Purpose of the System
The purpose of the DISplus is to meet the challenges for present and future generation BMW group vehicles.
The functions of the DISplus that are
- Diagnosis Program
- Measurement Techniques
- Remote Controller for the SSS to perform Coding Individualization and Programming
The DISplus has Network capability and allows for any necessary upgrades in the future to keep up with the vehicle technology to come.
Scheme 1
Specifications
- 500Mhz Intel Pentium TM III processor
- 128MB RAM
- 13.6 GB hard drive
- DVD drive
- Sound card with 2 speakers
- Network card for LAN connection (connected to the Service Department network)
- Additional SVGA output for connection to an external monitor
- 15" TFT touch screen monitor
- Vehicle communication via a diagnostic head (Radio frequency)
Monitor
The DISplus uses a 15" TFT (Thin Film Transistor) monitor. It has a pressure sensitive touch screen controller to direct the curser movement.
The monitor is attached to the DISplus by a 15" cable that allows it to be used either on the swivel stand or remotely, e.g. inside of a vehicle.
Scheme 2
Main Power Switch
The main power switch is located in the upper right hand side, at the rear of the DISplus.
The main switch is turned on first, before turning the DISplus on from the front panel. The System Status LED on the front panel should illuminate amber when the main power has been turned on.
Circuit breakers are located below the DISplus computer. If the unit fails to power-up, check the reset of the circuit breakers before calling for service.
Scheme 3
Scheme 4
Scheme 5
After the main power switch has been turned on, the DISplus is powered up by pressing the on/off button on the front panel.
During power up, LED 2 will illuminate. When the process is complete, the System Status LED changes from amber to green.
The fault indicator, LED 3, illuminates amber when there is a fault with the DISplus.
Scheme 6
DVD and 3.5" Floppy Drive
The DVD and Floppy drives are located behind a door on the right side of the unit.
The Floppy drive is used for the boot-up disk when loading the Diagnosis Program.
The DVD drive is used to load the Basis and Program CDs for Diagnosis.
The TIS CD is also loaded in the DVD drive and remains in the drive for the computer to access during TIS operation.
Scheme 7
RF Access Point
The access point is the transfer device between the hardwired LAN network and the radio frequency assisted LAN.
The DISplus is connected to the access point via a network LAN cable. The access point then communicates with the Diagnostic Head using a radio frequency LAN link.
Scheme 8
Diagnostic Head
The DISplus uses a Diagnostic Head similar to the DISplus III as the communication link between the DISplus and the vehicle electronics.
The Head receives operating power when the diagnosis cable is connected to the vehicle.
Scheme 9
Communication between the DISplus and the Head can occur two ways
- Radio frequency (maximum 30m distance)
- Hard wired to the network or DISplus
Scheme 10
Scheme 11
Scheme 12
Diagnostic Cable
20 and 16 pin cables are provided for connection between the vehicle diagnostic socket and Diagnostic Head.
Scheme 13
Scheme 14
Test Cables
Various test cables and the main power cable are connected to the rear of the DISplus through the conduit channel of the cable arm mast. The following test cables are stored on the arm.
LAN (Local Area Network) Connection
The LAN connection has the appearance of a large phone receptacle. It provides the connection for the DISplus to the Ethernet wiring for the Service Department Network.
Scheme 15
TD (RPM input) Cable
TD is a processed engine RPM signal. The TD input cable is used for specific test modules or preset measurements that require a hard wired RPM input for measurement functions.
Scheme 16
Multi-Function Test Cable-MFK#1 (two cable ends)
MFK 1 is used to measure
- Voltage - up to 50 Volts
- Current - up to 2 Amps
- Resistance
- Diode Testing
- Frequency
- Period
- Duty Cycle
- Pulse Duration
- Oscilloscope Measurements
Scheme 17
Multi-Function Test Cable-MFK #2 (Four cable ends)
MFK 2 is used to measure
- Voltage - up to 500 Volts
- Frequency
- Period
- Duty Cycle
- Pulse Duration
- Oscilloscope Measurements
Scheme 18
Both MFK 1 and MFK 2 can be used for signal outputs from the stimulate output function of the multimeter.
On MFK 2, the two large cable ends are for input only (measuring) and the two small ends are for the Stimulate Output function. MFK 1 's leads are for both measuring and stimulation.
Both large positive cable ends of MFK 1 and MFK 2 include a button used to hold the measured value on the display screen.
Scheme 19
Trigger Clip (inductive)
The trigger clip is used when testing ignition or fuel injection systems to establish engine firing order.
Scheme 20
Additional Test Cables
There are additional test cables connected to the rear of the DISplus on the measurement system board. The ends of the cables are color-coded for easy identification.
Scheme 21
Secondary Ignition Test Cables
The inductive clip (1) is used when checking secondary ignition on MINI vehicles. It is clipped to the vehicle's spark plug wire.
Scheme 22
50 and 1000 Amp Inductive Probes
The Amp probes measure AC and DC current. They are self calibrating inductive pickups.
Scheme 23
Temperature Sensor
The long temperature probe measures the temperature of liquids and gasses. The measurement range is from -20°C to 200°C.
Scheme 24
Pressure Sensor
The Pressure Sensor measures from 0 to 25 bar. There are two pressure inputs to the measuring unit that permit two different pressures to be measured simultaneously if two sensors are used.
Scheme 25
