History of the Mini
Due to an oil and gas crisis in the mid 1950's bubble or micro cars such as the BMW Isetta, appeared on the streets in all of the European countries. Driven by competition in the market British Motor Corporation (BMC), one of the world's largest manufacturers of small and medium cars decided to build a small car to compete with the bubble cars.
Designer Alec Issigonis was given the job of producing a miniature version of a car he had designed some 10 years earlier, the highly successful Morris Minor. Leonard Lord head of BMC instructed Issigonis to come up with something that would drive the bubble cars off the road. The new miniature car should be less than 10 feet in length, capable of accommodating four adults and use an existing engine. The design team shortened miniature to "Mini" and the name of the car was born.
Scheme 115
In order to achieve his design objectives, Issigonis decided to devote 80% of the space to passengers and luggage leaving little more than 18 inches in which to place the engine and gearbox.
He decided that this could only be achieved by using a transverse engine and front wheel drive. While this layout had previously been used by other manufacturers, Issigonis could not package a conventional transmission within the confines of his vehicle size objectives. He eventually settled on the unique idea of positioning the transmission in the engine sump. To maximize interior space he decided to adopt the 'wheel at each corner' configuration.
The design was not without its problems as many technical difficulties had to be overcome. The drive shafts used technology from submarine periscopes, the small tires had to be specially developed for longer wear and an oil was needed that could be shared by the engine and gearbox.
In August of 1959, just two years after the prototype had been driven, the Mini rolled off the production line in two versions - the Morris Mini Minor and the Austin Seven. The motoring press was immediately impressed with the handling of the car and its space efficiency.
While not designed as a sports car, its dynamic capabilities ensured the Mini would be driven like a sports car.
Scheme 116
Scheme 117
The Cooper Name
John Cooper, a Formula 1 car builder, having driven the Mini during its development saw more than just a simple economy car and wanted to exploit the Mini's power to weight ratio for racing.
In 1961 the first version of the Mini Cooper was launched with a larger (997cc) more powerful engine (55bhp) and disc brakes fitted to the miniscule 10" Mini wheels. The Mini Cooper was continuously developed and the name quickly became synonymous with affordable motor racing and rallying.
1963 saw the emergence of the Mini Cooper S with larger more powerful engines, improved brakes and gearbox, larger wheels and the beginning of the trademark white roof. The Cooper S took the motorsport world by storm with its outstanding chassis and power to weight ratio. Produced with an assortment of engines (1071 cc, 970cc and 1275cc) a Cooper S won the Monte Carlo Rally in 1964,1965 and 1966.
BMC ended its relationship with John Cooper in 1971 and the Mini Cooper disappeared until it was re-introduced in 1991.
Mini Variations
In addition to the the Mini and Mini Cooper, four other badge names owned by British Motor Corporation were used on the Mini, these being the Austin, Morris, Wolseley and Riley. In later years the ERA badge was used for a very special low volume turbo-charged version.
Over the years many different body types were available. Pick-up, van, estate and cabriolet versions were produced along with Wolseley and Riley versions which had their own distinctive vertical grills and tail fins. Perhaps the most unusual model was the Mini Moke which was an open-air utility vehicle originally designed for agricultural and military use but which eventually found favor as a fun vehicle. The Moke was also used as a test-bed for a bizarre four wheel drive design which was fitted with a separate engine at each end of the car. This idea was eventually abandoned.
The Mini proved to be an accessories "Gold Mine". A huge market unfolded as customers demanded the ability to personalize their Mini with every conceivable body, chassis and engine tuning accessory.
Between 1959 and 2000 some 5.3 million Mini were produced in various plants in Birmingham and Oxford, U.K., Belgium, Italy and Spain.
Scheme 118
Introducing the MINI COOPER
The design objective for the new MINI COOPER was to produce the most emotive small car in the world. To achieve this target the MINI is the best handling, performing and equipped car in its class.
Manufactured in an updated version of the original Oxford plant the MINI COOPER preserves the unique character of the old Mini, while fulfilling the MINI basic product values of safety, quality, efficient cost of ownership and environmental responsibility.
