SPECIAL TOOLS

SPECIAL TOOLS TOOL TOOL NUMBER AND NAME SUPERSESSION APPLICATION MD998333 Oil pump remover MD998333-01 Removal of oil pump MD998903 Spring compressor MD998903-01 Removal and installation of one-way clutch inner race snap ring MD998924 Spring compressor retainer MD998924-01 Use with spring compressor MB991625 Socket (41) MB991625-01 or General service tool Removal and installation of output shaft jam nut MB990607 Torque wrench socket MB990607-01 Removal and installation of output shaft jam nut MD998412 Guide MD998412 Installation of oil pump and transfer drive gear MB991631 Clearance dummy plate MB991631-01 Measurement of reaction plate low-reverse brake and second brake end play MD998913 Dial gauge extension MD998913-01 Measurement of low-reverse brake end play MB990938 Handle MB990938-01 Installation of input shaft rear bearing Use with installer adapter MB990930 Installer adapter MB990930-01 or General service tool Installation of output shaft taper roller bearing outer race MD998350 Bearing installer MD998350-01 Installation of output shaft collar and taper roller bearing MB990931 Installer adapter MB990931-01 or General service tool Installation of cap MB990935 Installer adapter MB990935-01 or General service tool Installation of differential taper roller bearing outer race MD998334 Oil seal installer MD998334-01 Installation of oil pump oil seal MD998907 Spring compressor MD998907-01 Removal and installation of underdrive clutch snap ring MB991628 Spring compressor MB991628-01 Measurement of underdrive clutch and overdrive clutch end play MD999590 Spring compressor MIT305039 Removal and installation of overdrive clutch snap ring MB991790 Spring compressor MB991790-01 Measurement of reverse clutch end play MD998917 Bearing remover General service tool or MD998348-01 Removal of transfer driven gear MD998801 Bearing remover MD998348-01 Removal of each bearing MD998812 Installer cap General service tool Use with installer and installer adapter MD998814 Installer 200 MIT304180-A Use with installer cap and installer adapter MB990936 Installer adapter MB990936-01 or General service tool Installation of output shaft taper roller bearing outer race MD998813 Installer 100 General service tool Use with installer cap and installer adapter MD998823 Installer adapter (48) General service tool Installation of output shaft taper roller bearing, transfer driven gear, differential taper roller bearing MD998800 Oil seal installer General service tool Installation of driveshaft oil seal
