Wiring diagram: Body control modules — Body control modules circuit MINI Cooper III facelift
All systems
- Air conditioning
- Anti-lock brakes
- Anti-theft 3
- Body control modules
- Computer data lines 2
- Cooling fan
- Cruise control
- Defoggers
- Electronic power steering
- Electronic suspension
- Engine performance 1.5l turbo
- Engine performance 2.0l turbo
- Exterior lights 3
- Ground distribution
- Headlights
- Horn
- Instrument cluster
- Interior lights 2
- Memory systems 2
- Navigation 8
- Power distribution
- Power door locks 2
- Power mirrors 3
- Power seats 4
- Power top/sunroof 2
- Power windows
- Radio 5
- Starting/charging 2
- Supplemental restraints
- Transmission
- Trunk, tailgate, fuel door 3
- Warning systems
- Wiper/washer
Body control modules circuit (1 of 4) MINI Cooper III facelift
Components on the diagram
Body control modules circuit (2 of 4) MINI Cooper III facelift
Components on the diagram
Body control modules circuit (3 of 4) MINI Cooper III facelift
Components on the diagram
Body control modules circuit (4 of 4) MINI Cooper III facelift
