ENGINE COMPRESSION

Warm engine to normal operating temperature. Check compression at cranking speed with throttle wide open and all spark plugs removed. Ensure crankcase is at correct level and oil is of correct viscosity. With compression gauge installed, use remote starter to crank engine.

Crank engine 5 revolutions (minimum) and record highest reading. Repeat procedure for all cylinders using approximately same number of revolutions. Lowest compression reading should not be less than 75 percent of highest compression reading. Cylinder compression readings should not be less than 100 psi (7 kg/cm 2 ).

ApplicationCompression Ratio
1.9L9.0:1

COMPRESSION RATIO SPECIFICATIONS

VALVE CLEARANCE

Note. Hydraulic valve lifters are used and valve adjustment is not required. If incorrect valve clearance is suspected, lifter must be collapsed before clearance can be checked.

ApplicationIn. (mm)
Intake & Exhaust
Allowable0-.177 (0-4.50)
Preferred0-.087 (0-2.21)

COLLAPSED VALVE LIFTER CLEARANCE

IGNITION COIL

ApplicationPrimary (Ohms)Secondary (Ohms)
1.9L(1)(1) *
(1) Resistance value is not available. For testing, see IGNITION SYSTEMS in the SYSTEM/COMPONENT TESTS - EEC-IV (1.9L) article in the ENGINE PERFORMANCE section.
(1)Resistance value is not available. For testing, see IGNITION SYSTEMS in the SYSTEM/COMPONENT TESTS - EEC-IV (1.9L) article in the ENGINE PERFORMANCE section.

IGNITION COIL RESISTANCE

HIGH TENSION WIRE RESISTANCE

Application (1)Ohms
1.9L4000-7000 Per Foot
(1) On distributorless systems, high tension wire resistance is 30,000 ohms max. for entire wire.
(1)On distributorless systems, high tension wire resistance is 30,000 ohms max. for entire wire.

HIGH TENSION WIRE RESISTANCE

SPARK PLUGS

ApplicationMotorcraft No.
1.9LAGSF-34PP

SPARK PLUG TYPE

ApplicationGap: In. (mm)Torque: Ft. Lbs. (N.m)
1.9L.054 (1.37)15 (20)

SPARK PLUG SPECIFICATIONS

Identifying Firing Order & Timing Marks (1.9L). Scheme 2

Scheme 2: Identifying Firing Order & Timing Marks (1.9L)

Scheme 3

Scheme 3

IGNITION TIMING

ApplicationDegrees BTDC @ Idle
1.9L(1) (2) 10
(1) Disconnect single in-line SPOUT connector, or remove shorting bar from double-wire SPOUT connector. (2) Timing is not adjustable.
(1)Disconnect single in-line SPOUT connector, or remove shorting bar from double-wire SPOUT connector.
(2)Timing is not adjustable.

BASE IGNITION TIMING

FUEL PUMP

Note. For fuel pressure specifications, see FUEL PRESSURE SPECIFICATIONS article.

IDLE SPEED & MIXTURE

Note. Idle mixture is not adjustable. If idle mixture is incorrect, see TESTS W/CODES - EEC-IV (1.9L) article in the ENGINE PERFORMANCE section.

ModelRPM
1.9L(1) 730-830
(1) Idle speed is not adjustable.
(1)Idle speed is not adjustable.

IDLE SPEED SPECIFICATIONS

THROTTLE POSITION (TP) SENSOR

Throttle Angle(1) Volts
.50
10°.97
20°1.44
30°1.90
40°2.37
50°2.84
60°3.31
70°3.78
80°4.24
(1) Values may vary by 15 percent.
(1)Values may vary by 15 percent.

TP SENSOR SPECIFICATIONS
