Air conditioning — A/c circuit Mercury Tracer I

Components on these wiring diagrams 22

Click a component to highlight it on every diagram it appears on.

• A/C Clutch Field Coil
• A/C Low Pressure Switch
• A/C Switch
• A/C Wac Relay
• A/C- Heater Control Assembly A/C On Indi- Cator
• Blower Circuit Breaker
• Blower Motor
• Blower Motor Relay
• Blower Switch
• Constant Control Relay Module
• Cooling Fan Fusible Link
• Electric Cooling Fan
• Engine Compartment Fuse Box Fuel Injector Fusible Link
• Engine Fuse
• I/P Fuse
• I/P Fuse Panel
• J/C 3
• J/C 6
• Lfc Relay Control Solid State
• Panel Floor Panel Floor Flr/Def A/C Max A/C Defrost
• Powertrain Control Module
• Resistor
