Interior Fuse Panel Identification

Fuse panel is located to left of steering column under instrument panel. To expose fuse panel, pull release bar up with right hand and pull panel down with left hand.

Scheme 1

Fuse & Circuit Breaker Identification

1. 1 - Not Used
2. 2 - 5 Amp (Tan) Instrument Illumination
3. 3 - 10 Amp (Red) Left Headlamp (Low-Beam)
4. 4 - 10 Amp (Red) Right Headlamp (Low-Beam)
5. 5 - 5 Amp (Tan) Brake/Shift Interlock, Rear Defroster
6. 6 - 15 Amp (Light Blue) MLPS Switch, Backup Lamps, Speed Control, Climate Control
7. 7 - 10 Amp (Red) MLPS Switch, Starter Relay
8. 8 - 5 Amp (Tan) Power Antenna, Radio Control Unit, GEM
9. 9 - 10 Amp (Red) ABS Brake System, Central Temperature Monitor
10. 10 - 20 Amp (Yellow) Electronic Engine Control (EEC) Relay, Ignition Coil, Passive Anti-Theft System, Radio
11. 11 - 5 Amp (Tan) Air Bag Indicator, Instrument Cluster
12. 12 - 5 Amp (Tan) Instrument Cluster, Autolamps, Transmission Control Switch, Integrated Control Panel, GEM
13. 13 - 5 Amp (Tan) Air Bag, Blower Motor, Electronic Automatic Temperature Control
14. 14 - 5 Amp (Tan) Lamp Outage Indication, Semi-Active Suspension (SHO Only)
15. 15 - 10 Amp (Red) Multi-Function Switch, (Turn Signal)
16. 16 - Not Used
17. 17 - 30 Amp (Light Green) Wiper System (Front)
18. 18 - 5 Amp (Tan) Headlamp Switch
19. 19 - 15 Amp (Light Blue) Wiper System (Rear)
20. 20 - 5 Amp (Tan) Integrated Control Panel, Remote Entry, Cigar Lighter
21. 21 - 20 Amp (Yellow) Cigar Lighter
22. 22 - 5 Amp (Tan) Power Mirrors, Power Antenna, Decklid Lamps, Autolamps
23. 23 - 5 Amp (Tan) Wiper System, Variable Assist Steering, Remote Entry, Anti-Theft Variable Assist Power Steering
24. 24 - 5 Amp (Tan) Radio
25. 25 - 15 Amp (Light Blue) Integrated Control Panel Speedometer, Electronic Automatic Temperature Control Module
26. 26 - 15 Amp (Light Blue) Trunklid
27. 27 - 10 Amp (Red) Battery Saver Relay
28. 28 - 15 Amp (Light Blue) Brake Lamps, Stop Control
29. 29 - 15 Amp (Light Blue) Multi-Function Switch, Hazard Flashers
30. 30 - 15 Amp (Light Blue) Headlamps (High-Beam), Daytime Running Lamps, Instrument Cluster
31. 31 - 5 Amp (Tan) Tail Lamp Feed
32. 32 - 10 Amp (Red) Integrated Control Panel, Heated Mirrors
33. 33 - 5 Amp (Tan) Power Windows, Lock Illumination

Relay Identification

1. 34 - Battery Saver Relay
2. 35 - Driver Door Unlock Relay
3. 36 - Rear Defroster Relay
4. 37 - Interior Lamps Relay
5. 38 - One Touch Window Down Relay
6. 39 - Accessory Delay Relay

Scheme 2

1. Maxi Fuses * * Mini Fuses
2. 1 - 40 Amp (Orange) Fuse Panel
3. 2 - 30 Amp (Light Green) Constant Control Relay Module
4. 3 - 40 Amp (Orange) Ignition Switch, Starter Relay
5. 4 - 30 Amp (Light Green) Accessory Delay Relay
6. 5 - 40 Amp (Orange) Ignition Switch
7. 6 - 30 Amp (Light Green) Power Seats
8. 7 - 40 Amp (Orange) Rear Window Defrost Relay
9. 8 - 30 Amp (Light Green) Thermactor Air Bypass Solenoid, EAM Solid State Relay
10. 9 - 40 Amp (Orange) Constant Control Relay Module
11. 10 - 20 Amp (Yellow) Constant Control Relay Module
12. 11 - 40 Amp (Orange) Blower Motor Relay
13. 12 - 20 Amp (Yellow) Semi-Active Ride Control Module
14. 13 - 40 Amp (Orange) Anti-Lock Motor Module
15. 14 - Not Used
16. 15 - 15 Amp (Blue) Daytime Running Lamps (DRL) Module
17. 16 - 10 Amp (Blue) Air Bag Diagnostic Monitor
18. 17 - 20 Amp (Yellow) Rear Control Unit, CD Changer
19. 18 - 30 Amp (Light Green) Anti-Lock Brake Module
20. 19 - 15 Amp (Blue) Horn Relay, Powertrain Control Module
21. 20 - 15 Amp (Blue) Headlamp Switch, Autolamp Park Relay
22. 21 - Not Used
23. 22 - 30 Amp (Light Green) Autolamps Relay, Multi-Function Switch, Headlamp Switch
24. 23 - N/A
25. 24 - N/A
26. 25 - N/A
27. 26 - 30 Amp (Light Green) Generator/Voltage Regulator
28. 27 - N/A
29. 28 - 15 Amp (Blue) Heated Oxygen Sensors, Canister Vent
30. 29 - N/A
31. 30 - N/A
32. 31 - N/A
33. 32 - N/A
34. 33 - N/A