Scheme 119
Scheme 120
Model Range MINI
- R50 MINI COOPER
- R52 MINI Convertible (Cooper and S)
- R53 MINI COOPER S (Supercharged)
Scheme 121
Mini Badge
The style of the old Mini badge has been retained for the MINI, but has been updated to give a crisper, more modern look to the match the product.
MINI Service
The MINI COOPER is fully integrated in the MINI Group organization. All data relating to the MINI COOPER is available in the BMW Group Service infrastructure (DIS, TIS, KSD and EPC), and in the minidealernet website.
Vehicle Identification Numbers
Vehicle Identification Numbers are referred to as the VIN. MINI utilizes a VIN with a 17 character structure. The characters are grouped to include multiple information as follows
Scheme 122
VIN Location on Vehicle
The VIN is located on the vehicle in the following locations
- Left lower corner of the instrument panel. This is viewed through the windshield from outside the vehicle.
- B pillar compliance label. On the drivers side door jamb.
Additionally the VIN is stamped into the chassis in one of two locations
- Under the hood on right side of engine compartment bulkhead.
- Under the hood on right side shock tower.
Scheme 123
Scheme 124
The production date of the vehicle is included in the B pillar compliance label.
Production date information is required quite often when a repair procedure affects only a certain range of vehicles. The range is based on production dates.
The date shown on the label reflects the actual month and year the vehicle was produced. It is not a model year indicator. The only way to be certain what the model year of the vehicle is, you will have to look at the tenth digit of the VIN.
Vehicle Production Anti-Theft Labels
Since 1987, the National Highway Traffic Safety Administration (NHTSA) requires that the VIN be marked on specific parts of the car during manufacture for theft identification. Some models are exempt if the total number of vehicles imported is below a certain number.
If the vehicle does have the label it is also a reference point for the VIN.
If equipped, the label is placed on the following locations
- Engine
- Quarter panels
- Transmission
- Shock Tower
- Front bumper
- Front Fenders
- Doors
- Hood
- Trunk lid
- Firewall
- Rear Bumper
Scheme 125
Paint Code Identification
When ordering painted parts it is necessary to obtain the vehicle's paint code. The paint code consists of a three digit number printed on the color identification tag as shown below. All color identification tags are located in the engine compartment.
Scheme 126
MINI Main Group Numbering System
MINI uses a group numbering system to aid internal and MINI Center personnel to identify vehicle components or MINI information resources.
The main group numbering system is made of two digits at the beginning of any MINI group number. The following information resources are all organized by the group numbering system.
- Part Numbers
- Service Information Bulletins
- Repair Manuals
- Tightening Torques
- Electrical Troubleshooting Manuals
- Warranty Labor and Defect codes
- Technical Reference Information
- Technical Data
- Special Tool Catalog
- Diagnosis Program Test Modules
| Group | Description |
|---|---|
| 00 | Maintenance and General Hints |
| 01 | Warranty |
| 02 | Aftersales Development |
| 03 | Technical Training |
| 04 | Tools and Equipment |
| 05 | Information Systems |
| 06 | Customer Relations |
| 07 | DISplus |
| 08 | GT1 |
| 09 | Programming/Coding Explanations |
| 10 | TIS |
| 11 | Engine |
| 12 | Engine Electrical Systems |
| 13 | Fuel Systems |
| 16 | Fuel Supply Systems |
| 17 | Cooling System |
| 18 | Exhaust Systems |
| 21 | Clutch |
| 22 | Engine and Gearbox Suspension |
| 23 | Manual Transmission |
| 24 | Automatic Transmission |
| 25 | Gear Shift Mechanism |
| 26 | Drive Shaft |
| 27 | Intermediate and Special Transmissions |
| 31 | Front Axle |
| 32 | Steering and Wheel Alignment |
| 33 | Rear Axle |
| 34 | Brakes |
| 35 | Pedals |
| 36 | Wheels and Tires |
| 37 | Special Suspension Systems |
| 41 | Body |
| 51 | Body Equipment |
| 52 | Seats |
| 54 | Special Roofs |
| 61 | General Electrical Systems |
| 62 | Instruments |
| 63 | Lights |
| 64 | Heating and Air Conditioning |
| 65 | Sound System, Cruise, Alarms, Monitors |
| 66 | Remote Control Systems |
| 67 | Electric Drives |
| 71 | Vehicle Tools |
| 72 | Safety Restraint Systems |
| 80 | Bicycles/Bicycle Accessories |
| 81 | Books, Calendars and Collectibles |
| 82 | Lifestyle and Gift Items |
| 84 | Phone, Navigation Systems |
| 91 | Individual Equipment |
| 97 | Corrosion Protection |
| 98 | Paints and Car Care Products |
| 99 | Paint Work |
| 100 | Visionwerke Information |
MINI MAIN GROUP NUMBERING DESCRIPTION CHART
MINI Abbreviations and Acronyms
Throughout your career as a MINI Group Service Technician you will come across many acronyms in the various Technical publications. An acronym is a word formed from the initial letters of a longer word. In the next two pages there is a list of acronyms describing various systems on MINI.
