STARTER SPECIFICATIONS
| Application | Specification |
|---|
| Brush Length |
| New | .55-.66" (14-17 mm) |
| Service Limit | .25" (6.4 mm) |
| Brush Spring Tension | 64 ozs. (2.3 kg) |
| Commutator |
| Diameter | (1) |
| Runout | (2) .005" (.13 mm) |
| Starter Load Test |
| Maximum Current Draw | 130-220 Amps |
| Starter No-Load Test |
| Maximum Current Draw | 60-80 Amps |
| (1) Not specified by manufacturer. (2) Replace armature if runout exceeds specification. |
| (1) | Not specified by manufacturer. |
| (2) | Replace armature if runout exceeds specification. |
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|
| Starter-To-Engine Bolts | 15-20 (20-27) |
| INCH Lbs. (N.m) |
| Brush End Plate Bolts | 55-80 (6-9) |
| Cable Terminal Nut | 70-130 (7.9-14.7) |
| Solenoid Bolts | 45-85 (5-10) |
| Solenoid Terminal Nuts | 80-124 (9-14) |
| Through-Bolts | 55-75 (6.2-8.5) |
Starter System Wiring Diagram (3.0 2V & 3.0L Flex-Fuel). Scheme 1
Scheme 1: Starter System Wiring Diagram (3.0 2V & 3.0L Flex-Fuel)
Starter System Wiring Diagram (3.0L 4V & 3.4L SHO). Scheme 2
Scheme 2: Starter System Wiring Diagram (3.0L 4V & 3.4L SHO)
