Wiring diagram: Computer data lines — Data link connector circuit, convertible MINI Cooper II
All systems
- Air conditioning 6
- Anti-lock brakes 4
- Anti-theft 3
- Body control modules 2
- Computer data lines 4
- Cooling fan 3
- Cruise control 2
- Defoggers 3
- Electronic power steering 2
- Engine performance 1.6l 2
- Engine performance 1.6l turbo 2
- Exterior lights 4
- Ground distribution 2
- Headlights 3
- Horn 2
- Instrument cluster 3
- Interior lights 5
- Navigation 5
- Power distribution 2
- Power door locks 2
- Power mirrors 6
- Power seats 2
- Power top/sunroof 3
- Power windows 2
- Radio 9
- Shift interlock 2
- Starting/charging 4
- Supplemental restraints
- Transmission 1.6l 2
- Transmission 1.6l turbo 2
- Trunk, tailgate, fuel door 2
- Warning systems
- Wiper/washer 5
Data link connector circuit, convertible — Computer data lines MINI Cooper II
Components on the diagram
Components on these wiring diagrams
Click a component to highlight it on every diagram it appears on.
