Wiring diagram: Computer data lines — Data link connector circuit, hatchback MINI Cooper S III
All systems — 48 systems
- Active bodyworks
- Air conditioning 1.5l turbo
- Air conditioning 1.6l 2
- Air conditioning 1.6l turbo 2
- Air conditioning 2.0l turbo
- Anti-lock brakes 4
- Anti-theft 8
- Body control modules 4
- Computer data lines 8
- Cooling fan 1.5l turbo
- Cooling fan 1.6l
- Cooling fan 1.6l turbo
- Cooling fan 2.0l turbo
- Cruise control 1.5l turbo
- Cruise control 1.6l
- Cruise control 1.6l turbo
- Cruise control 2.0l turbo
- Defoggers 4
- Electronic power steering 4
- Electronic suspension
- Engine performance 1.5l turbo
- Engine performance 1.6l 3
- Engine performance 1.6l turbo 3
- Engine performance 2.0l turbo
- Exterior lights 9
- Ground distribution 4
- Headlights 4
- Horn 4
- Instrument cluster 4
- Interior lights 11
- Navigation 13
- Power distribution 4
- Power door locks 4
- Power mirrors 10
- Power seats 4
- Power top/sunroof 4
- Power windows 4
- Radio 19
- Shift interlock
- Starting/charging 1.5l turbo 2
- Starting/charging 1.6l 2
- Starting/charging 1.6l turbo 2
- Starting/charging 2.0l turbo 2
- Supplemental restraints 4
- Transmission 4
- Trunk, tailgate, fuel door 4
- Warning systems 4
- Wiper/washer 10
Components on these wiring diagrams 4
Click a component to highlight it on every diagram it appears on.
