Wiring diagram: Headlights — Headlights circuit MINI Cooper S III facelift
All systems
- Air conditioning
- Anti-lock brakes
- Anti-theft 3
- Body control modules
- Computer data lines 2
- Cooling fan
- Cruise control
- Defoggers
- Electronic power steering
- Electronic suspension
- Engine performance 1.5l turbo
- Engine performance 2.0l turbo
- Exterior lights 3
- Ground distribution
- Headlights
- Horn
- Instrument cluster
- Interior lights 2
- Memory systems 2
- Navigation 8
- Power distribution
- Power door locks 2
- Power mirrors 3
- Power seats 4
- Power top/sunroof 2
- Power windows
- Radio 5
- Starting/charging 2
- Supplemental restraints
- Transmission
- Trunk, tailgate, fuel door 3
- Warning systems
- Wiper/washer
Headlights circuit (1 of 2) MINI Cooper S III facelift
Components on the diagram
Headlights circuit (2 of 2) MINI Cooper S III facelift
Components on the diagram
Components on these wiring diagrams
Click a component to highlight it on every diagram it appears on.