Remember this is only a partial list. MINI is a dynamic company and is always adding new systems to its products. Look for new systems and acronyms with new Technical Training courses, Service Information, and Technical Information Bulletins.
| A | Processed Vehicle Speed |
|---|---|
| AB | Airbag |
| ABS | Anti-lock Braking System |
| AHPS | Advanced Head Protection System |
| AIC | Automatic Interval Control (rain sensor) |
| ASC | Automatic Stability Control |
| ASC+T | ASC+ Traction |
| AUC | Automatic Air Recirculation |
| B | Benzene (gasoline) |
| BC | Board Computer |
| BC1 | Body Controller 1 |
| BL | Blue |
| BLS | Brake Light Switch |
| BMBT | Board Monitor |
| BMC | British Motor Corporation |
| BR | Brown |
| BS | Block Diagram |
| BST | Battery Safety Terminal |
| BZM | Center Console Control Center |
| CBC | Corner Braking Control |
| Can-bus | Controller Area Network(bus) |
| CCM | Check Control Module |
| CDC | Compact Disc Changer |
| CO | Carbon Monoxide |
| CO 2 | Carbon Dioxide |
| CVM | Convertible Top Module |
| CVT | Constantly Variable Trans. |
| D-Bus | Diagnosis Bus (same as TXD) |
| DBC | Dynamic Brake Control |
| DBW | Drive by Wire |
| DCS | Dealer Communication System |
| DSC | Dynamic Stability Control |
| DIN | German Industrial Standards |
| DIS | Diagnosis and Information System |
| DK | Throttle Housing |
| DKI | Throttle Position |
| DME | Digital Motor Electronics |
| DM-TL | Diag. Module Tank Leakage |
| DSC | Dynamic Stability Control |
| DSP | Digital Sound Processing |
| DTC | Diagnostic Trouble Code |
| DWA | Theft Deterrent System |
| EBV | Electronic Brake Proportioning |
| E-Box | Electronics Carrier Box |
| ECM | Engine control module (SAE) |
| ECVT | Electronic Continuously Variable |
| Electronic Transmission | |
| EDK | Electronic Throttle Valve |
| EDR | Electronic Throttle Regulator |
| EGS | Electronic Transmission Control |
| EH | Electronic Hydraulic |
| EHPS | Electronic Hydraulic Power Steering |
| EKP | Electronic Fuel Pump |
| ELV | Electronic Steering Lock |
| EM | Electro-Mechanical |
| EML | Electronic Motor Load Regulation |
| EMS | Engine Management System |
| EO | Component Location |
| EPC | Electronic Parts Catalog |
| ETM | Elec. Troubleshooting Manual |
| EWS | Electronic Drive-away Protection |
| FB | Function Description |
| FBZV | Radio Frequency Locking |
| FRU | Flat Rate Unit |
| GAL | Speed Dependent Volume |
| GE | Yellow |
| GIB | Gearbox Interface Box |
| GIU | Gearbox Interface Unit |
| GMR | Yaw Moment Control |
| GN | Green |
| GR | Gray |
| GRII | Cruise Control |
| GPS | Global Positioning System |
| HC | Hydrocarbon |
| HFM | Hot Film Air Mass Meter |
| HFS | Heated Front Windshield |
| HRW | Heated Rear Windshield |
| HW | Hardware |
| IB | Interior lighting Control Signal |
