COMPONENT TESTING
Note. Specific component testing information not available. Refer to any tests performed during REMOVAL & INSTALLATION or OVERHAUL procedures
Some models with fuel injection use a inertial switch (Ford Motor Co.) to stop the fuel pump if the engine stops or a collision occurs. The cut-off switch contacts close when oil pressure is above 4 psi (.3 kg/cm 2 ). This provides a secondary power feed to the fuel pump if the fuel pump relay fails. The cut-off switch is located in the oil pressure sending unit.
The inertia (may also be called shut-off) switch contacts are usually closed to complete the fuel pump circuit. If inertia switch is triggered the White reset button will pop up. Inertia switches are located in various positions in rear sections of the vehicle. To reset inertia switch, push White reset button down.
View of Escort, EXP & Excort Shut-Off Switch. Scheme 17
View of LTD & Marquis Shut-Off Switch Sedan Model inertia switch shown. Scheme 18
COMPONENT LOCATIONS
| Model | Location | |
|---|---|---|
| Capri & Mustang | ||
| Coupe & Convertible | Below Left Trunk Hinge | |
| Hatchback | Left Tail Light Trim Panel | |
| Continental & Town Car | At Left Trunk Hinge Panel | |
| Crown Victoria & Grand Marquis | ||
| Sedan | Left Side of Trunk | |
| Station Wagon | Left Storage or Automatic Load Level Compressor Compartment | |
| Escort, EXP & Lynx | ||
| Hatchback | Behind Right Truck Panel | |
| Station Wagon | Left Rear Piller | |
| LTD & Marquis | ||
| Sedan | Behind Right Trunk Panel | |
| Station Wagon | Left Rear Storage | |
| Mark VII | On Left Trunk Hinge | |
| Tempo & Topaz | Behind Left Trunk Panel | |
INERTIA/SHUT-OFF SWITCH LOCATIONS
