A/C SPECIFICATIONS
| WARNING | To avoid injury from accidental air bag deployment, read and carefully follow all SERVICE PRECAUTIONS and DISABLING & ACTIVATING AIR BAG SYSTEM procedures in appropriate AIR BAG RESTRAINT SYSTEM article in ACCESSORIES & ELECTRICAL article in ACCESSORIES & ELECTRICAL section. |
| Application | Specification |
|---|
| Compressor Type |
| Sedan |
| R-12 | Sanden FX105VS Scroll |
| R-134a | Sanden MSC105 |
| Wagon | Nippondenso 10PA17C 10-Cyl. |
| Compressor Belt Deflection |
| DOHC Engine |
| New | 9/64-5/32" (3.5-4.0 mm) |
| Used | 5/32-13/64" (4.0-5.0 mm) |
| SOHC Engine |
| New | 17/64-9/32" (6.5-7.0 mm) |
| Used | 9/32-11/32" (7.0-8.5 mm) |
| System Oil Capacity |
| Sedan |
| R-12 | 5.4-6.0 ozs. |
| R-134a | (1) 5.7-6.4 ozs. |
| Wagon (R-12) | 5.4 ozs. |
| Refrigerant Capacity |
| Sedan |
| R-12 | 34-38 ozs. |
| R-134a | 26-28 ozs. |
| Wagon | 28 ozs. |
| System Operating Pressures (2) |
| Sedan |
| High Side | 105-112 psi (7.4-7.9 kg/cm 2 ) |
| Low Side | 19-28 psi (1.3-2.0 kg/cm 2 ) |
| Wagon |
| High Side | 206-213 psi (14.5-15.0 kg/cm 2 ) |
| Low Side | 21-28 psi (1.5-2.0 kg/cm 2 ) |
| (1) Use SUN PAG 58 refrigerant oil. (2) Specification is with ambient temperature at about 80°F (26.7°C). |
| (1) | Use SUN PAG 58 refrigerant oil. |
| (2) | Specification is with ambient temperature at about 80°F (26.7°C). |
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|
| Belt Tension Pulley Bolt | 33 (45) |
| Compressor Bracket Bolt |
| Sedan | 30 (42) |
| Wagon | 30-40 (40-55) |
| Engine Coolant Temp. Switch | 25 (35) |
| INCH Lbs. (N.m) |
| Condenser Insulator Bolt | 108 (12) |
Automatic A/C-Heater System Wiring Diagram (3.0L SOHC). Scheme 1
Scheme 1: Automatic A/C-Heater System Wiring Diagram (3.0L SOHC)
Automatic A/C-Heater System Wiring Diagram (3.0L DOHC). Scheme 2
Scheme 2: Automatic A/C-Heater System Wiring Diagram (3.0L DOHC)