| I-Bus | Information Bus |
| IHKA | Automatic Heating and A/C |
| IHKR | Regulated Heating and A/C |
| IHKS | Manual Heating and A/C |
| IKE | Instrument Cluster Electronics |
| IR | Infrared |
| ISN | Individual Serial Number |
| K-Bus | Karisorie (Body) Bus |
| KL | Terminal |
| KO | Compressor "ON" Signal |
| KOMBI | Instrument Cluster |
| KOREL | Compressor Relay Signal |
| KW | Crankshaft |
| LCD | Liquid Crystal Display |
| LCM | Lamp Check Module |
| LDP | Leak Diagnosis Pump |
| LED | Light Emitting Diode |
| LEV | Low Emissions Vehicle |
| LL | Closed Throttle (idle) |
| LRA | Vertical Headlight Aiming |
| LSZ | Lamp Switching Center |
| LVA | Air Supply System |
| LWR | Vertical Headlight Aiming |
| LWS | Steering Angle Sensor |
| MAP | Manifold Absolute Pressure |
| MBC | Maximum Brake Control |
| MDK | Motorized Throttle Valve |
| MFL | Multi-Function Steering Wheel |
| MID | Multi-Information Display |
| MRS | Multiple Restraint System |
| MSR | Engine Drag Torque Reduction |
| NAV | Navigation |
| NO x | Oxides of Nitrogen |
| NTC | Negative Temperature Coefficient |
| OBC | On-Board Computer |
| OBD | On-Board Diagnosis (SAE) |
| OR | Orange |
| PB | Pin Assignments |
| P-Bus | Periphery Bus |
| PDC | Park Distance Control |
| PDI | Pre-Delivery Inspection |
| PWG | Pedal Position Sensor |
| QC1 | Quality Certification 1 |
| RDS | Radio Data System |
| RDW | Tire Pressure Warning |
| RM | Relay Module |
| RPS | Rollover Protection System |
| RPW | Tire Puncture Warning |
| RS | Rose/Pink |
| RT | Red |
| RZV | Direct Stationary Ignition |
| SB | Fuse Assignments |
| SBK | Safety Battery Cable |
| SG | Control Unit |
| SHD | Sunroof Module |
| SIM | Service Information Bulletin (MINI) |
| SIA | Service Indicator Announcement |
| SII | Service Interval Indicator |
| SP | Schematic Picture |
| ST | Connector Views |
| SW | Black |
| SW | Software |
| TD | Processed Engine Speed Signal |
| Ti | Injector on time |
| TIB | Transmission Interface Box |
| TIS | Technical Information System |
| TL | Part Throttle |
| TLEV | Transitional Low Emission Vehicle |
| T-MAP | Temperature + Manifold Absolute Pressure |
| TR | Transparent |
| TRS | Battery Isolation Switch |
| TSH | Door Lock Heating |
| TU | Technical Update |
| TXD | Transmitting Diagnosis Line |
| ULEV | Ultra Low Emission Vehicle |
| VI | Violet |
| VIN | Vehicle Identification Number |
| VL | Full load - wide open throttle |
| VM | Video Module |
| WS | White |
MINI ABBREVIATIONS AND ACRONYMS
Technical Data
| MINI Cooper | MINI Cooper S | MINI Convertible (Cooper/S) | |
|---|---|---|---|
| Length (mm) | 3635 | 3650 | 3649 |
| Width (mm) | 1688 | 1688 | 1687.5 |
| Height (mm) | 1396 | 1396 | 1398 |
| Wheelbase (mm) | 2467 | 2467 | 2467 |
| Turning Circle (m) | 10.66 | 10.66 | 10.66 |
