FASTENER TIGHTENING SPECIFICATIONS
| ITEMS | SPECIFICATIONS |
|---|---|
| Lower arm assembly | |
| Lower arm clamp bolt | 81 ± 12 N.m (60 ± 9 ft-lb) |
| Lower arm to clamp connection nut | 99 ± 11 N.m (73 ± 8 ft-lb) |
| Lower arm to crossmember connection nut | 108 ± 10 N.m (80 ± 7 ft-lb) |
| Lower arm to knuckle connection nut | 108 ± 10 N.m (80 ± 7 ft-lb) |
Fastener Tightening Specifications (1 Of 3)
| ITEMS | SPECIFICATIONS |
|---|---|
| Stabilizer bar | |
| Stabilizer bracket bolt | 44 ± 10 N.m (33 ± 7 ft-lb) |
| Stabilizer link nut | 44 ± 10 N.m (33 ± 7 ft-lb) |
| Strut assembly | |
| Stabilizer link nut | 44 ± 10 N.m (33 ± 7 ft-lb) |
| Strut assembly jam nut | 64 ± 5 N.m (47 ± 4 ft-lb) |
| Strut assembly to body connection nut | 44 ± 5 N.m (33 ± 3 ft-lb) |
| Strut assembly to knuckle connection nut | 300 ± 24 N.m (221 ± 18 ft-lb) |
Fastener Tightening Specifications (2 Of 3)
| ITEMS | SPECIFICATIONS |
|---|---|
| Caliper assembly bolt | 100 ± 10 N.m (74 ± 7 ft-lb) |
| Center bearing bolt | 40 ± 5 N.m (30 ± 3 ft-lb) |
| Driveshaft nut | 226 ± 29 N.m (167 ± 21 ft-lb) |
| Dust shield bolt | 8.9 ± 1.9 N.m (78 ± 17 in-lb) |
| Front strut nut | 300 ± 24 N.m (221 ± 18 ft-lb) |
| Knuckle and wheel bearing bolt | 88 ± 10 N.m (65 ± 7 ft-lb) |
| Lower arm ball joint nut | 108 ± 10 N.m (80 ± 7 ft-lb) |
| Stabilizer link nut | 44 ± 10 N.m (33 ± 7 ft-lb) |
| Tie rod end nut | 29 ± 4 N.m (21 ± 3 ft-lb) |
Fastener Tightening Specifications (3 Of 3)
GENERAL SPECIFICATION
COIL SPRING < ECLIPSE >
Scheme 1
COIL SPRING < ECLIPSE SPYDER >
