Engine Lubrication: Component Locations Mitsubishi Eclipse IV facelift

SPECIAL TOOLS

SPECIAL TOOLS TOOL TOOL NUMBER AND NAME SUPERSESSION APPLICATION MB991610 Oil filter wrench General service tool Removal and installation of engine oil filter (when using oil filter MD356000) MD998012 Engine oil pressure switch wrench General service tool Removal and installation of engine oil pressure switch

Scheme 7

Scheme 8

Scheme 9

1. Pull out the oil dipstick slowly and check that the oil level is within the marks on the oil dipstick.
2. Check that the oil is not excessively dirty, that there is no coolant or gasoline mixed in, and that it is sufficiently thick and slippery.

Scheme 10

Scheme 11

Scheme 12

1. Start the engine and allow it to warm up until the temperature of the coolant reaches 80 - 90°C (176 - 194°F). WARNING: Use care as oil could be hot.
2. Remove the engine oil filler cap.
3. Remove the drain plug to drain oil.
4. Install a new drain plug gasket so that it faces in the direction shown in the illustration, and then tighten the drain plug to the specified torque. Tightening torque: 39 +/- 5 N. m (29 +/- 3 ft-lb)
5. Refill the specified quantity of oil. Specified Engine Oil: Engine oils displaying ILSAC certification symbol ("Starburst" symbol) or conforming to the API classification SL, SL/CF Total quantity: 4.3 dm 3 (4.5 quarts) NOTE: SAE 5W-20 engine oil is strongly recommended for optimum fuel economy and cold starting. If the ambient temperature is not within the usable temperature range of SAE 5W-20 shown in illustration, use SAE 10W-30 engine oil.
6. Install the engine oil filler cap.
7. Check oil level.
