking diagnostic trouble codes

Scheme 3

Scheme 3: SPECIAL TOOL

Scheme 4

Scheme 4: REMOVAL AND INSTALLATION

Scheme 5

Scheme 5: >>A << ACCELERATOR STOPPER INSTALLATION
  1. Insert the accelerator stopper straight into the stud bolt of the floor.
  2. Install the accelerator stopper securely by turning it clockwise until its underside contacts with the body bracket as shown in the figure.
  3. After the installation, slightly pull the accelerator stopper by hand to check that it cannot be removed easily (appropriate holding power: 100N or more).