| Track Frt/Rear (mm) | 1460/1466 | 1454/1460 | 1458/1464 |
| Fuel Tank Capacity | 50 | 50 | 50 |
| Empty Weight (kg) | 1050(1075) | 1120 | 1250/1315 |
| Engine Data | |||
| Design | 4 cyl Transverse Mounted 4 Valves per cylinder | ||
| Displacement | 1598 | ||
| Bore/Stroke | 77/85.8 | ||
| Power | 115 @ 6000 | 168 @ 6000 | 115 @ 6000/168@ 6000 |
| Torque | 149 @ 4500 | 220 @ 4000 | 149 @ 4500/220@ 4000 |
| Compression | 10.6:1 | 8.3:1 | 10.6:1/8.3:1 |
| Engine Management | Siemens EMS2K | ||
| Chassis Data | |||
| Tire Size | 175/65R15 | 195/55R16 | 175/65R15/195/55R16 |
| Wheel Dimensions | 5.5 J x 15 Alloy | 5.5 J x 16 Alloy | 5.5 J x 15 Alloy/5.5 J x 16 Alloy |
TECHNICAL DATA
Overall Gear Ratios
| MINI Cooper | MINI Cooper S | MINI Cooper Convertible | All With ECVT | ||||
|---|---|---|---|---|---|---|---|
| Up to MY05 | Beginning MY05 | Up to MY05 | Beginning MY05 | Base | S | ||
| GS5-65BH | Getrag252 | Getrag285 | Getrag285 | Getrag252 | Getrag285 | GACVT16Z | |
| 1st | 13.463 | 14.4 | 11.425 | 12.789 | 14.4 | 12.789 | |
| 2nd | 7.671 | 8.327 | 7.181 | 7.793 | 8.327 | 7.793 | |
| 3rd | 5.252 | 5.476 | 5.397 | 5.651 | 5.476 | 5.651 | |
| 4th | 4.153 | 4.105 | 4.407 | 4.615 | 4.105 | 4.615 | |
| 5th | 3.333 | 3.509 | 3.656 | 3.828 | 3.509 | 3.828 | |
| 6th | 2.986 | 3.126 | 3.126 | ||||
| Rev | 14.105 | 14.065 | 11.131 | 11.944 | 14.065 | 11.944 | 3.820 |
| Final Drive | 1.0 | 1.00 | 1.0 | 1.0 | 1.00 | 1.0 | 5.76 |
OVERALL GEAR RATIOS
Driveline Data
| MINI COOPER (ECVT) | MINI COOPERS | |
|---|---|---|
| Gearbox (Optional) | 5 Speed R 65 (ECVT) GS5-65BH (ZF GACVT16Z) | 6 Speed Getrag 285 GS6-85BG |
| 1st | 3.417:1 | 4.167:1 (11.425) |
| 2nd | 1.947:1 | 2.619:1 (7.181) |
| 3rd | 1.333:1 | 1.333:1 (5.397) |
| 4th | 1.054 | 1.089:1 (4.407) |
| 5th | 0.846:1 | 1.333:1 (3.656) |
| 6th | 1.089:1 (2.986) | |
| Reverse | 3.58:1 | 2.75:1 (11.131) |
| Final Drive | 3.94:1 (4.05:1) | 2.74/4.05:1 |
| Transmission Oil Capacity (L) | 2.0 (4.01) | 1.5 |
DRIVELINE TECHNICAL DATA
Chassis Data
| Tire Size | 175/65R15 84T | 195/55R16 87V |
|---|---|---|
| Wheel Dimensions | 5.5 J x 15 Alloy | 5.5 J x 16 alloy |
| Front Brakes Diameter/Thickness (mm) | 276/22 Ventilated | |
| Rear Brakes Diameter/Thickness (mm) | 239/10Solid | |
CHASSIS TECHNICAL DATA
Performance Data
| Acceleration 0 to 62 MPH (seconds) | 9.2 (10.2) | 7.4 |
|---|---|---|
| Maximum Speed (MPH) | 124 (115) | 134 |
| Fuel Consumption(MPG) | TBA | TBA |
| Emission Compliancy | LEV | LEV |
| Fuel Requirement | 91 AKI (Premium) | 91 AKI (Premium) |
PERFORMANCE TECHNICAL DATA
Scheme 127
Scheme 128
Scheme 129
Scheme 130
Scheme 131
| Loaded Heights | With Antenna Base | Without Antenna |
|---|---|---|
| Empty | 1428mm | 1416mm |
| 2 Front and 1 Rear Passenger | 1405mm | 1396mm |
| Fully Loaded | 1365mm | 1356mm |
VEHICLE DIMENSIONS SPECIFICATION
