Power Windows: Other Mercury Villager I

Windows 13 illustrations ~1647 words

REAR QUARTER GLASS

The rear quarter window glass pivots outward from the back just like the manual rear quarter window glass. The power rear quarter window glass is operated remotely from the rear quarter window glass switches located on the roof-mounted overhead console. (Scheme 38)

When the rear window regulator control switch is pressed the power rear quarter glass motor is energized. The power rear quarter glass motor turns the power rear quarter window glass cable. The power rear quarter window glass cable will turn the power rear quarter window latch regulator to either open or close the rear quarter window glass. (Scheme 39)

Scheme 38

Scheme 38: REAR QUARTER GLASS
Scheme 38: REAR QUARTER GLASS

Scheme 39

Scheme 39
Scheme 39

FRONT DOOR GLASS

  1. Remove the front door trim panel. See appropriate POWER DOOR LOCKS article.
  2. Remove the two door panel bracket bolts and door panel bracket. (Scheme 40)
  3. Remove the plastic weather shield from the door.
  4. Loosen the four door glass regulator track bolts. (Scheme 41)
  5. Adjust the position of the door glass regulator track. (Scheme 42)
  6. Tighten the four door glass regulator track bolts securely.

Scheme 40

Scheme 40
Scheme 40

Scheme 41

Scheme 41
Scheme 41

Scheme 42

Scheme 42
Scheme 42
  1. Remove rear quarter trim. See «REAR QUARTER TRIM»(ref-138783-S26712161962002042900000) under REMOVAL & INSTALLATION.
  2. Loosen the two power rear quarter glass latch regulator bolts. (Scheme 43)
  3. Loosen the two rear quarter glass hinge nuts. (Scheme 44)
  4. Adjust the rear quarter glass. (Scheme 45)
  5. While holding the rear quarter glass have an assistant tighten the two rear quarter glass hinge nuts to 2.8-3.3 INCH Lbs. (3.8-4.5 N. m).
  6. Tighten the two rear quarter glass latch bolts to 2.8-3.3 INCH Lbs. (3.8-4.5 N. m).
  7. Tighten the power window rear quarter glass latch regulator bolts to 2.8-3.3 INCH Lbs. (3.8-4.5 N. m).
  8. Install the rear quarter trim. See «REAR QUARTER TRIM»(ref-138783-S26712161962002042900000) under REMOVAL & INSTALLATION.

Scheme 43

Scheme 43
Scheme 43

Scheme 44

Scheme 44
Scheme 44

Scheme 45

Scheme 45
Scheme 45

SYSTEM TESTS

SymptomPerform Test
Power Windows Completely InoperativeA
Power Windows And Rear Quarter Glass Completely InoperativeB
Single Power Window InoperativeC
Power Rear Quarter Glass InoperativeD
One-Touch Down Feature InoperativeE

SYMPTOM INDEX

  1. Turn the ignition switch to OFF. Disconnect the master window regulator control switch connector located on the left front door trim panel. Turn the ignition switch to ON. Measure the voltage on terminal No. 7 (Light Green/Yellow wire) at the master window regulator control switch connector. (Scheme 46) See «WIRING DIAGRAMS»(ref-138783-S30905480172002042300000). Is the voltage greater than 10 volts? If yes, then go to next step. If not, then repair the Light Green/Yellow wire.
  2. Check the master window regulator control switch. See «POWER WINDOW SWITCH»(ref-138783-S27574273832002042900000) under COMPONENT TESTS. Is the master window regulator control switch OK? If yes, then service the Black wire between the master window regulator control switch and ground. If not, then replace the master window regulator control switch. See «POWER WINDOW SWITCH»(ref-138783-S04561537892002042900000) under REMOVAL & INSTALLATION.

