Cooling System - Special Tools - Cooper (w10) & Cooper S (w11) MINI Cooper S I

Cooling System (mechanical) 5 illustrations ~987 words

17 0 000 Tester

Note: For checking cooling system for leaks and function of pressure relief valve in radiator cap. Replaced by 17 0 100.

Storage location: A43, C17.

Order number: 17 0 000 .

Tester.

Consisting of

  1. 1 = 17 0 001 Adapter. Note: For checking pressure relief valve in radiator cap / model series: all, except E28.
  2. 2 = 17 0 002 Tester without adapter. Note: Pressure range 0-2.5 bar / model series: all, except E28.
  3. 3 = 17 0 003 Screw neck. Note: For screw-on radiator caps (normal thread)/ model series: E28, E30, E31, E32 Engine: all, except M51.
  4. 4 = 17 0 004 Adapter. Note: For screw -on radiator caps (normal thread) / model series: E28, E30, E32 / Engine: M51.
  5. 5 = 17 0 005 Screw neck. Note: For screw -on radiator caps (buttress thread) / model series: E31, E32, E34, E36, E38, E39.
  6. 7 = 17 0 007 Adapter. Note: For checking expansion tank cap / model series: E31, E32, E34, E36, E38, E39.
  7. 8 = 17 0 008 Pressure hose.
  8. 9 = 17 0 009 Adapter for radiator expansion tank.

Note: Model series: E36 / Model: M3 US Engine W10.

Scheme 28

Scheme 28
Scheme 28

17 0 030 Pliers

Minimum set: Mechanical tools.

Note: For releasing fasteners on transmission oil cooler.

Series: E46, E53, E60, E61, E63, E64, E65, E66, E85, R50, R53.

Storage location: B46.

SI number: 1 14 01 (766).

Order number: 17 0 030 .

Pliers.

Scheme 29

Scheme 29: 17 0 030 Pliers
Scheme 29: 17 0 030 Pliers

17 0 100 Tester

Minimum set: Mechanical tools

Note: For checking engine cooling system for water leaks. For checking radiator cap.

Series: E12, E21, E23, E24, E28, E30, E30/C, E30tou, E31, E32, E32/3, E34, E34tou, E36, E36/2, E36/3, E36/5, E36/7, E36/C, E36tou, E38, E38/3, E39, E39PL, E39tou, E46, E46/16, E46/2, E46/3, E46/5, E46/C, E52, E53, E60, E61, E63, E64, E65, E66, E67, E83, E85, E87, R50, R52, R53, RR1.

Engine: M10, M20, M20B25, M20B27, M21, M30, M30B34, M30Tur, M40, M41, M42, M43, M43TU, M44, M47, M47TU, M50, M51, M52, M52TU, M54, M56, M57, M57D25, M57D30, M57TU, M60, M62, M62VAN, M67, M70, M73, M88, N40, N42, N45, N46, N52, N62, N73, S14, S38, S50B30, S50B32, S50US, S52US, S54, S62, W10, W11, W17.

SI number: 01 07 02 (884).

Order number: 17 0 100 .

Tester.

Consisting of

  1. = 17 0 101 Pump.
  2. = 17 0 102 Hose with quick-connect coupling.
  3. = 17 0 103 Adapter. Note: For radiator cap (normal thread).
  4. = 17 0 104 Adapter. Note: For radiator cap (normal thread).
  5. = 17 0 105 Adapter. Note: For radiator cap (sawtooth thread).
  6. = 17 0 106 Adapter. Note: For radiator cap (sawtooth thread).
  7. = 17 0 107 Adapter. Note: For radiator cap R50 / W10.
  8. = 17 0 108 Adapter. Note: For radiator cap R50 / W10.
  9. = 17 0 109 Adapter. Note: For radiator connection R53/W11, R50/W17 Adapter corresponds to 17 0 051.
  10. = 17 0 111 Adapter. Note: For radiator cap R53/W11, R50/W17 Adapter corresponds to 17 0 052.
  11. = 17 0 112 Case.
  12. = 17 0 113 Adapter. Note: For radiator cap Model series: E60, E61, E63, E64 SI no.: 1 08 03 (988).
  13. = 17 0 114 Adapter.

Note: For radiator cap Model series: E60, E61, E63, E64 SI no.: 1 08 03 (988).

Scheme 30

Scheme 30
Scheme 30

17 0 130 Set of adapters

In conjunction with: 17 0 101, 17 0 102.

Note: For connecting adapters from 17 0 000 to pump 17 0 101 and hose 17 0 102.

SI number: 01 07 02 (884).

Order number: 17 0 130

Set of adapters.

Consisting of

Scheme 31

Scheme 31: 17 0 130 Set of adapters
Scheme 31: 17 0 130 Set of adapters
  1. = 17 0 131 Adapter. Note: For connecting pump 17 0 101 and hose 17 0 102 to adapter from «17 0 000»(/mini/cooper-s/i-2000-2006/remont/cooling-system-mechanical/#cooling-system-special-tools-cooper-w10-cooper-s-w11__17-0-000-tester) .
  2. = 17 0 132 Hose with coupling connection. Note: For connecting pump 17 0 101 to adapter 17 0 007.
  3. = 17 0 133 Hose clamp. Note: For hose 17 0 132

17 2 010 Set of adapters

Note: For oil dispensers for flushing oil coolers of automatic transmissions.

Transmission: A4S 310R, A5S 300J, A5S 310Z, A5S 325Z, A5S 360R, A5S 390G, A5S 440Z, A5S 560Z, GA6 HP19Z, GA6 HP26Z, GA6 HP32Z.

SI number: 1 12 96 (103).

Order number: 17 2 010 .

Set of adapters.

Consisting of

  1. = 17 2 011 Adapter

Note: For connecting oil cooler lines to oil dispensing unit - transmission: A5S 310Z, A5S 560Z, A5S 325Z.

In conjunction with: 17 2 015, 17 2 016, 17 2 017, 17 2 018, 17 2 019.

  1. = 17 2 021 Retaining plate. Note: For Adapter 17 2 011 - transmission: A5S 325Z.
  2. = 17 2 012 Adapter (2 x). Note: For connecting oil cooler lines to oil dispensing unit - transmission: A4S 310R. In conjunction with: 17 2 015, 17 2 016, 17 2 017, 17 2 01, 17 2 018, 17 2 019.
  3. = 17 2 013 Banjo bolt (2 x). Note: M18x1.5 thread with nut and seal for connecting oil cooler lines to oil dispensing unit - transmission: A5S 440Z. In conjunction with: 17 2 012, 17 2 015, 17 2 016, 17 2 017, 17 2 018, 17 2 019.
  4. = 17 2 014 Banjo bolt (2 x). Note: M16x1.5 thread with nut, seal and threaded piece for connecting oil cooler lines to oil dispensing unit - transmission: A5S 300J. In conjunction with: 17 2 012, 17 2 015, 17 2 016, 17 2 017, 17 2 018, 17 2 019.
  5. = 17 2 015 Connecting piece. Note: For Tecalemit oil dispensing unit.
  6. = 17 2 016 Connecting piece. Note: For Horn oil dispensing unit.
  7. = 17 2 017 Coupling (2 x).
  8. = 17 2 018 Hose, long.
  9. = 17 2 019 Hose, short.

Scheme 32

Scheme 32
Scheme 32
