ENGINE COMPARTMENT
For fuse location and values, see illustration below.
Scheme 5
Fuse Index Information
For fuse locations within the engine compartment fuse box (Scheme 5), also see illustrations in COMPONENT LOCATION.
Use designated fuses only.
| Location | Protected Circuit | Fuse Rating |
|---|---|---|
| 1 | Fuse (B+) | 80A |
| 2 | Radiator Fan Motor | 30A *1 50A *2 |
| 3 | ABS-ECU ABS/TCL-ECU TCL/ASC-ECU | 60A |
| 4 | Ignition Switch | 40A |
| 5 | Power Windows Control | 30A |
| 6 | Front Fog Lights | 15A |
| 7 | Heated Seat | 20A |
| 8 | Horn | 15A |
| 9 | Engine Control | 20A |
| 10 | Air Conditioning | 10A |
| 11 | Stop Lights | 7.5A |
| 12 | Audio (AMP) | 30A |
| 13 | Alternator | 7.5A |
| 14 | ETACS-ECU | 10A |
| 15 | Automatic Transaxle | 20A |
| 16 | Headlight High Beam (Rt) | 10A |
| 17 | Headlight High Beam (Lt) | 10A |
| 18 | Headlight Low Beam (Rt) | 10A *3 20A *4 |
| 19 | Headlight Low Beam (Lt) | 10A *3 20A *4 |
| 20 | Position Light (Rt) | 7.5A |
| 21 | Position Light (Lt) | 7.5A |
| 22 | Dome Light | 10A |
| 23 | Radio | 15A |
| 24 | Fuel Pump | 15A |
| 25 | Windshield Wiper | 30A |
| 26 | Condeser Fan Motor | 20A *1 |
| 27 | Battery, Front-ECU, Fusible Links | 120A |
| 28 | Hydraulic Unit Pump Motor | 40A |
| *1: For 2.4L model. *2: For 3.8L model. *3: Except for Vehicles with high intensity discharge headlights. *4: Vehicles with high intensity discharge headlights. | ||
IDENTIFYING FUSES (ENGINE COMPARTMENT FUSE BOX)
- Some fuses may not be installed on your vehicle, depending on the vehicle model or specifications.
- The table above shows the main equipment corresponding to each fuse.
PASSENGER COMPARTMENT
For fuse locations and values, see illustration below.
Scheme 6
For fuse locations within the passenger compartment fuse box (Scheme 6)
Use designated fuses only.
| Location | Protected Circuit | Fuse Rating |
|---|---|---|
| 1 | Ignition Coil | 10A |
| 2 | Gauges | 7.5A |
| 3 | Back-up Lights | 7.5A |
| 4 | Convertible Top | 7.5A |
| 5 | Relay | 7.5A |
| 6 | Door Mirror Heater | 7.5A |
| 7 | ||
| 8 | Engine Control | 7.5A |
| 9 | ||
| 10 | ||
| 11 | Outside Rearview Mirror | 7.5A |
| 12 | Convertible Top | 7.5A |
| 13 | ||
| 14 | Rear Window Wiper | 15A |
| 15 | Data Link Connector Power Door Locks | 15A |
| 16 | Cigarette Lighter Power Outlet | 15A |
| 17 | ||
| 18 | ||
| 19 | Blower Motor | 30A |
| 20 | Rear Window Defogger | 30A |
| 21 | Sunroof | 20A |
| 22 | ||
| 23 | Power Window Control Convertible Top Control Module | 7.5A |
| 24 | Convertible Top Control Module | 15A |
| 25 | Spare Fuse | 20A |
| 26 | Spare Fuse | 30A |
| 27 | Spare Fuse | 30A |
IDENTIFYING FUSES (PASSENGER COMPARTMENT FUSE BOX)
Some fuses may not be installed on your vehicle, depending on the vehicle model or specifications.
The table above shows the main equipment corresponding to each fuse.
Some spare fuses are located on the instrument panel fuse box cover.
The fuse box does not contain spare 7.5A 10A and 15A fuses. If a fuse of one of these capacities blows, replace it temporarily by borrowing a fuse of correct rating from
- 7.5A: Door mirror heater
- 10A: Dome light (Engine Compartmet)
- 15A: Cigarette lighter (Power outlet)
Replace the borrowed fuse as soon as possible.