Scheme 46

Scheme 46
Scheme 46
  1. Check the RLY COIL fuse (10 amp) located in the interior fuse junction panel. Check the POWER WINDOW fuse (30 amp) located in the left engine compartment fuse junction panel. Are the fuses okay? If yes, then go to step 5. If not, then go to next step.
  2. Turn ignition switch to OFF position. Replace the RLY COIL fuse and/or the POWER WINDOW fuse. Turn the ignition switch to ON position. If the RLY COIL fuse fails again, go to next step. If the POWER WINDOW fuse fails again, go to step 4. If neither fuse fails, go to step 5.
  3. Turn the ignition switch to OFF position. Remove the RLY COIL fuse. Disconnect the power window relay located behind the interior fuse junction panel. Disconnect the power window module connector located behind the left front door trim panel. Measure the resistance of the Blue wire between the right terminal of the RLY COIL fuse and ground. See «WIRING DIAGRAMS»(ref-138783-S30905480172002042300000). Is the resistance less than 5 ohms? If yes, then repair the Blue wire. If not then replace the RLY COIL fuse. When repair is complete, go to step 5.
  4. Turn the ignition switch to OFF position. Disconnect the right circuit breaker connector located behind the interior fuse junction panel and the power window relay located behind the interior fuse junction panel. Measure the resistance of the White/Blue wire between the terminal nearest the battery of the POWER WINDOW fuse and ground. Measure the resistance of the Light Green wire between the power window relay and ground. See «WIRING DIAGRAMS»(ref-138783-S30905480172002042300000). Are the resistances greater than 10,000 ohms? If yes, then replace the POWER WINDOW fuse. Reconnect the right circuit breaker. If not, then repair the faulty circuit. When repairs are complete, go to next step.
  5. Turn the ignition switch to OFF position. Disconnect the power window relay located behind the interior fuse junction panel. Turn the ignition switch to ON position. Measure the voltage on the Blue wire at the power window relay connector. See «WIRING DIAGRAMS»(ref-138783-S30905480172002042300000). Is the voltage greater than 10 volts? If yes, then go to next step. If not, then repair the Blue wire between the interior fuse junction panel and the power window relay.
  6. Turn the ignition switch to OFF position. Disconnect the power window relay. Turn the ignition switch to ON. Measure the voltage on the Light Green wire at the power window relay connector. See «WIRING DIAGRAMS»(ref-138783-S30905480172002042300000). Is the voltage greater than 10 volts? If yes, then go to step 9. If not, then go to next step.
  7. Turn the ignition switch to OFF position. Disconnect the right circuit breaker connector. Turn the ignition switch to ON. Measure the voltage on the White/Blue wire at the right circuit breaker connector. See «WIRING DIAGRAMS»(ref-138783-S30905480172002042300000). Is the voltage greater than 10 volts? If yes, then go to next step. If not, then repair the White/Blue wire between the interior fuse junction panel and the right circuit breaker.
  8. Turn the ignition switch to OFF position. Remove the power window relay. Disconnect the right circuit breaker connector. Measure the resistance of the Light Green wire between the right circuit breaker connector and the power window relay connector. See «WIRING DIAGRAMS»(ref-138783-S30905480172002042300000). Is the resistance less than 5 ohms? If yes, then replace the right circuit breaker. See «CIRCUIT BREAKER»(ref-138783-S16512085332002042900000) under REMOVAL & INSTALLATION.
  9. Turn the ignition switch to OFF position. Remove the power window relay. Measure the resistance of the Black wire between the power window relay connector and ground. See «WIRING DIAGRAMS»(ref-138783-S30905480172002042300000). Is the resistance less than 5 ohms? If yes, then replace the power window relay. See «RELAY»(ref-138783-S15202185672002042900000) under REMOVAL & INSTALLATION. If not, then go to next step.
  10. Turn the ignition switch to OFF position. Remove the instrument cluster. See INSTRUMENT PANELS, ANALOG -- VILLAGER or INSTRUMENT PANELS ELECTRONIC -- VILLAGER article. Disconnect the center green diode strip from the diode junction box connector located behind the instrument cluster. Measure the resistance of the Black wire between the power window relay connector and terminal No. 13 of the diode junction box connector. (Scheme 47) See «WIRING DIAGRAMS»(ref-138783-S30905480172002042300000). Is the resistance less than 5 ohms? If yes, then go to next step. If not, then repair the Black wire.
  11. Turn the ignition switch to OFF position. Measure the resistance of the Black/Red wire between terminal No. 15 of the diode junction box connector and ground. (Scheme 47) See «WIRING DIAGRAMS»(ref-138783-S30905480172002042300000). Is the resistance less than 5 ohms? If yes, then replace the center green diode strip. If not then repair the Black/Red wire and/or Black wire.

