Wiring diagram: Body control modules — Door module circuit Mitsubishi Diamante II
All systems
- Air conditioning
- Anti-lock brakes 2
- Anti-theft 2
- Body control modules 3
- Computer data lines
- Cooling fan
- Cruise control
- Defoggers
- Engine performance 3.5l
- Exterior lights 2
- Ground distribution
- Headlights
- Horn
- Instrument cluster 3
- Interior lights 2
- Memory systems
- Power antenna
- Power distribution
- Power door locks
- Power mirrors
- Power seats 3
- Power top/sunroof
- Power windows
- Radio 2
- Starting/charging 2
- Supplemental restraints
- Transmission
- Trunk, tailgate, fuel door
- Warning systems
- Wiper/washer
Components on these wiring diagrams
Click a component to highlight it on every diagram it appears on.
