Fuse & Circuit Breaker Identification
- 1 - 10 Amp (Red) Anti-Theft
- 2 - 10 Amp (Red) Turn Signals
- 3 - 10 Amp (Red) Back-up Lights
- 4 - 15 Amp (Blue) Amplifier
- 5 - 30 Amp (Green) Heater
- 6 - 10 Amp (Red) Door Locks
- 7 - 20 Amp (Yellow) Wiper
- 8 - 10 Amp (Red) Meters
- 9 - 30 Amp (Green) Rear Window Defogger
- 10 - 20 Amp (Yellow) Sunroof (If Equipped)
- 11 - 10 Amp (Red) ELC-4
- 12 - 15 Amp (Blue) Cigarette Lighter
- 13 - 10 Amp (Red) Heater Relay
- 14 - Spare Fuses
Scheme 1
Scheme 1: UNDERHOOD POWER DISTRIBUTION CENTER IDENTIFICATION
| WARNING | Always disconnect battery ground cable before servicing "high-current fuses. It is recommended that "high-current" fuses be replaced by a qualified technician. |
- 1 - 30 Amp (Green) Power Window
- 2 - 30 Amp (Green) Engine
- 3 - 40 Amp Headlights
- 4 - 30 Amp (Green) Ignition Switch
- 5 - 30 Amp (Green) Radiator Fan
- 6 - 60 Amp ABS
- 7 - 15 Amp (Blue) Stoplights
- 8 - 15 Amp (Blue) Horn
- 9 - 15 Amp (Blue) Hazard
- 10 - 15 Amp (Blue) Tailights
- 11 - 10 Amp (Red) ABS
- 12 - 15 Amp (Blue) Foglights
- 13 - 10 Amp (Red) Headlamps High-Beam
- 14 - 10 Amp (Red) Air Conditioning
- 15 - 30 Amp (Green) Condensor Fan
- 16 - 10 Amp (Red) Radio
- 17 - 10 Amp (Red) Room Lights
Scheme 2
| WARNING | Always disconnect battery ground cable before servicing "high-current fuses. It is recommended that "high-current" fuses be replaced by a qualified technician. |
- 1 - 30 Amp (Green) Power Window
- 2 - 30 Amp (Green) Engine
- 3 - 40 Amp Headlights
- 4 - 30 Amp (Green) Ignition Switch
- 5 - 30 Amp (Green) Radiator Fan
- 6 - 60 Amp ABS
- 7 - 15 Amp (Blue) Stoplights
- 8 - 15 Amp (Blue) Horn
- 9 - 15 Amp (Blue) Hazard
- 10 - 15 Amp (Blue) Tailights
- 11 - 10 Amp (Red) ABS
- 12 - 15 Amp (Blue) Foglights
- 13 - 10 Amp (Red) Headlamps High-Beam
- 14 - 10 Amp (Red) Air Conditioning
- 15 - 30 Amp (Green) Condensor Fan
- 16 - 10 Amp (Red) Radio
- 17 - 10 Amp (Red) Room Lights