Scheme 47

Scheme 47
Scheme 47

Master Switch

  1. Turn the ignition switch to OFF position.
  2. Disconnect the master window regulator control switch connector located on the left front door trim panel. Measure the resistance between the specified wire terminals on the master window regulator control switch. See «MASTER WINDOW SWITCH TEST»(ref-138783-S26573262362002043000000) table. (Scheme 46)
  3. If the master window regulator control switch does not operate as specified, replace the master window regulator control switch. See «POWER WINDOW SWITCH»(ref-138783-S04561537892002042900000) under REMOVAL & INSTALLATION.
Control SwitchSwitch PositionTest Between Terminals No.
LeftUP1-7
LeftNeutral1-8
LeftDOWN2-1, 2-8 &1-8
LeftOne-Touch3-2, 3-1, 3-8, 2-1, 2-8 &1-8
RightUP8-6 & 7-5
RightNeutral8-6, 8-5 & 6-5
RightDOWN8-5 & 7-6
LockOFF8-6

MASTER WINDOW SWITCH TEST

Right Front Switch

  1. Turn the ignition switch to OFF position.
  2. Remove the right window regulator control switch. See «POWER WINDOW SWITCH»(ref-138783-S04561537892002042900000) under REMOVAL & INSTALLATION.
  3. Leave the electrical connector connected.
  4. Turn the ignition switch to ON position.
  5. Check for voltage at the right window regulator control switch terminals, while moving the right window regulator control switch. See «RIGHT WINDOW CONTROL SWITCH TEST»(ref-138783-S36409529122002043000000). (Scheme 48)
Switch PositionCheck Terminal No.Voltage
UP1Less Than 1
UP4More Than 10
Neutral1Less Than 1
Neutral4Less Than 1
DOWN1More Than 10
DOWN4Less Than 1

RIGHT WINDOW CONTROL SWITCH TEST

Scheme 48

Scheme 48
Scheme 48
  1. Turn ignition switch to OFF position
  2. Disconnect power rear quarter glass window control switch.
  3. Measure the resistance between specified terminals on control switch connector. (Scheme 49) See «REAR QUARTER GLASS SWITCH TEST»(ref-138783-S09055651432002043000000) table.
  4. Replace the switch if operation is not as specified. See «POWER WINDOW SWITCH»(ref-138783-S04561537892002042900000) under REMOVAL & INSTALLATION.
SwitchPositionCheck Between Terminals No.Measured Resistance
LeftOPEN6-3 & 5-4Less Than 5 Ohms
LeftOPEN5-3 & 6-4More than 10,000 Ohms
LeftNeutral6-4 & 5-4Less Than 5 Ohms
LeftNeutral5-3 & 6-3More Than 10,000 Ohms
LeftCLOSE5-3 & 6-4Less Than 5 Ohms
LeftCLOSE5-4 & 6-4Greater Than 10,000 Ohms
RightOPEN1-4 & 2-3Less Than 5 Ohms
RightOPEN1-3 & 2-4More Than 10,000 Ohms
RightNeutral1-4 & 2-4Less Than 5 Ohms
RightNeutral1-3 & 2-3More Than 10,000 Ohms
RightCLOSED1-3 & 2-4Less Than 5 Ohms
RightCLOSED1-4 & 2-3More Than 10,000 Ohms

REAR QUARTER GLASS SWITCH TEST

Scheme 49

Scheme 49
Scheme 49

Front Motors

  1. Turn the ignition switch to OFF position.
  2. Disconnect the window regulator electric drive connector in question.
  3. Using jumpers, connect one of the terminals on the window regulator electric drive to the battery positive terminal. Connect the other terminal on the window regulator electric drive to the battery negative terminal. (Scheme 50)
  4. Reverse the jumpers on the window regulator electric drive.
  5. The window will move in one direction (down or up) when battery voltage is supplied. When battery voltage is reversed, the window regulator electric drive operates the window in the opposite direction.
  6. If the window regulator electric drive does not operate as specified, replace the window regulator electric drive. See «MOTOR»(ref-138783-S28463637212002043000000) under REMOVAL & INSTALLATION.

Scheme 50

Scheme 50
Scheme 50
  1. Turn the ignition switch to OFF position.
  2. Disconnect the power rear quarter glass motor connector in question.
  3. Using a jumper, connect one of the terminals on the power rear quarter glass motor to the battery's positive terminal.
  4. Using a jumper, connect the other terminal on the power rear quarter glass motor to the battery's negative terminal. (Scheme 50)
  5. Reverse the jumpers on the power rear quarter glass motor.
  6. The rear quarter glass will open or close when battery voltage is supplied. When the battery's voltage is reversed, the rear quarter glass will operate in the opposite direction.
  7. If the power rear quarter glass motor does not operate as specified, replace the power rear quarter glass motor. See «MOTOR»(ref-138783-S28463637212002043000000) under REMOVAL & INSTALLATION.

DOOR TRIM PANEL

CAUTIONUse care when removing the front door inside handle escutcheon. Failure to do so can result in damage to the component.
CAUTIONSupport the rear quarter glass before removing the two rear quarter glass hinge nuts. If the glass is not supported it may fall and break or cause damage to the vehicle.
